Acrosser Technology ANR-C621A1 User Manual

2u 19” rackmount network appliance with intel c621a pch, socket type dual cpu, 8x nim modules
Table of Contents

Advertisement

Quick Links

ANR-C621A1
ANR-C621A1
2U 19" Rackmount Network Appliance
With Intel C621A PCH, Socket Type Dual CPU,
8x NIM Modules
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANR-C621A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acrosser Technology ANR-C621A1

  • Page 1 ANR-C621A1 ANR-C621A1 2U 19” Rackmount Network Appliance With Intel C621A PCH, Socket Type Dual CPU, 8x NIM Modules User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 3: Table Of Contents

    ANR-C621A1 Table of Contents 1. Introduction ..............5 1.1. Specifications ......................5 1.2. Packing List ........................ 7 1.3. System Dissection ...................... 8 1.3.1. Dimensions ..................... 8 1.4. Product View ......................10 1.4.1. Front View ..................... 10 1.4.2. Rear View .......................11 2. Hardware Configuration ..........12 2.1.
  • Page 4 3.11. Server Management Settings ................... 46 4. Appendix ..............47 4.1. I/O Port Address Map ....................47 4.2. Interrupt Request Lines (IRQ) .................. 49 5. FAQ ................51 Q 1. Where can I find the serial number of this product? ..........51 Acrosser Technology Co., Ltd.
  • Page 5: Introduction

    Introduction Acrosser has announced a new 2U rackmount edge network appliance named ANR-C621A1. This appliance is powered by dual Intel 3rd Gen Xeon Scalable Processors (Intel code name “Ice Lake-SP”). The ANR-C621A1 is infused with Intel Crypto Acceleration, which enhances data...
  • Page 6 32°F ~ 104°F (0°C ~ 40°C ) Storage Temperature • -4°F ~ 140°F (-20°C ~ 60°C) Humidity • 10%~90% @45°C relative humidity, non-condensing Vibration • Non-operating: 1.0 Grms (3~500Hz) Z-axis, duration 60 mins Certification • CE / FCC Class A Acrosser Technology Co., Ltd.
  • Page 7: Packing List

    ANR-C621A1 1.2. Packing List Check if the following items are included in the package. Item Q’ty ANR-C621A1 � Console cable, 160cm � 2.5” STAT data and power cable � www.acrosser.com...
  • Page 8: System Dissection

    ANR-C621A1 1.3. System Dissection 1.3.1. Dimensions (Unit: mm) 88.50 Acrosser Technology Co., Ltd.
  • Page 9 ANR-C621A1 www.acrosser.com...
  • Page 10: Product View

    Off: HDD not in use • POWER Green: power on Off: power not detected Console Port 2x USB 2.0 Ports MGMT Port LCM Display with 4 buttons NIC Modules Up to 8 NIC modules, 64GbE ports Max. Acrosser Technology Co., Ltd.
  • Page 11: Rear View

    ANR-C621A1 1.4.2. Rear View Description System Fans VGA Port Power Button (ATX mode) Power Supply Units (Single / Redundant) 2 AC 100~240V Full range 1200W 1+1 www.acrosser.com...
  • Page 12: Hardware Configuration

    Network Module Installation • Redundant Power Supply Installation 2.1. Installations For installation or replacement of the memory modules, HDD/SSD, or other internal components, you need to disassemble the device cover first by loosening 9 screws as indicated below. Acrosser Technology Co., Ltd.
  • Page 13: Memory Installation / Replacement

    ANR-C621A1 2.1.1. Memory Installation / Replacement If you need to install or replace a memory module, follow the instructions below after you have removed the device cover. Step 1: Locate the memory slots in the device. Step 2: Press the ejector tab of the memory slot down and outwards with your fingertips.
  • Page 14: Hdd Installation / Replacement

    Once the HDD tray has been removed, unfasten the screws (as shown by the circles and arrows) to uninstall the HDD from the tray. Step 3: Replace the HDD tray back to its original location after installation/ replacement/removal of the HDD. Acrosser Technology Co., Ltd.
  • Page 15: Card Installation / Replacement

    ANR-C621A1 2.1.3. M.2 Card Installation / Replacement To remove and install the M.2 card, remove the device cover as mentioned in the previous section and locate that card socket. Step 1: Locate the M.2 slot inside the device. Step 2: Align the key of the M.2 card to the interface, and insert the card...
  • Page 16: Fan Module Installation / Replacement

    2.1.5. SSL Card Installation / Replacement Step 1: Remove the device cover as described in the previous section. Unfasten the four (4) screws at the two edges as indicated in the picture below. Acrosser Technology Co., Ltd.
  • Page 17 ANR-C621A1 Step 2: Remove two (2) screws as shown in the picture below. Step 3: Remove the four (4) screws that fasten the SSL card to the standoffs. Step 4: The picture below shows the detached SSL card. Reverse the steps to install or reintall the SSL card in the system.
  • Page 18: Rackmount Installation Precautions

    2.1.8. Redundant Power Supply Installation To install or replace a redundant power supply, push the latch inwards first. Grasp the handle, pull the PSU out carefully and replace it with a new one. Acrosser Technology Co., Ltd.
  • Page 19: Setting The Jumpers

    ANR-C621A1 2.2. Setting the Jumpers Set up and configure your device by using jumpers for various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your use. 2.2.1. How to Set Jumpers Jumpers are short-length conductors consisting of several metal pins with a non- conductive base mounted on the circuit board.
  • Page 20: Jumper & Connector Locations On Motherboard

    ANR-C621A1 2.3. Jumper & Connector Locations on Motherboard Acrosser Technology Co., Ltd.
  • Page 21: Jumpers Quick Reference

    ANR-C621A1 2.4. Jumpers Quick Reference Function Jumper AT & ATX Mode Selection BMC Setting JP4, JP5 Clear CMOS 2.4.1. AT & ATX Mode Selection (JP1) Function Pin Closed Setting ATX (default) www.acrosser.com...
  • Page 22: Bmc Setting (Jp4, Jp5)

    JP5(2-3) (default) [For MBN901] JP4(2-3) JP5(1-2) Single CPU, CPU Temp from PECI, Redundant PSU JP4(1-2) JP5(2-3) Single CPU, CPU Temp from PECI, Non PNBus Single CPU, CPU Temp from NCT7904D Pin 8, NO JP4(1-2) JP5(1-2) PMBus Acrosser Technology Co., Ltd.
  • Page 23: Clear Cmos (Jp6)

    ANR-C621A1 2.4.3. Clear CMOS (JP6) Function Pin Closed Setting Normal RTC Reset (default) Clear RTC Registers www.acrosser.com...
  • Page 24: Connectors Quick Reference

    U.2 Connector (SATA 3.0 / PCIe x4) PMBus Connector USB 3.0 Box Header LAN Port Connector J42~J45 SATA Connector J48~J51 Gen-Z Cable Power Connector System 12V Power Connector 2.5.1. U. 2 Connector for SATA 3.0 / PCIe x4 (J32, J33) Acrosser Technology Co., Ltd.
  • Page 25: Pmbus Connector (J36)

    ANR-C621A1 2.5.2. PMBus Connector (J36) www.acrosser.com...
  • Page 26: Sata Connector (J42, J43, J44, J45)

    ANR-C621A1 2.5.3. SATA Connector (J42, J43, J44, J45) 2.5.4. System Fan (FAN1, FAN2, FAN3, FAN4) 2.5.5. ATX Power Button (J2) 2.5.6. CPU1 12V Power Connector (J3) Acrosser Technology Co., Ltd.
  • Page 27: Front Panel Function (J4)

    ANR-C621A1 2.5.7. Front Panel Function (J4) Pin # Signal Name Pin # Signal Name ATX PW SW ATX PW SW Reset SW (+) Reset SW (-) PW LED(+) PW LED(-) HDD LED(+) HDD LED(-) 2.5.8. CPU2 12V Power Connector (J5) 2.5.9.
  • Page 28: Sgpio Pin Header (J27)

    2.5.14. BMC Connector (IPMI) (J29) 2.5.15. U.2 Connector SATA3.0 & PCIe x4 (J32, J33) 2.5.16. PMBus Connector (J36) 2.5.17. USB3.0 Box Header (J37) 2.5.18. J30-pin LAN Port Connector (41) 2.5.19. SATA Connector (J42, J43, J44, J45) Acrosser Technology Co., Ltd.
  • Page 29: Gen-Z Cable Power Connector (J48, J49, J50, J51)

    ANR-C621A1 2.5.20. Gen-Z Cable Power Connector (J48, J49, J50, J51) Pin # Signal Name P12V P3V3 P3V3 Ground Ground 5V Dual 2.5.21. System 12V Power Connector (J53) www.acrosser.com...
  • Page 30: Bios Settings

    <PgDn> keys to change entries, <F1> for help, and <Esc> to quit. When you enter the BIOS Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices. Acrosser Technology Co., Ltd.
  • Page 31: Main Settings

    ANR-C621A1 Warning: It is strongly recommended that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases 3.3.
  • Page 32: Advanced Settings

    Settings in this section covers: • Trusted Computing • ACPI Settings • NCT55230 Super IO Configuration • NCT78940 HW Monitor • Serial Port Console Redirection • PCI Subsystem Settings • USB Configuration • NVME Configuration Acrosser Technology Co., Ltd.
  • Page 33: Trusted Computing

    ANR-C621A1 3.4.1. Trusted Computing • Security Device Support Enables / Disables BIOS support for security device. O.S. will not show security device. TCG EFI protocol and INT1A interface will not be available. • Pending operation Schedule an operation for the security device.
  • Page 34: Nct552130 Settings

    Enables / Disables system ability to hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. 3.4.3. NCT552130 Settings • Serial Port Configuration Sets parameters of Serial Ports. Enables / Disables the serial port and select an optimal setting for the Super IO device. Acrosser Technology Co., Ltd.
  • Page 35: Nct78940 Hw Monitor

    ANR-C621A1 3.4.4. NCT78940 HW Monitor • Smart Fan Control Disable or setting smart fan control start up temperature. • Temperatures / Voltages These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status.
  • Page 36 0 if the num of 1’s in the data bits is even. Options: None, Even, Odd, Mark, Space • Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit. Options: 1, 2 Acrosser Technology Co., Ltd.
  • Page 37 ANR-C621A1 • Flow Control Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a “stop” signal can be sent to stop the data flow. Options: None, Hardware RTS/CTS • VT-VTF8 Combo Key Support Enables / Disables VT-UTFB combination key support for ANSI/VT100 terminals.
  • Page 38: Pci Subsystem Settings

    This item if system has SR-IOV capable PCIe Devices, this option enables or disables Single Root IO Virtualization Support. • BME DMA Mitigation This item Re-enable Bus Master Attribute disabled during Pci enumeration for PCI Bridges after SMM Locked. 3.4.7. USB Configuration Acrosser Technology Co., Ltd.
  • Page 39: Nvme Configuration

    ANR-C621A1 • Legacy USB Support • Enable: Enables Ledacy USB Support. • Auto: Disables legacy support if no USB devices are connected. • Disable: Keeps USB devices available only for EFI applications. • XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
  • Page 40: Platform Configuration

    Wake on LAN Enable Enables / Disables integrated LAN to wake the system. • Restore AC Power Loss Select AC power state when power is re- applied after a power failure. Options: Power Off, Power On, Last State. Acrosser Technology Co., Ltd.
  • Page 41: Socket Configuration

    ANR-C621A1 3.6. Socket Configuration This section is for processor configuration. It displays and provides options to change the processor settings. www.acrosser.com...
  • Page 42: Server Management

    • System Event Log Allows you to configure the settings for system event log. • BMC self test log Allows you to configure when to erase the log. • BMC Network Configuration Configures BMC network parameters. Acrosser Technology Co., Ltd.
  • Page 43 ANR-C621A1 • SEL Components Enables / Disables all features of system event logging during boot. • Erase SEL Allows you to choose options for erasing SEL. Options: No, Yes on next reset, Yes on every reset • When SEL is Full Allows you to choose options for reactions to a full SEL.
  • Page 44: Security Settings

    Sets an administrator password for the setup utility. • User Password Sets a user password. 3.9. Boot Settings • Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Acrosser Technology Co., Ltd.
  • Page 45: Save & Exit Settings

    ANR-C621A1 • Bootup NumLock State Turns on/off the keyboard NumLock state. • Quiet Boot Enables / Disables Quiet Boot option. • Network Enables / Disables Network • Boot Option Priorities Sets the system boot order. 3.10. Save & Exit Settings •...
  • Page 46: Server Management Settings

    Station IP address Displays IP Address information • Subnet mask Displays Subnet Mask information Please note that the IP address must be in three digitals for example 192.168.000.001. • Router IP address Displays the Router IP Address information Acrosser Technology Co., Ltd.
  • Page 47: Appendix

    ANR-C621A1 Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) 4.1. I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device.
  • Page 48 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller 0x00000038-0x00000039 Programmable interrupt controller 0x0000003C-0x0000003D Programmable interrupt controller 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller Acrosser Technology Co., Ltd.
  • Page 49: Interrupt Request Lines (Irq)

    ANR-C621A1 Address Device Description 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000A000-0x0000AFFF Intel(R) Atom(TM) processor C3000 product family PCIe Root Port 4 - 19A8 4.2. Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required.
  • Page 50 PCIe Root Port 3 - 19A7 IRQ 4294967292 Intel(R) Atom(TM) processor C3000 product family PCIe Root Port 2 - 19A6 IRQ 4294967293 Intel(R) Atom(TM) processor C3000 product family PCIe Root Port 0 - 19A4 IRQ 4294967294 PCI Express Root Port Acrosser Technology Co., Ltd.
  • Page 51: Faq

    ANR-C621A1 Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box.
  • Page 52: Technical Support Form

    ANR-C621A1 Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 53 Acrosser Headquarters Acrosser China Subsidiary 深圳市欣扬通电子有限公司 241402新北市三重區重新路5段609巷4號3樓之8 深圳市福田区泰然八路安华工业区4栋5层505室 Rm. 8, 3F., No. 4, Ln. 609, Sec. 5, Chongxin Rd., (邮编: 518040) Sanchong Dist., New Taipei City 241402, Taiwan Room 505, Floor 5, Building 4, Anhua Industrial TEL: +886-2-29999000 Zone, Tairan 8th Road, Futian District, Shenzhen, FAX: +886-2-29992887 China (Postal: 518040) Acrosser Taichung Office...
