Lumens VS-LC102Bundle Manual

1 Preparation before use
▼ Very Important
 Please activate your warranty:
 To download the updated software, multilingual manuals, and Quick Start Guide, please
visit Lumens™ web site at:
 To ensure successful installation, please be sure to follow each of the following steps
1.1 Equipment requirements
VS-LC101 / VS-LC102 x 1

IP PTZ camera x 1 ~ 3, e.g. VC-A20P x 3

Computer (or Laptop) x 1

Router x 1, Giga router recommended

Display x 1

Network cables x 3 ~ 5

HDMI or VGA cable x 2

External hard drive: USB or eSATA external hard drive x 1 (VS-LC102 has a built-in hard

drive, and thus it is optional)
Amplifier x 1

Audio mixer x 1

Speaker set x 1

Mic x 1

[Remark] The number of connected devices can be increased or adjusted based on
environment requirements.
http://www.MyLumens.com/reg
http://www.MyLumens.com/support.php
