- Page 1 Shelleyglas FlexiWell™ Shelleyglas by Del eld by Del eld Dry Serving Lines Shelleysteel Shelleysteel by Del eld by Del eld Installation, Operation and Maintenance Manual Caution Read this instruction before operating this equipment. Original Document Part Number: 9291544-GEN2 12/24...
-
Page 2: Table Of Contents
Table of Contents Section 1 General Information Model Numbers ........................5 Serial Number Location ..................... 5 Warranty Information ......................5 Regulatory Certifications ....................5 Section 2 Specifications General Specifications ....................... 6 Weight ..........................7 Dimensions ......................... 8 Clearance Requirements ....................13 Electrical Service ......................13 Voltage .............................. - Page 3 Table of Contents (continued) THIS PAGE INTENTIONALLY LEFT BLANK Part Number: 9291544-GEN2 03/24...
-
Page 4: Safety Notices
Safety Notices Warning This product contains chemicals known to the State Warning of California to cause cancer and/or birth defects or Read this manual thoroughly before operating, installing other reproductive harm. Operation, installation, and or performing maintenance on the equipment. Failure servicing of this product could expose you to airborne to follow instructions in this manual can cause property particles of glasswool or ceramic fibers, crystalline... -
Page 5: General Information
Warranty Information • Register your product for warranty, • Verify warranty information, • View and download a copy of your warranty, at www.delfield.com/warranty Part Number: 9291544-GEN2 03/24... -
Page 6: Specifications
Section 2 Specifications GENERAL SPECIFICATIONS CHART FlexiWell™ Mobile Hot and Cold Combo Serving Counters Shelleyglas® Shelleysteel® 12” x20” Pan Hot Electrical Cold Electrical Nema System Heat of R290 Charge Capacity Plug Capacity Rejection Amount (BTU) KFW-1-NU SFW-1-NU 500 W, 120/208Y-240V, 120 V, 1/5HP, 14-20P 2.0 A... -
Page 7: Weight
Section 2 Specifications WEIGHT FlexiWell™ Mobile Hot and Cold Combo Serving Counters Shelleyglas® Shelleysteel® Weight KFW-1-NU SFW-1-NU 300lbs (136kg) KFW-2-NU SFW-2-NU 380lbs (172kg) KFW-3-NU SFW-3-NU 460lbs (209kg) KFW-4-NU SFW-4-NU 550lbs (249kg) KFW-5-NU SFW-5-NU 660lbs (299kg) KFW-6-NU SFW-6-NU 720lbs (327kg) FlexiWell™ Hot and Cold Combo Serving Counters EcoMark®... -
Page 8: Dimensions
Specifications Section 2 DIMENSIONS FlexiWell™ Drop-In Hot and Cold Combo Serving Counters Model Length Depth Height N8618-FWP 18” (46cm) N8633-FWP 33” (84cm) N8648-FWP 48” (122cm) 26” 26.03” (66cm) (67cm) N8663-FWP 63” (160cm) N8678-FWP 78” (198cm) N8693-FWP 93” (237cm) FlexiWell™ ShelleySteel Mobile Hot and Cold Combo Serving Counters Model Length Depth... - Page 9 Section 2 Specifications Dimension Images FlexiWell™ N8600 Drop-In Series Part Number: 9291544-GEN2 12/24...
- Page 10 Specifications Section 2 FlexiWell™ SFW ShelleySteel Series ® Part Number: 9291544-GEN2 12/24...
- Page 11 Section 2 Specifications FlexiWell™ KFW ShelleyGlas Series ® Part Number: 9291544-GEN2 12/24...
- Page 12 Specifications Section 2 FlexiWell™ EcoMark 1042 Series ® Part Number: 9291544-GEN2 12/24...
-
Page 13: Clearance Requirements
Section 2 Specifications Clearance Requirements Clearance Dimensions Model Bottom Sides Back DANGER CAUTION FlexiWell™ The flooring under the appliance must be made of a KFW Series 12” 0” 0” 0” noncombustible material. SFW Series 12” 0” 0” 0” DANGER EcoMark 12”... - Page 14 Specifications Section 2 THIS PAGE INTENTIONALLY LEFT BLANK Part Number: 9291544-GEN2 12/24...
- Page 15 Section 2 Specifications THIS PAGE INTENTIONALLY LEFT BLANK Part Number: 9291544-GEN2 12/24...
-
Page 16: Installation
Section 3 Installation The location selected for the equipment must meet the DANGER following criteria. If any of these criteria are not met, select Installation must comply with all applicable fire and another location. health codes in your jurisdiction. • Units are intended for indoor use only. -
Page 17: Leveling
Section 3 Installation Cooled Wells Leg & Caster Installation Warning If a refrigerated base does not have a condensate Legs or casters must be installed and the legs or casters evaporator supplied, you must connect the condensate must be screwed in completely to prevent bending. line to a suitable drain. -
Page 18: Self-Contained Flexi Drop-In Cabinet Dimensions
Installation Section 3 SELF-CONTAINED FLEXIWELL DROP-IN UNITS 7. Louver cutout must extend to bottom of cabinet and align with condenser face. FlexiTop N8600-FWP Cut-Out Dimentions NOTE: The louver provided must be installed in For any non-standard installation consult the factory. front of CONT: the condensing unit’s finned coil. - Page 19 Section 3 Installation CABINET INTERIOR MINIMUM DIMENSIONS N8618-FWP N8633-FWP N8648-FWP N8663-FWP N8678-FWP N8693-FWP 29.75"/76cm 36.25"/103cm 51.25"/130cm 64"/163cm 79"/201cm 94"/239cm 29"/74cm 28"/71cm 17"/43cm 32"/82cm 47"/120cm 62"/158cm 77"/196cm 92"/234cm 25"/64cm 4.75"/12cm "Min 2.75""/7cm - Max 4.75""/12cm" 11.38"/29cm 16.38"/42cm 21.38"/55cm 26.38"/67cm 31.38"/80cm 8.50"/22cm 8.0"/21cm 8.00"/21cm 8.00"/22cm...
-
Page 20: Operation
Section 4 Operation Caution DANGER Units with pans should be operated with pans in place. The on-site supervisor is responsible for ensuring that Operating the unit without all pans in place will lower operators are made aware of the inherent dangers of operating this equipment. -
Page 21: Heated And Refrigerated Combo Counter Operation
Section 4 Operation Heated and Refrigerated Combo Counter well during preheating or when empty. Operation • Always place covers on pans when not serving to prevent food from drying out. OPERATION DANGER DANGER Steam can cause serious burns. Always use some type When operated at the highest temperature setting, the of protective covering on your hands and arms when top of the unit will become very hot. -
Page 22: Maintenance
Section 5 Maintenance Warning DANGER Never use a high-pressure water jet for cleaning or hose It is the responsibility of the equipment owner to down or flood interior or exterior of units with water. perform a personal protective equipment hazard assessment to ensure adequate protection during This will void the warranty. -
Page 23: Interior Cleaning
Section 5 Maintenance INTERIOR CLEANING Counter Protector Glass & Hardware Cleaning Routine cleaning can be done with soap and water. Extreme Caution stains or grease should be cleaned with a nonabrasive DO NOT fill dry wells with water during operation or cleaner and plastic scrub pad. - Page 24 Section 6 Diagrams & Parts FLEXIWELL DIAGRAMS Power Supply Wiring SINGLE POINT ELECTRICAL CONNECTION INFORMATION All units must be hard wired to a single point connection at installation. Model 12”x20” V/Hz/Ph Amps (max) Ship Weight Pan Capacity N8618-FWP 1 well 120/208-240/60/1 N8633-FWP 2 well...
- Page 25 Section 6 Diagrams FLEXIWELL DIAGRAMS Single Well Wiring Part Number: 9291544-GEN2 12/24...
- Page 26 Diagrams Section 6 FLEXIWELL DIAGRAMS Multi-Well Wiring 2 Well Self Contained Assembly *above is an example of a two well unit. Multi well units will have the same repeating wiring schematic per number of wells. Part Number: 9291544-GEN2 12/24...
- Page 27 Section 6 Diagrams 4 Well Self Contained Assembly 6 Well Self Contained Assembly For the most up-to-date parts list, visit https://www.Delfield.com/Service/Parts-Lists Part Number: 9291544-GEN2 12/24...
- Page 28 DELFIELD 980 SOUTH ISABELLA ROAD, MOUNT PLEASANT, MI 48858 800-733-8821 WWW.DELFIELD.COM ©2019 Welbilt Inc. except where explicitly stated otherwise. All rights reserved. Part Number: 9291544-GEN2 12/24...
