FA01325-EN
TH/700 WH BT
TH/700 BK BT
OPERATING AND INSTALLATION MANUAL
EN
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TH/700 WH BT and is the answer not in the manual?

Questions and answers

Related Manuals for CAME TH/700 WH BT

Summary of Contents for CAME TH/700 WH BT

  • Page 1 FA01325-EN TH/700 WH BT TH/700 BK BT OPERATING AND INSTALLATION MANUAL English...

  • Page 2: General Precautions

    • Use this product only for its specifically intended use. Any other use is hazardous. • Came S.p.A. is not liable for any damage caused by improper, wrongful and unreasonable use. • Use soft, dry or slightly damp cloths to clean the terminal;...
  • Page 3 DESCRIPTION Built-in Bluetooth® programmable chronothermostat. Powered by three 1.5 V AA batteries. 1 - System in operation 11 - Comfort level 2 - The thermal zone is in Manual mode 12 - The system is in heating mode 3 - The thermal zone is in Automatic mode 13 - The system is in cooling mode 4 - Clock 14 - The thermal zone is in BOOST mode...

  • Page 4: Operating Modes

    OPERATING MODES Basic Mode The modes that can be selected both from the THermo app and from the chronothermostat are indicated below. Manual With this mode it is possible to adjust the temperature quickly. Automatic With this mode it is possible to use the device with a predefined time programming in heating or cooling mode, on four pre-set temperature levels.

  • Page 5: Advanced Functions

    ADVANCED FUNCTIONS The modes available only from the THermo app are indicated below. Display mode Through the THermo app it is possible to select a simplified display of the screen. In this case, the following will be displayed: - temperature set-point, - system state, - internal temperature detected.
  • Page 6 Proportional Integral Algorithm Suggested for systems that are hard to control due to extreme, outdoor temperature variations. It ensures that the system is fully exploited while containing costs. It is for optimizing consumption while obtaining the most out ambient comfort, by reducing a boiler's powering-on times according to the difference between the set and room temperatures.

  • Page 7: Installation

    INSTALLATION Install the device in a place suitable for detecting the room's temperature, possibly onto an inside wall, and avoid any nooks, behind doors, near curtains or heat sources. Recess-mounted installation Once the electrical connections have been made, assemble the device Install the device on flat surfaces, avoiding to excessively close the screws.

  • Page 8: Electrical Connections

    Electrical connections The connections must be suitable for the devices controlled by the chronothermostat. Legend Mains power-supply conductors N = neutral - L = phase Relay contacts C = common NA = normally open contact NC = normally closed contact Loads U1 = burner, circulation pump, electric valve, etc.
  • Page 9 COMMISSIONING Download the THermo app from the reference stores. Power on the device. Start the app and select Bluetooth® data transmission. 1 Press to add a new chronothermostat.
  • Page 10 Select the chronothermostat to be added to those found. A six-digit code is displayed on the display of the device. Enter the code in the space provided and continue.
  • Page 11 It is possible to insert a description that identifies the device. The device is registered correctly.

  • Page 12: Using The Device

    USING THE DEVICE Premise When first switched on, the device is in automatic heating mode The temperature measured appears on the display. When the device is in stand-by, putting your hand near it, the screen is activated without executing any command. Weekly pre-set temperature programming (automatic mode) To allow an immediate use of the device, a standard programming has been set up for operation in heating mode and one for cooling mode, where the temperature levels set are:...

  • Page 13: Manual Mode

    Manual mode Press until the icon appears Use the arrows to set the desired function In this mode, when the device is in stand-by, putting your hand near it, the display is activated and, instead of the time display, the value of the set temperature appears for a few seconds.

  • Page 14: Vacation Mode

    If the system is in 'Cooling' mode, the control will be totally excluded If the system is in 'Heating' mode, the antifreeze function remains active For a few seconds the temperature set for the antifreeze is shown and then the current time and the detected temperature are displayed.

  • Page 15: Boost Mode

    Press the button to set the temperature to be maintained in the previously set days interval Use the arrows to set the desired value. A long press on the arrows allows to reach the desired value faster. The countdown is displayed each time the screen is activated After expiry of the set time the device will resume operation in automatic mode.
  • Page 16 The device starts a countdown The countdown is displayed each time the screen is activated. After expiry of the set period, the device will resume operation in the previously set mode...
  • Page 17 CONFIGURATION OF THE GENERAL PARAMETERS OF THE DEVICE Premise From the main screen, press and hold down the arrows to enter the SET-UP menu Press the center button to navigate through the various menus Screen lock Enter the SET-UP menu. Choose the parameter to be set.
  • Page 18 Change the system's mode of operation Enter the SET-UP menu. Choose the parameter to be set. Use the arrows to set the operating mode of the system The system is in heating mode The system is in cooling mode The thermal zone is off Buttons 'beep' Enter the SET-UP menu.
  • Page 19 Set date and time Enter the SET-UP menu. Choose the parameter to be set. Press one of the two arrows to display the submenu. Use the arrows to set the desired value. Press to confirm and move on to the next parameter to be configured.

  • Page 20: Window Contact

    Window contact Enter the SET-UP menu. Choose the parameter to be set. Use the arrows to enable or disable the window contact. With function enabled - when the contact is opened, the thermal zone (after a few tens of seconds) goes out. - when the contact is closed, the thermal zone returns to the previous mode.

  • Page 21: Device Reset

    Device reset Enter the SET-UP menu. Choose the parameter to be set. Use the arrows to select a different reset mode. Press and hold the button until the device is restarted to reset the thermal part. Press and hold the button until the device is restarted to restore it to factory conditions.

  • Page 22: Batteries Replacement

    Batteries replacement The indications show that the battery charge is not sufficient to manage the thermal zone and it is therefore excluded from the control The display backlighting is reduced Failure to replace batteries in convenient time may cause damage to the heating system (the antifreeze protection is no longer guaranteed) Open the device using a screwdriver...
  • Page 24 Technical data MODELS TH/700 WH BT TH/700 BK BT Protection rating (IP) 0-40 Working temperature (°C) Maximum relative operating humidity in 93 No condensation percentage BT Directive, EMC Directive, RED Directive Regulatory compliance Software class Dimensions (mm) 126 x 87 x 12...
