VEVOR MHTJXM01F User Manual

VEVOR MHTJXM01F User Manual

Cotton candy makers
Hide thumbs Also See for MHTJXM01F:

Advertisement

Table of Contents

Technical Support and E-Warranty Certificate www. vevor. com/support
COTTON CANDY MAKERS
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and does not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MHTJXM01F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VEVOR MHTJXM01F

Summary of Contents for VEVOR MHTJXM01F

  • Page 1 Technical Support and E-Warranty Certificate www. vevor. com/support COTTON CANDY MAKERS USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an...
  • Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 4: Important Safeguards

    Warning-To reduce the risk of injury, user must read instructions manual carefully. CORRECT DISPOSAL This product is subject to the provision of european Directive 2012/19/EU. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union.

  • Page 5: Product Parameters

    3) The extension cord should be a grounding-type 3-wire cord. PRODUCT PARAMETERS Heating Dimensions(mm) Model Voltage Frequency Plate Power MHTJXM01F MHTJXM01H AC120V 60Hz MHTJXM01L MHTJXM02F 518*518*415 MHTJXM03F MHTJXM02H...

  • Page 6: Packing List

    PACKING LIST Item Part Name Picture Cotton Candy Machine 1 PCS Stainless Steel Bowl 1 PCS Stainless Steel Sugar Scoop 1 PCS Carbon Brush 1 PCS Fuse 1 PCS Power Cord 1 PCS User Manual 1 PCS Installation Tools Note: For the cart-style ones only. 1 SET - 4 -...
  • Page 7 INSTALLATION KIT ACCESSORIES LIST Note: Only the cart-style machines come with the installation kits. Item Part Name Picture Wheel 2 PCS Table 1 PCS Handle 1 PCS (P1) - Long Bracket 2 PCS (P2)-Short Bracket (Wheel Mounting) 2 PCS (P3)-Transverse Fixing Bracket 3 PCS Plastic Pad 2 PCS...
  • Page 8 PRODUCT COMPOSITION DIAGRAM Spinning Head Bowl Voltmeter Fuse Heating Switch Power Plug Power Switch Drawer Cotton Candy Machine (Countertop Type with Cabinet) - 6 -...
  • Page 9 Spinning Head Bowl Voltmeter Heating Power Plug Switch Fuse Power Switch Cotton Candy Machine (Countertop Type) Cotton Candy Machine (Cart Type) - 7 -...
  • Page 10 Please install the wheels for the Cart Type in the following order. 1．Use screws (M5*12) and screws (M5*35) to install the bracket as shown in the figure. The installation steps on both sides are the same. Screws (M5*12) (P1)- Long Bracket (P2)-Short Bracket (Wheel Mounting) (P3)-Transverse...
  • Page 11 2．Install two wheels under the frame with two Bolts (M8*70). (P2)-Short Bracket (Wheel Mounting) (P3)- Wheel Transverse Fixing Bracket Bolt (P1)- Long Bracket 3．Install the table on the left side of the main body, and install the push handle on the right side with 8 pcs Screw (M5*12) Table Screw (M5*12) Main Body...
  • Page 12 Table Push Handle 4．Place the stainless steel pan on top of the box and fix it with the 4 locking clips on both sides. - 10 -...

  • Page 13: Operation Precautions

    5．After all assembly is completed, it is ready to use. Please properly keep the other components, which will be used during use or maintenance. OPERATION PRECAUTIONS 1．Please read this manual carefully before use. In order to give full play to its advantages and achieve satisfactory results, please understand the structure and function of the machine, and be familiar with its main parts and related safety operations.
  • Page 14 OPERATING INSTRUCTIONS 1．Press the switch to turn on the machine and wait for 1-2 minutes. Observe whether the machine runs smoothly when the spinning head of the machine is rotating. If the vibration is too severe, the machine needs to be adjusted. It must be ensured that the machine is placed stably.

  • Page 15: Circuit Diagram

    machine to cool down. 4．Do not touch the rotating spinning head when the machine is working. Do not reach your hands.into the bowl until the sugar is gone. To avoid burns, do not move the machine while it is working. 5．Do not touch the plug or wire when the plug or wire is wet or your hands are wet, otherwise it may cause an electric shock.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Fault: No Sugar Filament 1．Check whether the sugar head is rotating or not, and stop the machine to sense whether the sugar head is hot. 2．If the sugar head does not rotate: check whether the machine is powered on, and whether the motor is broken.
  • Page 17 3．Replace the new carbon brush, place it in position and fix it with screws, and plug in the connecting end. 4．Check the installation of the new carbon brush. (whether the spring and the installation contact is good) 5．Reinstall the top cover and baffle, complete the carbon brush replacement. Note: The carbon brush is a consumable and should be replaced after a period of use.
  • Page 18 Adjust the voltage knob to Max, and the voltmeter will change with the adjustment. Warm up the machine for 2-3 minutes. After preheating, the voltage can be adjusted according to the user's temperature requirements. WARNING Please read the instructions carefully and use them correctly. Wrong use may cause personal injury and product damage.
  • Page 19 COTTON CANDY TROUBLESHOOTING Description of Adverse Solution Remark Phenomena. The switch light is on, no heating, Replace Carbon Brush. Reference replacement video. Please contact customer service for a video ignition. The switch light does not light up, the Reference replacement video. spinning head does not rotate, and it Replace Fuse.
  • Page 20 Technical Support and E-Warranty Certificate www. vevor. com/support...
