Broadcom F5D7010CE1 Test Report page 16

CETECOM Inc.
Test report no.:EMC_381EN328-2002
SPURIOUS EMISSIONS
(Radiated)
Transmitter operating
NOTE:
1. Measurements were done on low & high channels, but plots depicting the worst case are submitted in the test report.
2. The spurious emissions were done with different settings, using the relevant pre-amplifiers for the relevant frequency
ranges. This is the reason that the graphs show different noise levels.
Lowest Frequecy
f
(MHz)
NF
NF
NF
NF
NF
NF
NF
NF
NF
NF
NF
Measurement
uncertainty
Note: NF = No Significant Peak was found.
LIMITS
Frequency Range
30 MHz - 1 GHz
above 1 GHz - 12,75 GHz
1,8 - 1,9 GHz
5,15 - 5,3 GhZ
Issue date:2003-01-10
Band- Level
width (dBm)
(kHz)
Narrowband spurious
emissions
Limit when
operating
-36 dBm
-30 dBm
-47 dBm
CLAUSE 5.2.4
Highest Frequecy
f Band-
(MHz) width
(kHz)
NF
NF
NF
NF
NF
NF
NF
NF
NF
NF
NF
± 6 dB
Wideband spurious emissions
Limit when Limit when
in standby operating
-57 dBm -86 dBm/Hz
-47 dBm -80 dBm/Hz
-47 dBm -97 dBm/Hz
Page 16 (33)
Level
(dBm)
Clause 5.2.4
Limit when
in standby
-107 dBm/Hz
-97 dBm/Hz
-97 dBm/Hz
