Haworth HAT elements Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE
HAT elements
Installation guide
ECO No:
Page: 1 OF 45
Part number:
Rev:

Advertisement

loading
Need help?

Need help?

Do you have a question about the HAT elements and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Haworth HAT elements

Summary of Contents for Haworth HAT elements

  • Page 1 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE HAT elements Installation guide ECO No: Page: 1 OF 45 Part number: Rev:...

  • Page 2: Table Of Contents

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Contents Page • 1. Introduction……………..……………………………………………….3 • 2. Important notice: Resetting the base…………………………………4 • 3. Freestanding…….………………………………………………………5 • 4. Single bench..………………………………………………………….13 • 4.1 Single bench frame……………………………………………….13 • 4.2 Single bench leg connector……………………………………...14 • 4.3 Single bench cable trunk…………………………………………16 •...

  • Page 3: Introduction

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1. Introduction The following installation guide assumes some knowledge of the installation of HAT elements. ECO No: Page: 3 OF 45 Part number: Rev:...

  • Page 4: Important Notice: Resetting The Base

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE IMPORTANT NOTICE 2. Resetting the base 1. For the first time use or the desk is unbalanced, or the LED displays the wrong height data, it needs to be reset. 2. Press and hold the “UP” and “DOWN” buttons for 5 seconds, LED displays “RST”...

  • Page 5: Freestanding

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3. Freestanding 3.1 Fixed Square or Round Leg HAT Step 1: Fix foot plate to leg with 4 PCS M10X30 screws and spring washer, same way to install another leg Step 2: Fix beam to leg with 4 PCS M6X10 screws , same way to install another leg...
  • Page 6 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Fix side bracket to leg with 2 PCS M6X10 screws , same way to install another side bracket. Step 4: Pull beam at normal width, then fixed beam by 8 PCS M6X10 set screws, W1 will recess 30mm per worktop’s width,...
  • Page 7 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 5: Put on accent plate , same way to put another one Step 6: Put worktop on frame, and make sure the both sides distances between worktop edge and frame edge are the same, then use self screw to fix frame to worktop.
  • Page 8 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.2 Hand crank Square Leg HAT Step 1: Hand crank leg install method is same as fixed leg except below 2 points. 1. Hand crank leg is 2 stages and fixed leg is 1 stage...
  • Page 9 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.3 Motorized Square or Round leg HAT Step 1: The install method is same as fixed leg except below 2 points. 1. Motorized leg is 3 stages and fixed leg only 1 stage 2. Slide the control box into slot on beam Tips: When adjusting the height of workstation, please make sure the control box installed as above picture, or the frame can’t work properly.
  • Page 10 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.4 Motorized Rectangular leg HAT Step 1: Fix foot plate on leg with M6*20 screw and spring washer. Same way to install another leg Step 2: Fix beam at normal length. For example, if worktop is 1600mm, the beam length is 1575mm Step 3: Fix beam on leg with M6*12 screws.
  • Page 11 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Measure W1 and W2,make sure difference not over than 2 mm, then fix tight all the screws. Step 4: Install side bracket with M6*12 screws ECO No: Page: 11 OF 45 Part number:...
  • Page 12 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 5: Put on accent plate , same way to put another one Step 6: Put worktop on frame, and make sure the both sides distances between worktop edge and frame edge are same, then use self screw to fix frame to worktop...

  • Page 13: Single Bench

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4. Single bench 4.1 Single bench frame Basically single bench is similar to freestanding, except that single bench has welding bracket on leg, while freestanding don’t have it Single bench HAT frame Freestanding HAT frame...

  • Page 14: Single Bench Leg Connector

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.2 Single bench leg connector Step 1 Put leg connector to welding bracket on HAT leg. Step 2 Fix leg connector and welding bracket with 2 PCS M8X55 screws . ECO No: Page: 14 OF 45...
  • Page 15 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Image after installation, use same method to install another side. For round leg connector, it will have a round cutout to make the connection looks better, see compared image below. Square leg connector Round leg connector...

  • Page 16: Single Bench Cable Trunk

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3 Single bench cable trunk Step 1 Put cable trunk at correct position to make holes align with leg connector’s holes ,the use M6X10 screw to fix one side Step 2 Same way to install in another side...

  • Page 17: Single Bench Hung Screen

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.4.1 Single bench hung screen(Frameless) Step 1: Fix hung screen bracket to leg connector by 4 PCS M6X16 screws, use the same way to fix another side Step 2: Fix hung screen bracket to hung screen’s pre-drill holes with 4 PCS...
  • Page 18 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.4.2 Single bench hung screen(Framed) Step 1: Fix hung screen bracket to leg connector by 4 PCS M6X10 screws, use the same way to fix another side Step 2: Slide framed hung screen into hung screen bracket’s slot Step 3: Fix hung screen bracket to hung screen’s pre-drill holes with 4 PCS...

  • Page 19: Single Bench Ganger

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.5 Single bench ganger Step 1: Fix single side floor feed top cover on 2 closed leg connector with M6X12 screws Step 2: Fix single side ganger on 2 closed leg connector with M6X12 screws...

  • Page 20: Single Bench Floor Feed

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.6 Single bench floor feed Step 1: Tight the glide to end of floor feed frame Step 2: Fix the floor feed frame with floor feed top cover by M4X6 self screws Step 3: Hung the floor feed cover on floor feed frame...

  • Page 21: Single Bench Jumper Cover

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.7 Single bench jumper cover Step 1: Hung the jumper cover on cable trunk then use click(black parts) to insert the holes of cable trunk, use same way to install another side ECO No:...

  • Page 22: Double Bench

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5. Double bench 5.1 Double bench leg connector Step 1 The install way is similar to single leg connector. The only difference is double leg connector should fix double sides legs. Use 4 PCS M8X55 screws, same method to install other 2 legs.
  • Page 23 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE For screen For trunk For screen and trunk For round leg connector cover ,will have a round cutout to make the connection looks better, see compared image below. Square leg connector Round leg connector...

  • Page 24: Double Bench Cable Trunk

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.2 Double bench cable trunk 5.2.1 For normal Step 1 Put the cable trunk at middle of leg connector and fixed by M6X10 screw Step 2 Same way to install another side Step 3 Put on cable trunk cover...
  • Page 25 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.2.2 For heavy duty Step 1 Put the cable trunk align with leg connector’s screw holes and fixed by M6X10 screw Step 2 Same way to install another side Step 3 Put on cable trunk cover...

  • Page 26: Double Bench Hung Screen

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.3.1 Double bench hung screen (frameless) Step 1: Fix desk screen bracket to leg connector as below step with M6*12 screws Step 2: Fix desk screen bracket with desk screen(have pre-nuts) with M6X16 screws, only fix outer 2 holes and leave inner 2 holes open, use same way to...
  • Page 27 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Put 2 magnetics at back of screen bracket cover Step 4: Put the bracket cover on the bracket, use the same way to install other cover ECO No: Page: 27 OF 45...
  • Page 28 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.3.2 Double bench hung screen (framed) Basically the installation is same as frameless screen. The only different is there is a spacer for framed screen to make sure screen bracket have a flat surface to be fixed.

  • Page 29: Double Bench Ganger

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.4 Double bench ganger Step 1: Fix double sides floor feed top cover on 2 closed leg connector with M6X12 screws Step 2: Fix double sides ganger on 2 closed leg connector with M6X12 screws...

  • Page 30: Double Bench Floor Feed

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.5 Double bench floor feed 5.5.1 For normal Step 1: Tight the glide to end of floor feed frame Step 2: Fix the floor feed frame with ganger with M6X12 screws Step 3: Hung the floor feed cover on floor feed frame...
  • Page 31 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.5.2 For heavy duty Step 1: Tight the glide to end of floor feed frame (need prepare 2 PCS) Step 2: Fix the floor feed frame with ganger with M6X12 screws Step 3: Hung the floor feed cover on floor feed frame...

  • Page 32: Double Bench Jumper

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5.6 Double bench jumper cover Step 1: Hung the jumper cover on cable trunk then insert the click(black parts) to the holes of cable trunk, use same way to install another side There are 3 different position for jump cover as below 1.

  • Page 33: Umbilical Cord

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 6. Umbilical cord 6.1 Trunk to desk Step 1: Fix top bracket with umbilical cord by self screw , then use the hook on bracket hung the rope on umbilical cord Step 2: Fix bottom bracket on cable trunk , by 2 PCS M4X6 screws, then use...
  • Page 34 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 6.2 Floor to desk Step 1: Fix top bracket with worktop by self screw, then use the hook on bracket hung the rope on umbilical cord ECO No: Page: 34 OF 45 Part number:...

  • Page 35: Hat

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7. 120D HAT 7.1 120D freestanding 120D freestanding installation is basically same as bench freestanding, The difference is 120D frame have 3 middle leg and 350mm middle foot plate , the beam also have handed, here only show the installation of middle leg and beam Step 1: Fix middle foot plate with leg with 4 PCS M10X30 screws and spring washer, make sure longer parts toward outside .
  • Page 36 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 2: Fix left hand beam to middle leg with M6*12 screws, same way to fix right hand beam ECO No: Page: 36 OF 45 Part number: Rev:...

  • Page 37: 120D Single Bench

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.2 120D Single bench 120D single bench installation is basically same as 120D freestanding except it has 3 welding brackets on legs 120D single bench leg connector includes left hand ,right hand (common use...
  • Page 38 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 2 Fix leg connector to welding bracket with 6 PCS of M8*55 screws. ECO No: Page: 38 OF 45 Part number: Rev:...

  • Page 39: 120D Back To Back

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.3 120D back to back Compared with 120D single bench, 120D back to back has no foot plate and no middle welding bracket as below 120D back to back leg connector common use bench back to back leg connector, the only difference is 3 PCS instead of 2 PCS, use 12 PCS M8*55 screws fix.

  • Page 40: 120D Floor Feed

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.4 120D floor feed Step 1: Fix 3 glides with bottom plate Step 2: Fix 3 columns with M6*16 screws ECO No: Page: 40 OF 45 Part number: Rev:...
  • Page 41 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Fix top plate on 3 columns Step 4: Put on top cover with M6*16 screws Step 5: Fix 12 PCS screws on Step 6: Hook side cover to screws columns in step 5...

  • Page 42: Beam Cover

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 8. Beam cover 8.1 Beam cover for bench Step 1: The beam cover is packed by a flat PET board, bend 2 edges to 90 degree by bending line Flat Bended Step 2: Use the beam cover hold HAT beam, then make marks by beam cover’s...
  • Page 43 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Push cutout edges of beam cover into clips slot ECO No: Page: 43 OF 45 Part number: Rev:...
  • Page 44 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 8.2 Beam cover for 120D Step 1: The beam cover for 1200 and 1400 width have an option for 120D HAT frame, which have 2 cutting remarks at end , for left hand beam , need cut right...

  • Page 45: Shift Panel Bracket

    HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 9. SHIFT panel bracket Step 1: Fix SHIFT panel bracket to leg connector with 4 PCS M6*20 screws Same way to install another leg connector Step 2: Slide SHIFT panel to bracket’s slot then fix 2 set screws with panel Same way to install another side.
