- Page 1 18600 Series & CTP-NB Original Instructions Installation, Operation and Maintenance Manual This manual is updated as new information and models are released. Visit our website for the latest manual. Part Number: 9291455 06/16...
- Page 2 18600 and CTP-NB Series Service and Installation Manual Important Warning And Safety Information WARNING WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing Maintenance On The Equipment. WARNING WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage, Injury Or Death. WARNING WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The Vicinity Of This Or Any Other...
-
Page 3: Table Of Contents
18600 and CTP-NB Series Service and Installation Manual Contents Receiving & Inspecting Equipment ........... 3 Serial Number Information ............4 Warranty Information ..............4 Regulatory Certifications ............4 Domestic Specifications ............. 5 Domestic Refrigerant Charges ........... 6 Export Specifications ..............7 Installation ................. -
Page 4: Serial Number Information
18600 and CTP-NB Series Service and Installation Manual Serial Number Information The serial number on 18600 Series units is located on the electrical specifications tag affixed inside the compressor section next to the pressure control. The serial number on CTP-NB Series units is located on the front of the unit. -
Page 5: Domestic Specifications
18600 and CTP-NB Series Service and Installation Manual Domestic Specifications 18600PTBM Pizza tables with raised rail 1/3 Pan Size # Of Shelf Max Shelf Area Volume BTU Load BTU Sys. Cap. Voltz/Hertz/ NEMA Ship Weight FT 2 FT 3 Model Capacity # Of Doors Shelves... -
Page 6: Domestic Refrigerant Charges
18600 and CTP-NB Series Service and Installation Manual Domestic Refrigerant Charges 18648-PTBM & PTL 16 oz. (454g) 18699-BUCM & BSTM 24 oz. (680g) 18660-PTBM 24 oz. (680g) 186114-BUCM & BSTM 24 oz. (680g) 18672-PTBM & PTL 32 oz. (907g) 18648PDL Rail 16 oz. -
Page 7: Export Specifications
18600 and CTP-NB Series Service and Installation Manual Export Specifications 18600PTB-E Pizza tables with raised rail R404A Custom 1/3 Pan Size # Of Shelf Max Shelf Storage BTU Load BTU Sys. Cap. Charge Voltz/Hertz/ Ship Weight Area CM 2 Model Capacity # Of Doors Shelves... -
Page 8: Installation
18600 and CTP-NB Series Service and Installation Manual Installation Location Plumbing These units are intended for indoor use only. Be sure the location Self-contained models are standard with a condensate evaporator. If, chosen has a floor strong enough to support the total weight of the for some reason, a unit does not have a condensate evaporator, or the cabinet and contents. -
Page 9: 18600Ptb & Ptl Series
After turning the ON/OFF switch to ON, the units compressor will Refrigerator Evaporator Fan Operation begin operating. Delfield refrigerated bases are designed to maintain When the refrigerator is initially powered up or immediately following an operational temperature of 36°F to 40°F (2°C to 4°C). -
Page 10: 18600Pdl Series
18600 and CTP-NB Series Service and Installation Manual Operation: 18600PDL Series Product should be loaded into the unit with care. All R404A models have a high pressure limiting device. Under Failure to heed these recommendations could result in severe overloading conditions, or in the event of a condenser fan CAUTION damage to the interior of the cabinet or the blower coil. -
Page 11: Pressure Control Settings
Please contact KitchenCare 1 (844) 724-2273 or your local service agent. Delfield is not responsible for charges incurred while having the pressure control adjusted. Temperature Control Settings... -
Page 12: Care And Cleaning
18600 and CTP-NB Series Service and Installation Manual Care & Cleaning Never hose down interior or exterior of units with water. Reassembly This will void the warranty. Wipe interior dry of any water Push the drawer tracks into the drawer cage. The blue safety clip accumulation. - Page 13 18600 and CTP-NB Series Service and Installation Manual Care & Cleaning, continued Cleaning the Condenser Coil Units with pans should be operated with pans in place. Operating the unit without all pans in place will lower In order to maintain proper refrigeration performance, the efficiency and may damage the unit.
-
Page 14: 18600Ptb Cutting Board Installation
18600 and CTP-NB Series Service and Installation Manual 18600PTB Cutting Board Installation 1. Orient each bracket with a bend at the back and the 3. Mark the bracket hole locations. other to the outside. 4. Drill each 0.125” hole. 5. Secure each bracket to the Pizza Table with four 0.125” pop rivets. -
Page 15: Notes
18600 and CTP-NB Series Service and Installation Manual Notes... - Page 16 DELFIELD 980 SOUTH ISABELLA ROAD, MOUNT PLEASANT, MI 48858 800-733-8821 WWW.DELFIELD.COM Every new piece of Manitowoc Foodservice equipment comes with KitchenCare™ and you choose the level of service that meets your operational needs from one restaurant to multiple locations. StarCare – Warranty & lifetime service, certified OEM parts, global parts inventory, performance audited ExtraCare —...
