Please read this manual carefully before using the Cambo WRE-CA lens panel!
Figure 1: WRE-CA user interface
INSTRUCTION MANUAL
WRE-CA Canon
aperture controller
WRE-CA lens panel – WRS series
A
On/Off button
B
Active state LED
C
USB-C port
D
Battery indicator LED
E
Max. open aperture
F
Stop down aperture
G
Stop up aperture
H
Toggle to work aperture
I
Display
®
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cambo WRS Series
Summary of Contents for Cambo WRS Series
- Page 1 WRE-CA Canon ® aperture controller WRE-CA lens panel – WRS series INSTRUCTION MANUAL Please read this manual carefully before using the Cambo WRE-CA lens panel! On/Off button Active state LED USB-C port Battery indicator LED Max. open aperture Stop down aperture...
- Page 2 User instructions The WRE-CA is compatible with Cambo WRS and Phase One XT camera systems. To make good use of EF lenses a digital back with on-sensor shutter is required. Mount a Canon lens to the lens panel by aligning the red dot and turning the lens counter clockwise until the lens snaps in the lens lock.
