Summary of Contents for Factor SLiCK 2025
- Page 2 2025 SLiCK MANUAL...
-
Page 3: Warranty
Since specific tools and bicycle service experience is required for proper assembly installation, it is recommended that the product be assembled by a qualified bicycle mechanic. FACTOR BIKES assumes no responsibility for damages or injury due to improper assembly and installation of the product(s). -
Page 4: Hose Routing
2025 SLiCK Hose routing Di2 routing Install rear brake and fish hose through the frame and out the head tube ● Install the Front and rear derailleur Di2 wires as needed, extending from the ● ● install the anti rattle rear brake hose foam sleeve battery mounting hole for attachment to the BT DN300 battery Insure that the clear plastic anti wear guard portion of the anti rattle hose ●... -
Page 5: Di2 Battery Installation
2025 SLiCK Di2 Battery installation Affix the Di2 Battery to the battery carrier ● ● Attach the Di2 Leads to the battery, give preference to the RD being attached to the center plug position for best function. Depending on the severity of your roads (ie, cobblestones) you may want to ●... - Page 6 2025 SLiCK Di2 Battery fixation Carefully slide the Di2 Battery holder and wires into the frame, leaving ● adequate slack in the cables to allow them to traverse the seattube past the battery without kinking them ● Install the two taperhead screws to fix the battery holder in position, tightening them to 2Nm...
- Page 7 Determine the type of SP rails on your saddle and choose the appropriate clamp setup from the Pizza Box of parts Factor frame sets are shipped with 7X9 mm outer rail clamps for carbon rail saddles. 7x7 mm outer rail clamps for traditional saddle...
- Page 8 2025 SLiCK Seat Post fixation Grease the rear side of the Seat Post Clamp ● inorder to “stick” it to the inside of the flat area in on the frame, at the rear of the seat post hole. Slide the seatpost gasket onto the seat post ●...
- Page 9 2025 SLiCK Steerer Working with your mechanic determine the correct number of spacers, and cut the fork ● Pre-cut fork steerer making sure that it is cut 3mm below steerer tube as shown below the top of the stem. WARNING! Only use a maximum of 40mm of spacers (including tall headset cover) supplied with the frameset.
- Page 10 2025 SLiCK Fork mounting ● Fish the front brake hose through the fork, from the bottom up. Pass the lower bearing over this hose and the cut steerer tube Lightly grease the lower bearing and install the fork in the frame, at the same time retract the rear brake hose in its anti-rattle housing ●...
- Page 11 2025 SLiCK Top bearing ● Lightly grease the top bearing, and the split ring. ● Pull the hoses through the top bearing, the split ring and your chosen height dust cover. Assemble spacers as required ● ● Bottom out the compression plug onto the top of the steerer, and tighten to 8 Nm...
- Page 12 2025 SLiCK Handlebar Installation Please refer to the handlebar manufacturers separate manual to guide you through the hose routing. ● In the case of the FSA/Vision handlebars you can retrieve this information from visiontechusa.com ●...
- Page 13 2025 SLiCK ● The 2025 Slick is configured for the use of a front derailleur, as well as supporting 1x only function. If using 1x, remove the FDM and install the supplied blanking plate. Be sure to follow all manufacturer recommendations for supporting plates, wedges, and screws when using the Slick, and tighten the FDM to no more ●...
- Page 14 2025 SLiCK Grommets Install the front and rear grommets ● Route the rear derailleur Di2 cable through Install Di2 cable grommet. Connect to the Di2 Junction B the chainstay. Route the front derailleur Di2 cable through Install Di2 cable grommet. Connect to the Di2 Junction B the seat tube hole to the bottom bracket exit port.
- Page 15 2025 SLiCK Apply a layer of good quality assembly paste Thread the cups into the frame and torque the cups Clean the inside of the frame bottom bracket to the threads of both bottom bracket cups. down to 30nm for the drive side and 40nm for the &...
- Page 16 2025 SLiCK Freehub on non-drive side ! Apply Loctite 243 on bolt threads. Thread the Install a rear hub in the dropout with the free After ensuring the dropout insert is correctly bolt in but do not tighten, this will allow the hub on non-drive side.
- Page 17 2025 SLiCK Install a front hub in the dropout with the free hub on non-drive side. This will allow better access for the After ensuring the dropout insert is correctly next step. Install the thru-axle with the nylon washer aligned, tighten the dropout bolt to 1 Nm. and tighten to 12Nm Apply Loctite 243 on bolt threads.
- Page 18 2025 SLiCK Install cap and tighten M5 bolts with Hex3 to 2 Nm.
- Page 19 2025 SLiCK Install cages and tighten M5 bolts with Hex3 to 2 Nm.
