  • Page 1 FA01665-EN TH/700 WH BT TH/700 BK BT OPERATING AND INSTALLATION MANUAL English...
  • Page 2 • Before carrying out any cleaning or maintenance, disconnect the device from the power supply. • Only use this product for its intended purpose. Any other use is hazardous. • Came S.p.A. is not liable for any damage caused by improper, erroneous or unreasonable use. • Only use soft, dry or slightly damp cloths to clean the device.
  • Page 3 DESCRIPTION 845AA-0080 TH/700 WH BT -Bluetooth programmable thermostat with soft-touch keys, recess- mounted, white. Battery powered 3 x 1.5V AAA. 845AA-0090 TH/700 BK BT -Bluetooth programmable thermostat with soft-touch keys, recess- mounted, black. Battery powered 3 x 1.5V AAA. Heating system in operation...

  • Page 4: Technical Data

    Technical data TH/700 WH TH/700 BK MODELS Protection rating (IP) Operating temperature (°C) 0-40 Maximum relative operating humidity (%) 93 No condensation Size (mm) 126 x 87 x 12 Wireless frequency fi eld (MHz) 2400 Transmission power (dBm) Item Maximum current with resistive load and 250V relay (A) Maximum current with inductive load and 250V relay Number of relay outputs 1 NO-NC...

  • Page 5: Installation

    INSTALLATION 503/503B...

  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS Make the electrical connections according to the device controlled by the programmable thermostat. Please consult the technical documentation for the device to be controlled. In the event of a loss of power, the relay maintains the status it had prior to the power outage.
  • Page 7 Example 2 Closed valve Open valve...

  • Page 8: Final Operations

    Window contact inputs 1 -Connection for magnetic contact (maximum distance 20 meters) FINAL OPERATIONS...

  • Page 9: Getting Started

    GETTING STARTED Download the THermo app from Google Play Store or the App store. Start the app and select Bluetooth® data Tap this icon to add a new transmission. programmable thermostat.
  • Page 10 Select the chronothermostat to be added to A six-digit code is displayed on the display those found. of the device. Enter the code in the space provided and continue.
  • Page 11 Enter a description to identify the device. The device has been registered correctly.

  • Page 12: Using The Device

    USING THE DEVICE When fi rst switched on, the programmable thermostat is in automatic heating mode. The temperature measured appears on the display. Weekly preset temperature programming To get started quickly with the programmable thermostat, you can use the preset programming both for heating and cooling.

  • Page 13: Operating Modes

    Cooling Cooling programming table from Monday to Sunday Time Setpoint temperature level Midnight to 6 am T3 = 28°C 6 am to 10 pm T1 = 24°C 10 pm to midnight T3 = 28°C Operating modes Basic operation The following basic operation modes can be selected both from the THermo app and from the programmable thermostat itself.
  • Page 14 Set temperature Change mode key If the programmable thermostat is in Press to go to the next mode. standby, move your hand near it to activate If no keys are pressed, after a few the screen. seconds the detected temperature The set temperature will show in place of will show again on the programmable the time for a few seconds...
  • Page 15 BOOST mode In BOOST mode, you can activate heating or cooling for a limited period of 30, 60, 90 or 120 minutes, regardless of the programming set and the room temperature. Change mode key Navigation keys Thermal zone in BOOST mode Activation time Press and hold until the...
  • Page 16 HOLIDAY mode With holiday mode, you can set a temperature to be maintained for a chosen number of days. Change mode key Navigation keys Thermal zone in holiday mode Change mode key Press repeatedly until the icon Set the number of days using the keys.
  • Page 17 Navigation keys Change mode key Change mode key When the screen is activated, the remaining number of holiday days is displayed. Set the desired temperature using the When the set number of days have keys. passed, the programmable thermostat Press to confi...
  • Page 18 OFF - Exclusion from thermal control Change mode key Thermal zone off Press repeatedly until the icon appears. Press to go to the next mode. If the system is in COOLING mode, thermal control is excluded. For a few seconds the temperature is not shown, then the current time and temperature detected are displayed.

  • Page 19: Advanced Operation

    Advanced operation The advanced operation modes can be selected from the THermo app only. Display mode You can choose between a simplifi ed view (temperature setpoint, internal temperature detected and system status) and a full view. To switch from the simplifi ed to the full view, press one of the navigation keys.
  • Page 20 Proportional-Integral algorithm For systems with signifi cant variations in the outdoor temperature. Optimise consumption and reduce boiler ignition times by setting a minimum boiler ignition time as part of a cycle. There are 3 pre-confi gured programmes and 1 manual programme available for setting parameters.
  • Page 21 Example of thermal control with the Proportional-Integral algorithm Proportional band in degrees Temperature setpoint Centigrade Internal temperature trend Time in minutes Cycle Proportional band in degrees Centigrade...

  • Page 22: Setup Menu

    SETUP MENU Navigation keys Change mode key From the main screen, press and hold the Use the key to navigate through the keys to enter the [SETUP] menu. menu. Screen lock Navigation keys Change mode key Screen lock From the SETUP menu, choose [LOCK] using the key.
  • Page 23 Heating, cooling, OFF From the [SETUP] menu, choose [SEASON] Navigation keys using the key. Change mode key Use the keys to choose between the [SEASON] menu heating, cooling and OFF system operating Cooling mode modes. Heating mode Key sounds Navigation keys Change mode key [SET BIP] menu From the [SETUP] menu, choose [SET BIP]...
  • Page 24 Date/Time Navigation keys Change mode key [CLOCK] menu From the [SETUP] menu, choose [CLOCK] using the key. Press one of the two keys to open the submenu. Set the desired value using the keys. Press and hold the keys to set the desired value more quickly.
  • Page 25 Window contact Navigation keys From the [SETUP] menu, choose [SET cntc]. Use the keys to enable [On] or disable [Off ] the window contact. With the window contact set to [ON] and the programmable thermostat in operation, if the window is opened the programmable thermostat will switch off .
  • Page 26 Firmware version Change mode key From the [SETUP] menu, choose [Ver] using the key. The screen shows the fi rmware version for the programmable thermostat. Resetting the programmable thermostat Navigation keys Change mode key From the [SETUP] menu, choose [RESET] using the key.
  • Page 27 Batteries replacement Flat battery If the battery does not have suffi cient charge to manage the thermal zone, the zone is excluded. The display backlighting is reduced. If the batteries are fl at, the heating system antifreeze function may not work, causing damage.
  • Page 28 CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941...

This manual is also suitable for:

Th/700 bk bt
