Maintenance - Shark POWERDETECT HZ4000 Series Owner's Manual

MAINTENANCE

IMPORTANT: Unplug the vacuum before performing any maintenance.
EMPTYING THE DUST CUP
Empty the dust cup each time you vacuum and periodically during cleaning, when debris in
the dust cup reaches the MAX fill line.
Press the Wand Release button and lift off
the handheld vacuum.
Hold the dust cup over the trash. Pull back
on the yellow Empty button and pull up to
open the dust cup lid until it clicks and locks
in the open position. Gently tap the cone-
shaped screen inside the dust cup to knock
dust and debris into the trash.
s h a r kc l e a n . c o m
To remove the dust cup from the handheld
vacuum, press the two Dust Cup Release
buttons at the same time and pull out the
dust cup from the top.
To reinstall, push the lid closed, then insert
the dust cup into the handheld vacuum from
the top, until it clicks into place.
MAINTENANCE
IMPORTANT: Unplug the vacuum before performing any maintenance.
CLEANING FILTERS
Regularly rinse and replace the filters to maintain your vacuum's suction power and to
maximize the effectiveness of Odor Neutralizer Technology. To prevent damage from cleaning
chemicals, rinse filters with cold water only. Do not use soap. Allow all filters to air-dry for at
least 24 hours before reinstalling them to prevent liquid from being drawn into electronic parts.
PRE-MOTOR FILTERS
The Pre-Motor Filters should be rinsed
every month. To remove the pre-motor
filters, detach the dust cup, then slide down
the Filter Access buttons on both sides of
the dust cup lid. Pull out the filter housing,
then lift out the Foam Filter. Next, remove
the Felt Filter by the pull tab. After the
filters have been rinsed and are completely
dry, insert the foam filter into the housing
first, then slide in the felt filter, and reinstall
the housing into the dust cup lid.
NOTE: The pre-motor filters should be replaced every 2.5 years. The post-motor filter should be replaced every 3 years.
HEADLIGHT INDICATOR LIGHTS
HEADLIGHTS
The headlights will flash or turn red to
indicate issues that need attention.
HEPA FILTER
The HEPA Filter should be rinsed every 6
months. To remove the HEPA filter, detach
the dust cup, then pull the Filter Release
tab on the handheld vacuum filter cover.
Remove the cover, then squeeze the side
tabs on the HEPA filter and lift it out. After
the filter has been rinsed and is completely
dry, reinsert it into the handheld vacuum,
then reattach the filter cover.
Solid White Lights: The brushroll is spinning
and the unit is working as it should.
Solid Red Lights: There is a jam in the
brushroll area. Turn off the vacuum and unplug
it, then remove any blockages in the nozzle.
Flashing Red Lights: The motorized floor
nozzle is overheating. Turn off the vacuum,
unplug it, and remove any blockages. Let the
vacuum cool down for at least 60 minutes
before restarting. See Troubleshooting
section for more information.
Flashing White Lights: The vacuum is
operating in an environment that is either too
hot or too cold. This vacuum will only function
properly in temperatures ranging from 32°F
(0°C) to 104°F (40°C). Turn the vacuum off
and adjust the room temperature.
