Mounting the limit switches ......................13 Troubleshooting ..........................13 Operation via the hand control not possible ................ 13 Operation via the hand control only partially possible ............14 Spare parts............................. 14 Electrical components ......................14 Other components ........................ 15 info@iskomed.de | +49 921 150845-0...
Page 3
List of figures Figure 1: Dimensional sketch of the movement area of the Rotadorm Care ......... 4 Figure 2: Customer hand control ......................5 Figure 3: Service hand control ......................... 5 Figure 4: Key description of customer hand control ................6 Figure 5: Key description of service hand control ...................
1 Dimensional sketch of the movement space For the rotating function of the lying surface, it is essential to keep the following space free for movement outside the nursing bed. Figure 1: Dimensional sketch of the movement area of the Rotadorm Care Type SI-011-1...
2 Description of hand controls For the Rotadorm Care there is a customer hand control for daily use (Figure 2) and a service hand control V1 (Figure 3) for initializing the control box and motors and for programming the stand-up parameters.
For initialization, simultaneously press the first row of keys (neck rest - up and down; H2 + H3) until a long signal tone sounds. During this process, the motors may search for their end position. info@iskomed.de | +49 921 150845-0...
To reactivate the factory settings, press the third row of keys (knee break - up and down, H14 + H15) simultaneously (really simultaneously) and together until a short signal tone sounds (after approx. 5 seconds). Figure 5: Key description of service hand control www.iskomed.de...
The fifth row is pressed to the right until the signal goes out after 5 seconds. The customer-specific values now set for the stand-up position 1 are now fixed and can be controlled by the customer's hand control. info@iskomed.de | +49 921 150845-0...
Press H31 + H16 simultaneously. This version is indicated by a short beep (100ms) after plugging into the mains. 2 SLS for use with side grid monitoring Actuate H31 + H18 simultaneously. This version is indicated by 2 beeps (1s) after plugging into the mains. Figure 9: Pressed pushbutton/limit switch through lowered side rail www.iskomed.de...
3.5 Mounting the bed extensions The Rotadorm Care can be used in lengths of 200 cm, 210 cm and 220 cm. For this purpose, in addition to wooden side rails of different lengths, it is also necessary to ensure correct assembly of the footrest extension.
In addition, the 220 cm version has an extension attached to the headboard. This is to be attached centrally to the headboard end (cf. Figure 13). Figure 13: Assembly of the head traverse (220 cm lying surface length) www.iskomed.de...
4 Changing the direction of rotation With the Rotadorm Care, the direction of rotation can be changed from left to right or vice versa by a few simple assembly steps. To do this, please proceed as follows. Figure 14 shows a Rotadorm Care with the direction of rotation on the right. This is now to be changed to the left-hand direction of rotation (see Figure 15).
5 Mounting the limit switches If the Rotadorm Care is delivered with a special mattress of height 14 cm (article number: SI-500-3, SI-500-4, SI-500-5), the side rails must not be used as protection against the patient falling out. The side rails are supplied, but must not be used. In this case, the side limit switches are mounted below the lying surface, as they are not used.
Matratzenhalter mit Befestigungsteilen Beinteil matress holder leg part left 011.80.501 links Matratzenhalter mit Befestigungsteilen Beinteil matress holder leg part right 011.80.502 rechts Matratzenband - Bügel links matress belt - left handle 011.80.723 Matratzenband - Bügel rechts matress belt - right handle 011.80.724 www.iskomed.de...
