This manual is intended for the maintenance and repair of T350 frequency-modulated handheld radio, and can only be used by engineers and professional technicians who are trained by Kirisun. The parameters in this manual may vary with technology improvement, so for updated technical information, please contact Kirisun or its local dealers.
DP680 service manual 1.3 Maintenance Service Paid maintenance service will be provided after the warranty period. Meanwhile, we offer parts to authorized maintenance stations and dealers at preferential prices, except those of discontinued products. The radio and accessory are provided with warranty service. But if one of the following occurs, no free maintenance is offered.
DP680 service manual Name Name Antenna Power/volume knob Side key 1 LED indicator PTT key Accessory interface Side key 2 Microphone Alarm key Screw of earphone cover Speaker Screw of earphone cover LCD screen Down key Up key Belt clip...
DP680 service manual second operational amplifier, and the error voltage that is output will change the transmitting power through the grid bias voltage of the control power amplifier tube (including the drive level and final level). 3.3 RX Circuit The receiver circuit includes RF band pass filter, low-noise amplifier, mixer, IF filter, IF amplifier and IF processor.
DP680 service manual SSI TO OMAP IF input 16.8MHZ Reference frequency Figure 3-4 IF Processor 3.4 Frequency Generation Unit (FGU) U1007 Loop filter Figure 3.5 Frequency Generation Unit Diagram Frequency generation unit (FGU) is composed of VCO and PLL. It is the core module of the TX-RX system.
DP680 service manual varactor of VCO to adjusts and control the output frequency, till the CV becomes constant. Then the PLL will be locked, the stable frequency output by VCO will go to the TX-RX channel before passing through two buffet amplifiers.
DP680 service manual 3.6 Baseband Circuits 3.6.1 Power Supply Circuit GPS_3V3 RTC_1V2 AUDIO AMP VCC_3V3 PMOS 3.6V VBAT VCC_1V8 DCDC VCC_1V2 VBATS MAIN LDO_3V3 BATT ON/OFF SWITCH NAND PWR_CTL PWR_SWITCH_DET Figure 3-7 Power Supply Diagram The radio is powered by MAIN BATT composed of two lithium batteries, with a fully charged voltage of 8.4V and a minimum protection voltage of 6.3V.
DP680 service manual 3.6.2 Audio Processing Circuit AD9864 OMAP-L138 mode tone 模式 Audio CODEC 内部 内部 Amplifier 外部 外部 Figure 3-8 Audio Processing Diagram The audio processing circuit is for audio input and output. This system employs TLV320AIC14 as the audio codec for converting analog and digital signals.
The radio has been set before delivery. However, to meet customers’ requirements, it may be necessary to set such digital functions as operating frequencies, channels, DT/DQT and automatic scan. This can be achieved by the programming software Kirisun CPSp. It is user-friendly and easy to operate, and supports Chinese and English.
DP680 service manual Step 6.In the software interface, modify parameters, select Program → Write Data. In the prompted dialog box, click Write. The radio parameters will be written. 5 Assembly and Disassembly 5.1 Installing and Uninstalling the Battery Installing the Battery Step 1.Press the upper part of the belt clip gently so that it goes up.
DP680 service manual 5.3 Installing and Uninstalling Belt Clip To install the belt clip, align the two screw holes on the belt clip with the two at the back of the radio, and fasten the clip using two 2.5*8 machine screws.
DP680 service manual Step 2. Unweld the soldering joint of the antenna connector using a soldering iron. The main board is separated from the aluminium-alloy holder. Step 3. Unweld the antenna (or take off the antenna connector nut). The main board and the aluminum-alloy holder is separated.
DP680 service manual 5.7 Explosion Diagram Material Code Name 147K05000013 Numeric key (waterproof) Metal dome array of numeric key (improved 147K02000208 waterproofing) 61SM000541 SMD key board 157F15000304 Dual-sided adhesive for key PCB 147K01000357 Upper housing 157F15000115 Speaker dust screen M2*3 cross recessed mushroom-head machine...
Page 20
DP680 service manual 7GCM-S4334-A Sponge mat for LED indicator 7MHP-4169-05C-W0 Plastic PTT key 7MHP-4320-05A-W0 Plastic holder of PTT key M2.0*3.7 cross recessed countersunk-head 7SMF-020037M-SZCT-N machine screw 7MHP-4320-06A-W0 Side key cap 7MHR-4320-01A-W0 Silicon-rubber PTT key 7MHS-4320-02A-W Metal dome array of PTT key...
DP680 service manual 6.1.2 Tuning in PC Mode (1)、Tx Frequency Under computer mode (frequency stability), adjust Tx frequency as reference frequency within ± 100Hz. (2)、Power a. Under PC mode (Tx high power) (eight frequencies), adjust Tx high power as 3.8-4.5W.
DP680 service manual b. Off threshold: Set RF signal to -80dBm, and modulation deviation to 3 kHz/ 1.5 kHz. Under PC mode, click OK when the value [RSSI L4] (at eight frequencies) becomes stable. (1).In Rx State a. Set the channel at a high Rx frequency, and check whether the TP101 voltage is <=3.9V.
DP680 service manual 8 Devices for Maintenance and Test Equipment Specification Frequency range: 100MHz~500MHz Modulation: Frequency modulation and external Standard signal generator modulation Output: -127dBm/0.1uV to > -47dBm/1mV Input impedance: 50Ω Power meter Operating frequency: 100MHz~500MHz Measurement range: About 10W...
DP680 service manual 9 Troubleshooting Failure Reason and Solution Description A. The battery may be in low power. Change to a new battery or change the battery. Failed to power on B. Fuse F100 is broken. the radio C. Power chip IC100 is broken. Replace it.
