Lumens VC-TR61 User Manual

Auto tracking camera
Hide thumbs Also See for VC-TR61:
Table of Contents

Advertisement

Quick Links

Download this manual
VC-TR61
Auto Tracking Camera
User Manual - English
Version VYW100Q
To download the latest version of Quick Start Guide,
multilingual user manual, software, or driver, etc.,
please visit Lumens
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC-TR61 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens VC-TR61

Summary of Contents for Lumens VC-TR61

  • Page 1 VC-TR61 Auto Tracking Camera User Manual - English Version VYW100Q To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Contents Chapter 1 Packing List ......................... 2 Chapter 2 Product Appearance ....................3 2.1 I/O interface ........................ 3 2.2 LED Indicator ....................... 4 2.3 Tally Lamp ........................4 Chapter 3 Installation Instructions ..................5 3.1 Scenario ........................5 3.2 Instruction for installation ..................5 3.3 Connection ........................

  • Page 3: Chapter 1 Packing List

    Chapter 1 Packing List USB 3.0 Cable-2m Power Adapter Power Cord Remote Control (Type B - Type A) Appearance may vary depending on county/ region M3 Screws Metal Plate A Metal Plate B 3PIN-2PIN Connector Silver x8/ Black x2 (For Japan only)

  • Page 4: Chapter 2 Product Appearance

    Chapter 2 Product Appearance I/O interface Front Back 10 11 項目 功能說明 Main camera lens PTZ camera lens Panoramic lens Panoramic camera lens LED indicators Displaying the status of the camera, please refer to LED Indicator Tally Lamp Displaying the Tally Lamp status of the camera Lock Safety lock slot RS232 IN...

  • Page 5: Led Indicator

    LED Indicator Status Power Standby Power not connected No light No light Startup in progress Green Orange (initialization) Power on (In use) Green No light Standby No light Orange Tracking / Framing mode Green Flickering Green Flickering Privacy mode Orange No light Tally Lamp The Tally lamp function may be enabled through the RS232 command.

  • Page 6: Chapter 3 Installation Instructions

    Chapter 3 Installation Instructions 3.1 Scenario VC-TR61 supported tracking distance: 2-18m 為保持最佳追蹤效果, 請避免背景中的海報/顯示器 等物品出現人像圖案 3.2 Instruction for installation Installation and connection of HD camera requires special skills. To install by yourself, please follow necessary steps, ensure steady and tight installation of the device, and pay attention to your safety to avoid any accident.
  • Page 7  Before installation, please confirm the orientation of the machine relative to the object to be captured Camera  It is recommended that the machine should 1.5m↑ be set at a distance of more than 1.5 meter away from the object to be captured. Please adjust for a best distance according to the magnification of the lens ...
  • Page 8 2. Lock the metal plate B on ceiling mounted hanger ※Caution：  Please use the hanger that has obtained UL security approval  Please reserve the hole for the connecting wires of the camera 3. Combine the metal plate A and the metal plate B (1) Push the metal plate A up to the ceiling and then to the right to latch the metal plate B...

  • Page 9: Connection

    3.3 Connection 3.3.1 Connecting devices Ethernet port supports PoE+ (IEEE802.3at) 3.3.2 RS-232 Pin Definition Daisy Chain supports 7 cameras connected Pin No.

  • Page 10: Chapter 4 Remote Control And Setting Menu

    Rotate the image (OFF / Mirror / Flip / Mirror Rotate) Choose Camera ID 1 ~ 3 Camera select Turn on/off back light compensation Back Light Clear the Pan/Tilt setting Pan/Tilt Reset Enable/ Disable Auto framing.  On/Off: Auto Framing  Trigger: (VC-TR61 not supported.)

  • Page 11: Setting Menu

    Setting Menu Press [MENU] on the remote control to call the on-screen menu. Default is indicated in bold. Layer 1 Layer 2 Layer 3 Description Full Auto/ Shutter Pri/ Iris Mode Exposure mode setting Pri/ Manual/ White Board Turn on/off Exposure Exposure Comp On/ Off Compensation.
  • Page 12 Layer 1 Layer 2 Layer 3 Description Users can customize the selected Image Mode Default/ Custom image mode Adjustable when Image Mode set Gamma 0~C~3 to Custom Adjustable when Image Mode set Brightness 0~C~25 to Custom Adjustable when Image Mode set Contrast 0~C~25 to Custom...
  • Page 13 Layer 1 Layer 2 Layer 3 Description Changes the focusing zone to the selected mode.  Central area: focusing will be AF Frame Center Area/ All Area performed based on the center.  Full Frame: focusing will be calculated based on the full screen The focus mode during lens zooming Zoom tracking...
  • Page 14 Layer 1 Layer 2 Layer 3 Description On/off the infrared reception When it’s Off, the remote control IR Receive On/ Off will not be able to control the camera. Disconnect and then plug the power cable to re-activate. Match the remote control's IR IR Select 1/ 2/ 3 setting with the camera's IR...
  • Page 15 Layer 1 Layer 2 Layer 3 Description When the camera is turned off via the remote control or software, Privacy Mode On/ Off the lens will automatically turn to the bottom right to ensure the user’s privacy Protocol VISCA Supports VISCA protocol Transmission speed of the control Baud Rate 9600/38400...

  • Page 16: Chapter 5 Network Setting And Web Interface

    Chapter 5 Network setting and Web interface 5.1 Connecting Camera to Network 5.1.1 Connection Two common connection methods are shown below 1. Connect via switch or router Cat5e cable Cat5e cable Camera Ethernet Switch 2. Connect directly via an Ethernet cable, and the computer's IP address must be modified to match the network segment used by the camera.
  • Page 17 Lumens IP Camera  Account: admin  Password: 9999 5.1.3 Use a RTSP Player to View Images Free software can be used for RTSP connection, such as VLC, Quick Time and PotPlayer. RTSP connection address formats are as follows:  RTSP Stream 1 =>rtsp://camera IP:8554/hevc...

  • Page 18: Web Interface Functions

    Web interface functions 5.2.1 Login Item Function Descriptions User name Enter user login account (default: admin) Enter user password (default: 9999) For the first-time login, please refer to 5.2.11 System-User Password change the default password Save user name and password. When you log in next time, there is Remember Me no need to re-enter them.
  • Page 19 5.2.2 Live View Item Function Descriptions Camera ID/ Display camera ID/ Location Location Please refer to 5.2.7 System-Device Preview screen Display the current view of the camera Preset setting Select the number first and then select Store or Load Pan/Tilt Adjust the Pan/Tilt position of the camera Zoom Zoom In/Zoom Out...
  • Page 20 5.2.3 Live View - Camera Setting Item Descriptions Mode: Exposure mode (Full Auto/ Shutter Pri/ Iris Pri/ Manual/  White Board) WDR: Set the level to change the dynamic range of the picture.  Exposure Comp. Level: Select exposure compensation level ...
  • Page 21 Mirror Mirror: Set image mirroring  Flip: Set the mode at which the image is turned  Pan/Tilt Limit: Enable to set the pan/tilt limit  Pan/Tilt Flip: Set On and the Pan/Tilt directions will be reversed.  Preset Speed: Set the rotation speed of the cradle head when ...
  • Page 22 5.2.4 Tracking Item Descriptions Camera ID/Location Display camera ID/ location. Please refer to 5.2.7 System-Device PTZ preview Display the current view of the main lens. Panoramic preview Display the current view of the panoramic lens Lens Tilt Direction Set the tilt direction for the panoramic lens People Count Display the calculated number of people in the screen.
  • Page 23 Target Lost Time Set a delay to take action after a tracking target is lost Target Lost Action Set the action after a tracking target is lost After a person enters the area for 3 seconds, tracking/ framing will be triggered. ...
  • Page 24 outside the zone, everywhere tracking will be active. Head Position: Set the head position of the person on the screen  Block Area: Click into the Edit mode, frame by holding the left  mouse button and set the blocked area Block Area: Click the left mouse button to draw a frame on the ...
  • Page 25 5.2.5 Audio Item Descriptions Select to enable Audio function Audio In: Set Line In  Audio Enable Encode type: AAC  Encode sample rate: 48KHz(AAC)  Volume: Adjust Audio Volume  Audio Delay Check to set the audio delay time (10 ~ -500 ms) Apply/ Cancel Apply/ Cancel Audio Settings...
  • Page 26 5.2.6 Stream Item Descriptions Stream Supporting 2 streams and panoramic view stream outputs Stream settings Please refer to 5.2.6.1 Stream Settings. Select to enable RTSP Enable/ Disable Multicast  Multicast is recommended when the stream is being watched by more than 4 viewers. Enable/Disable Password Authentication ...

  • Page 27: Streaming Settings

    maximum value of 65535 The following ports are used by the camera. Setting the ports may result in connection issues. 8554, 8556, 8557, 8080, 9090, 1935 Latency can be set between 20-8000 microseconds. (Default is 120  microseconds 5.2.6.1 Streaming settings Function Stream 1 Stream 2...

  • Page 28: System - Output

    5.2.8 System - Output Item Descriptions Set the resolution of the camera Resolution After changing resolution, the camera will restart. The browser will need to be refreshed. HDMI Format Supporting YUV422/ RGB After the privacy mode is enabled, when the camera is turned off via the Privacy Mode remote control or software, the lens will automatically turn to the bottom (UVC)
  • Page 29 5.2.9 System - Network Item Descriptions DHCP Camera network settings. Configurable when DHCP is set to Off. HTTP Port Set HTTP port. The default Port value is 80 HTTPS Port Set HTTPS port. The default Port value is 81 Apply/ Cancel Apply/ Cancel Setting 5.2.10 System - Date &...
  • Page 30 5.2.11 System - User Description Add/Modify/Delete user account  Supports 4 - 32 characters for user name and password  Use uppercase, lowercase letters or numbers. Special symbols cannot be used  Account permissions: User Type Admin Operator Viewer Live View Settings Account management Performing a factory reset will clear all user data.

  • Page 31: System Control

    5.2.12 System - Control Item Function Descriptions Protocol Supports VISCA protocol Baud Rate Select the transmission speed of the control signal VISCA address The camera ID address 0 ~ 7 can be assigned. When enabled, LED on the front panel will flash green while Tracking LED status the camera is tracking.

  • Page 32: Maintenance

    Save setup parameters as a Profile, and users can download and Configuration upload camera setup parameters. If the camera operates abnormally, please export event log and Event Log provide it to Lumens for investigation. 5.2.14 About Description Display the firmware version, serial number, and other related information of the camera...

  • Page 33: Chapter 6 Troubleshooting

    Chapter 6 Troubleshooting This chapter describes problems you may encounter while using VC-TR61. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occur, please contact your local distributor or Lumens.

  • Page 34: Chapter 7 Addendum

    Addendum Chapter 7 7.2 Camera Size  Length x Width x Height: 174 x 186.65x 197.11mm  Weight: 2.2Kg 7.3 Dimensions of the base The camera can be mounted on a 1/4”-20 UNC PTZ tripod head by using the lock holes on the bottom.
  • Page 35 (1)Metal plate A - camera side Metal plate A locking screw Metal plate A - Camera side...
  • Page 36 (2)Metal plate B - ceiling side Metal plate B locking bolt Metal plate B locking screw 3 threaded hole M3 threaded hole M3 threaded hole Metal plate B - ceiling side...

  • Page 37: Chapter 8 Safety Instructions

    Safety Instructions Chapter 8 Always follow these safety instructions when setting up and using PTZ Video Camera: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on an uneven surface. 1.3 Ensure the power plug is free of dust prior to usage.
  • Page 38  IC Warning This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe A prescrites dans la norme sur le material brouilleur: “Appareils Numeriques,”...

  • Page 39: Copyright Information

    Lumens is a trademark registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
