VC-A51S Firmware(FW) Upgrade
Please contact Lumens FAE Department through e-mail to get the proper FW and AP before
upgrading.
1. Device and Tool Preparation
1.1 Please prepare following devices and tools before FW upgrade.
VC Model
RS232 cable
(9Pin D-Sub Female to 8Pin Mini Din Male)
VC FW Upgrade Instruction
All manuals and user guides at all-guides.com
Monitor
PC with a RS232 port or Laptop
or
RS232-USB cable
(if connect with a laptop)
Power adapter and power cord
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lumens VC-A51S
Summary of Contents for Lumens VC-A51S
- Page 1 All manuals and user guides at all-guides.com VC-A51S Firmware(FW) Upgrade Please contact Lumens FAE Department through e-mail to get the proper FW and AP before upgrading. 1. Device and Tool Preparation 1.1 Please prepare following devices and tools before FW upgrade.
- Page 2 All manuals and user guides at all-guides.com 2. Connections for FW upgrade **Note: OS Support: Windows XP, Windows 7, Windows 8, Windows 10 The VC FW cannot be upgraded through MAC OS. 2.1 Connect the VC camera(RS232 In) with a PC RS232 cable 2.2 Connect the VC camera(RS232 In) with a laptop Need 2 cables: RS232 cable and RS232-USB cable...
- Page 3 All manuals and user guides at all-guides.com 3. Control FW 3.1 Please refer to 2. Connections for FW upgrade 3.2 Launch the [VC-A51S_Download_AP]. 3.3 Browse and select proper FW file. - Check the box in the front for the FW you would like to update. - Click [Browse] and select the FW file VC FW Upgrade Instruction...
- Page 4 All manuals and user guides at all-guides.com 3.4 Select proper [Com Port] and set the [Baud Rate] as [9600], and then press [DownLoad AP] to start. 3.5 FW start updating. (around 1.5min taken) The Percentage will be increased when it’s running. 3.6 When firmware upgrade finished, please unplug and reconnect the power cord to restart the camera.
- Page 5 All manuals and user guides at all-guides.com 4. Check FW version on OSD 9.1 Plug in the power cord and connect the VC camera with a Monitor. 9.2 Power on the unit and press [Menu] button on the remote control 9.3 Select [Status] 9.4 Press [ ▼...
