- Page 1 MAIN OPERATING INSTRUCTIONS Wide DS...
- Page 2 1. INTRODUCTION These instructions give short information about the main functions of the new Wide DS camera. The functions that differ from the existing Cambo wide camera will get most attention. 2. LIST OF FUNCTIONS 1. Housing camera 6. Horizontal Shift Locking Knob 2.
- Page 3 INSTRUCTIONS Most functions speak for themselves. The main difference to the existing Cambo Wide camera is the double shift (vertical and horizontal simultaneously) and the extra shift stroke upwards (40 mm). This has been made possible by applying the shift close to the camera body. That is why this camera system uses filling houses at the backside to get the lens focal distances exactly right.
-
Page 4: Specifications
38 XL, 47 XL, 58 XL, 72 XL, 6.8/90 and 5.6/150L Schneider lenses. For other lens solutions contact your Cambo dealer. For the use of all lenses except for the 38 and the 47mm we use modules at the back to get the Ground glass holder at the right position.
