Summary of Contents for Autool AST603
- Page 1 AUTOOL AST603 Brake Fluid Bleeder User Manual www.autooltech.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Copyright Information..................2 Copyright......................2 Trademark ....................... 2 Safety Rules ......................3 General safety rules ..................3 Handling ......................3 Electrical safety rules ..................4 Equipment safety rules..................4 Application....................... 4 Personnel protection safety rules..............5 Cautions ......................6 Warning ...................... -
Page 3: Copyright Information
COPYRIGHT INFORMATION Copyright ● All rights reserved by AUTOOL TECH. CO., LTD. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of AUTOOL. -
Page 4: Safety Rules
SAFETY RULES General Always keep this user manual with the machine. safety rules Before using this product, read all the operational instructions in this manual. Failure to follow them may result in electric shock and irritation to skin and eyes. Each user is responsible for installing and using the equipment according to this user manual. -
Page 5: Electrical Safety Rules
Electrical This is a Class I equipment that must only be powered safety rules through a power socket with a protective grounding conductor. This connection must not be interrupted at any point (e.g., through extension cords). Any interrup- tion or disconnection of the protective conductor may result in electric shock. -
Page 6: Personnel Protection Safety Rules
Personnel Replacing the oil used by the equipment can be harmful protection to health; avoid any contact. safety rules Always wear protective eyewear when replacing oil to prevent possible splashes into the eyes. If contact occurs, rinse with running water for several minutes with eyelids open. -
Page 7: Cautions
CAUTIONS Warning Before using the brake fluid bleeder, please pay attention to the following: Improper use may lead to health hazards or property damage! Brake fluid is toxic and may cause severe health damage! Avoid contact with brake fluid. Wear safety goggles to minimize the risk of injury from splash- ing liquids. -
Page 8: Predictable Misapplication
Corrosion-resistant oil hoses are aesthetically pleasing, durable, and easy to move. Product ● Controlled by a microcontroller, the AST603 allows precise features regulation of brake fluid pressure and flow. It has a high degree of automation, enabling single-person operation. This makes it... -
Page 9: Technical Specifications
Technical Power Supply AC 110V/220V specifications 0.5-2.5Bar Working Pressure Maximum Power Maximum Output Flow Rate 1.6L/min 0.7-2.5Bar Output Pressure Filling Hose Length 3.5m Low Oil Protection Supported -10°C~+60°C Operating Temperature Storage Temperature -10°C~+65°C... -
Page 10: Product Structure
PRODUCT STRUCTURE Structure diagram Pressure Gauge Power Cable Work Indicator Light Power Indicator Light Start Button Pressure Balance Hose Filling Hose Suction Hose Pressure Regulation Knob Safety Device Power Switch... -
Page 11: Basic Operating Procedure
BASIC OPERATING PROCEDURE ● First, connect the universal adapter to the quick-connect fitting of the filling hose. The pressure adjustment knob should be turned counterclockwise to the lowest pressure setting. Add new brake fluid to the new oil bottle. Press and hold the start button for 30 seconds until new brake fluid begins to flow from the adapter (The pipeline has been purged). -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS Layout / ● Place the brake fluid bleeder on a flat and stable surface. Workstation During startup and operation, ensure that the vehicle's workstation is located near the brake fluid bleeder. ● When the vehicle is lifted on a lift, make sure that the filling hose is connected to the vehicle without any stress concentra- tions, such as tangling or twisting. -
Page 13: Replacing Brake Fluid
● At this point, the brake fluid bleeder has completed the purging process and is ready for use. Replacing Warning brake fluid Changing brake fluid must strictly adhere to the safety guide- lines and specifications provided. Before starting work, pay attention to the vehicle manufactur- er's instructions regarding the maximum filling pressure and any special operational guidelines. -
Page 14: Maintenance Service
MAINTENANCE SERVICE Our products are made of long-lasting and durable materials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspec- tion work, which ensures that each product has excellent quality and performance. -
Page 15: Warranty
Disclaimer All information, illustrations, and specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice. The physical appearance and color may differ from what is shown in the manual, please refer to the actual product. -
Page 16: Return & Exchange Service
RETURN & EXCHANGE SERVICE ● If you are an AUTOOL user and are not satisfied with the Return & AUTOOL products purchased from the online authorized Exchange shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;... - Page 17 AUTOOL TECHNOLOGY CO.,LTD www.autooltech.com aftersale@autooltech.com +86-755-2330 4822 / +86-400 032 0988 Hangcheng Jinchi Industrial Park, Bao’an, Shenzhen,China Corporate Standard: Q/OR 001-2023...
