- Page 1 Operating Instruction Please read this instruction carefully before use...
- Page 2 CONTENES Ⅰ Machine construction ............1 Ⅱ Safety attention ..............2 Ⅲ Work condition .................2 Ⅳ Installation ................2 Ⅴ Operating instruction ............3 Ⅵ Maintenance ................5 Ⅶ Specification and electrical diagram ......8...
- Page 3 Machine Construction Single Cylinder Series Name Name Name Drip dray Beater Evaporetor Grate for drip tray Beater cover Machine base Operation mask Cover Condenser Front panel Motoreductor wire Expect nib Inner cover O-Ring Bush for motoreductor Back panel Rear agitator Side panel Spring Tank...
- Page 4 Safety attention Do not touch the machine with wet hands and do not ever insert any part of your body into any part of the machine while it is plugged in or operating, as serious injury may occur. Do not wear loose fitting clothing when operating the machine, as serious in ...
- Page 5 that may have occurred during the shipping .Remove the protective coverings (plastic bags, etc.) and insure that they are stored out of the reach of children. The equipment must never be lifted by the tank or plastic components when being moved, and improper handling may damage near the machine .Always lift the machine by the bottom of the machine near the legs and hold the machine on both...
- Page 6 to the drink. Fill the tanks with mix, but no more than up to the maximum level, and replace the cover top cover on the bowl WARNING the equipment is not designed for sugar-free liquids. If you use a natural juice or mix product, then the sugar content must be between 15% and 25%.
- Page 7 4" Online speed measurement: In the cleaning state, long press the cleaning key for 5 seconds to enter the online speed measurement mode. At this time, all indicator lights flash and prompt, and the screen displays the current motor speed. After 20 seconds, the speed measurement ends.
- Page 8 Empty the tanks; Fill the tanks with tepid water to remove the product; Residue and rinse outTo remove the paddle, turn it counter clockwise and after pull it as in the picture. (Fig.2) Fig.2 To remove the tank, pull it as in ...
- Page 9 To clean the dispensing nozzle: Remove the lever safety plug pull in it indicate direction Remove lever picture(Fig.4) Remove the lever it will be possible to extract tap and the spring Fig.4 Fig.5 To reassemble the tank, is necessary to the tank gasket. The gasket may be installed on the bottom of the bowl or on the evaporator.
- Page 10 Every 30 days the dust that accumulated on the condenser should be removed/cleaned. To remove the dust, unplug the machine, remove the right panel, and vacuum or lightly dist the condenser to remove the dust. Reinstall the panel before operating or plugging in the machine. Ⅶ...
