- Page 1 WRS-HVSA For Cambo Wide Camera’s INSTRUCTION MANUAL this manual using the WRS-HVSA! Please read carefully before Version 1.0...
- Page 3 INDEX WRS-HVSA Key-features _________________________________ 4 Lens mount ___________________________________________ 5 WRS-HVSA workings ____________________________________ 6 Connecting your digital back ______________________________ 7 Removing the lens ______________________________________ 7...
- Page 4 1. WRS-HVSA Key-features Figure 1: WRS-HVSA key-features. Cable release Manual release Cocking lever Lens lock...
- Page 5 To mount the lens to the WRS-HVSA, place the red triangle mark on the lens in front of the red dot on the WRS-HVSA and mount the lens to the adapter by rotating it clockwise until you hear a click.
- Page 6 3. WRS-HVSA workings If the lens is mounted correctly, the WRS-HVSA and lens are ready for making a capture. At first the shutter will be open. Push the cable release once briefly to close the shutter. You can notice the cocking lever will move to the half way point.
- Page 7 5. Removing the lens Before unmounting the lens, the WRS-HVSA must be cocked by pulling the cocking lever towards the cable release. After cocking the WRS-HVSA the lens can be unmounted by pushing the lens lock and simultaneously rotating the...
- Page 8 This instruction manual is prepared with care, although no responsibility, financial or otherwise, is accepted for any consequences related the information stated in this instruction manual. All specifications in this instruction manual are subject to change without notice. For more information please visit the Cambo web site: www.cambo.com...
