Features

•

AVR

8-bit RISC Microcontroller with 83 ns Instruction Cycle Time

•

USB Hub with One Attached and Four External Ports

•

USB Function with Two Programmable Endpoints

•

External Program Memory, 512-byte Data SRAM

•

32 x 8 General Purpose Working Registers

•

32 Programmable I/O Port Pins

•

Programmable Serial UART

•

Master/Slave SPI Serial Interface

•

One 8-bit Timer/Counter with Separate Pre-scaler

•

One 16-bit Timer/Counter with Separate Pre-scaler and Two PWMs

•

External and Internal Interrupt Sources

•

Programmable Watchdog Timer

•

6 MHz Oscillator with On-chip PLL

•

5V Operation with On-chip 3.3V Power Supply

•

100-lead LQFP Package

Description

The Atmel AT43USB320A is an 8-bit microcontroller based on the AVR RISC architec-

ture. By executing powerful instructions in a single clock cycle, the AT43USB320A

achieves throughputs approaching 12 MIPS. The AVR core combines a rich instruc-

tion set with 32 general-purpose working registers. All 32 registers are directly

connected to the ALU allowing two independent registers to be accessed in one single

instruction executed in one clock cycle. The resulting architecture is more code effi-

cient while achieving throughputs up to ten times faster than conventional CISC

microcontrollers.

The AT43USB320A features an on-chip 512-byte of data memory. It is supported by a

standard set of peripherals such as timer/counter modules, watchdog timer and inter-

n al an d ext er n al int er r u p t s ou r ce s. Th e m ajo r p e r iph e ra l in clu d ed in th e

AT43USB320A is the USB Hub with an embedded function for use in peripherals such

as monitor with remote control as shown in Figure 1.

Note:

There are two versions of the AT43USB320A. They are indicated by the internal part

numbers 55618D and 55618E. The only difference between the two versions is in the

polarity of the SUSPEND pin. The 55618D SUSPEND pin is active low, while the

55618E SUSPEND pin is active high.

Full-speed USB

Microcontroller

with an

Embedded Hub

AT43USB320A

Rev. 1443D–USB–12/03
