Core Stand Swivel Plate Add-on
Assembly Instructions
Fixed Mounting
VHB PAD
Swivel Mounting
©Compulocks Brands Inc. All Rights Reserved
SKU: SWBB
PRIOR TO INSTALL OF
VHB PAD CLEAN BOTH
MOUNTING SURFACES USING
ALCOHOL PADS PROVIDED
OR
SWIVEL LOCKNUT
PLASTIC WASHER
SWIVEL DISK
FLAT HEAD
MOUNTING SCREWS
(PROVIDED)
FIXING DISK
www.compulocks.com | online@maclocks.com | +1 800-948-0344
VHB PAD
CLOSE THE
PLASTIC CAP
PRIOR TO INSTALL OF
VHB PAD CLEAN BOTH
MOUNTING SURFACES USING
ALCOHOL PADS PROVIDED
Sheet 1 of 2
