  • Page 1 FA02049-EN TH/ONE OPERATING AND INSTALLATION MANUAL English...

  • Page 2: Technical Data

    DESCRIPTION Button Luminous ring Soft-touch arrows LED matrix display Printed CAME logo Brightness sensor Technical data MODELS TH/ONE Protection rating (IP) Power supply (V) 220-240 AC Frequency (Hz) 50/60 Maximum absorption (mA) Operating temperature (°C) 0-40 Maximum relative operating humidity (%)

  • Page 3: Installation

    INSTALLATION Remove the front cover...
  • Page 4 Access the terminal boards...
  • Page 5 Fasten to back box type 503 Fasten to UK back box...
  • Page 6 Fasten to German back box Fasten to round back box Ø60 Ø60...

  • Page 7: Wall-Mounted

    Wall-mounted...

  • Page 8: Electrical Connections

    ELECTRICAL CONNECTIONS Make the electrical connections according to the device controlled by the programmable thermostat. Please consult the technical documentation for the device to be controlled. In the event of a loss of power, the relay maintains the status it had prior to the power outage. U1 = Burner, circulation pump, solenoid valve, etc.

  • Page 9: Final Operations

    FINAL OPERATIONS Screw the terminal board protective cover back on...

  • Page 10: Getting Started

    GETTING STARTED Download the THermo Wi-Fi app from Google Play Store or the App store. Before accessing the THermo Wi-Fi app, make sure that your smartphone/tablet is connected to the internet with mobile data network exchange or to a Wi-Fi network that allows you to navigate correctly and view the CAMEConnect Cloud (open ports on the router 8883 and 1883).
  • Page 11 WELCOME TO CAME THERMO WI-FI WELCOME TO The CAME THermo Wi-Fi app allows you to manage your programmable thermostat from anywhere. CAME THERMO WI-FI WEEKLY TIME PROGRAMMING SCENARIOS AND ROUTINES Have you already got a CAMEConnect account? Sign in Create new...
  • Page 12 CREATE NEW ACCOUNT Email* Password* ..Passwords must have between 8 and 70 characters, at least one capital letter and one lowercase letter. Re-enter password* ..*Mandatory fields Continue Cancel Enter the required data to create a new CAMEConnect account. Log in.
  • Page 13 Check the connection icon is showing on the display. TH/550 If the connection icon is not showing on the display, press and hold the middle key until the icon appears. TH/500 TH/ONE Continue Cancel Choose the TH/ONE model. Follow the in-app instructions.
  • Page 14 DEVICE PAIRING PAIRING THERMOSTAT Select the thermostat you want to pair below. TH/ONE_SN_xxxx Drag to run a new search Cancel Select the thermostat found.
  • Page 15 DEVICE PAIRING DEVICE PAIRING WI-FI PAIRING Your thermostat is connecting. You can now connect the TH/ONE to your home network. Select the network from those listed and enter the password. Wait for the middle key to stop flashing. Is the connection icon you see here showing on the...
  • Page 16 DEVICE PAIRING DEVICE PAIRING HOUSE SETTINGS WI-FI PAIRING Give the zone or room where your thermostat is installed a name. Enter the password for the selected network Zone/Room name* Password ....House name* Continue ..Cancel Position ..By setting the city the device is installed in, you can see the weather forecast and compare your usage reports with the outside temperatures in your city.
  • Page 17 CREATE NEW ACCOUNT DEVICE CONFIGURATION COMPLETED SUCCESSFULLY! Go to home Resetting the network credentials If the programmable thermostat is not connected, you may need to set the network login details again. Select the programmable thermostat to be configured. Reset the Wi-Fi configuration (reset the programmable thermostat NET menu).
  • Page 18 USING THE DEVICE When first switched on, the programmable thermostat is in manual heating mode. The temperature measured appears on the display. Weekly preset temperature programming Timed programmes can be programmed only if the programmable thermostat is connected to the Wi-Fi network. If the programmable thermostat is not connected, the date and time cannot be set.

  • Page 19: Navigating The Device

    Navigating the device Press the button once. The ambient temperature read by the device appears on the display. If you do not press the button or the arrows, the device will go into standby mode after approximately 5 seconds. Press the button twice. The ambient humidity read by the device appears on the display as a percentage.
  • Page 20 Press the button three times. The active option from the four available in the operating menu is shown. The options do not necessarily appear in the order shown here. Use the arrows next to the button to navigate the operating menu. Press the button to confirm your choice from the options available in the operating menu.
  • Page 21 From this screen, press the button to view or modify the temperature set as the desired temperature in the app. Use the arrows next to the button to modify the desired temperature. Each time one of the arrows is pressed, the temperature increases or decreases by a tenth of a degree. Press and hold the arrows next to the button to either increase or decrease the desired temperature value more quickly.
  • Page 22 From this screen, press the button to activate BOOST mode. If the system is not yet active, you will hear the relay click and the luminous ring on the button will light up red to indicate activation. BOOST mode can last 30 minutes (shown on the screen by a single square lit up), 60 minutes (two squares lit up), 90 minutes (three squares lit up) and 120 minutes (four squares lit up).
  • Page 23 To access the ADVANCED menu, from any active screen, press and hold the button until you hear a beep. Release the button only after hearing the beep. The luminous button ring will light up white and stay on. Next press the button again to navigate the advanced menu. Press the button once to open the firmware submenu;...
  • Page 24 This screen shows the Wi-Fi signal strength. In the event of any errors, press the middle button from this screen to view them. Errors are explained at the end of the manual.
  • Page 25 On this screen, press the button to view the time. The time will show on the display only if the device is connected to CAMEConnect.
  • Page 26 Device reset On this screen, press the button to access the submenu. Use the arrows to choose the type of reset to be performed. There are three different types of reset: network reset (NET), device reset (TH) and full reset (ALL). Use the GO BACK arrow to exit the reset menu.
  • Page 27 From the reset menu, select the type of reset using the arrows. Press the button to confirm the selection. Then use the arrows to select whether you want to confirm the reset or cancel your choice. Press the button to confirm the option. The device will restart. Use the GO BACK arrow to exit the reset menu and return to the advanced menu start screen.

  • Page 28: Error Messages

    The programmable thermostat could not connect to the Cloud. Cloud service Wait for it to be restored (it may be temporarily undergoing maintenance). CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941 info@came.com - www.came.com...
