Acrosser Technology AND-DNV3B Series User Manual

Networking micro box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AND-DNV3Bx
Networking Micro Box
®
• Intel
Denverton
• 6x 2.5GbE Copper
• 2x SFP
• 2x SFP+
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
®
SoC
AND-DNV3Bx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AND-DNV3B Series and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology AND-DNV3B Series

Summary of Contents for Acrosser Technology AND-DNV3B Series

  • Page 1 AND-DNV3Bx AND-DNV3Bx Networking Micro Box ® ® • Intel Denverton • 6x 2.5GbE Copper • 2x SFP • 2x SFP+ User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AND-DNV3Bx Table of Contents 1. System Introduction ..............5 1.1. Specifications ......................5 1.2. Package Contents ...................... 8 1.3. Model Description ....................... 8 1.4. System Dissection ...................... 9 1.4.1. Dimensions ..................... 9 1.4.2. Front I/O Panel ....................10 1.4.3. Rear I/O Panel ....................11 2.
  • Page 4 Q 1. Where is the serial number located on my system ? ..........45 Q 2. How to active the second SIM card SIMCOM SIM8202G 5G ? ......45 Q 3. How to switch over Sierra Module Dual SIM Setting ? ..........45 Acrosser Technology Co., Ltd.

  • Page 5: System Introduction

    AND-DNV3Bx System Introduction AND-DNV3Bx is an entry level networking appliance. In a small box, this appliance equip a powerful Intel Atom C3000 SoC. This SoC supports multi-core CPU computing and support QAT, USB 3.0 and LAN controller which can be 10GbE capable.

  • Page 6: Network Interface

    • 2x USB 3.0 (USB 2.0 for AND-DNV3B1) • 1x RJ45 Console Port • 2x SFP+ (for AND-DNV3B2/AND-DNV3B3) • 2x SFP • 6x GbE RJ45 • 10x Optional SMA for WLAN & WWAN (WiFi 5 & 4G/5G LTE) • 1x DC-in Connector (12V) Acrosser Technology Co., Ltd.
  • Page 7 AND-DNV3Bx Internal I/O • 1x M.2E_1 2242 Connector (for Wi-Fi 2T2R module) • 1x M.2B_1 Connector (with USB 2.0+3.0 signal) with SIM socket, support 3042/3052 • 1x M.2B_2 Connector 1x M.2 2242/2280/3042/3052 B-key support SATA, USB 2.0+3.0 signal with SIM socket. For AND-DNV3B1 and AND-DNV3B2: BIOS default setting is SATA, user need to change signal from SATA to USB 3.0 under BIOS setting when...

  • Page 8: Package Contents

    2x SFP+, 2x USB 3.0, 1x 12V DC-In. 40W Adapter and fanless design. AND-DNV3B3 Intel Atom C3758 (8-core) SoC, 6x 2.5GbE Copper, 2x SFP, 2x SFP+, 2x USB 3.0, 1x 12V DC-In. 60W Adapter (With Smart fan design) Acrosser Technology Co., Ltd.

  • Page 9: System Dissection

    AND-DNV3Bx 1.4. System Dissection 1.4.1. Dimensions (Unit: mm) www.acrosser.com...

  • Page 10: Front I/O Panel

    SFP+ 1~2 Link/Active LED • SIM CARD SIM Card Socket SIM1 SIM2 Note: If you use a 4G LTE/5G module that only supports one single SIM card, please insert the SIM CARD into the SIM1 slot. Acrosser Technology Co., Ltd.

  • Page 11: Rear I/O Panel

    AND-DNV3Bx 1.4.3. Rear I/O Panel • ANT1 ~ ANT10 SMA Antenna Hole. Reserved for optional WLAN & WWAN (WiFi 5 & 4G/5G LTE) • Reset Reset Button • DC 12V DC12V Power Input • Console: Console Port (RJ45) Pin # Signal Pin # Signal...

  • Page 12: Components Assembly

    Please follow the instruction to install the inner modules. 2.1. SIM Card Installation Step 1: Remove the screw on the SIM Card cover plate. Step 2: Take down the SIM Card cover plate. Step 3: Insert the SIM card . Acrosser Technology Co., Ltd.
  • Page 13 AND-DNV3Bx Step 4: Push the SIM card into the socket until it docks in locked position. Step 5: Put the the SIM Card cover plate back. Step 6: Lock the SIM Card cover plate with screw . www.acrosser.com...

  • Page 14: Pcb Parts Description

    Step2: Allign with the two screw holes and put the plate on the copper pillar. Step3: Lock the plate with screws to the copper pillar. Step4: Install the 2242 4G/5G model or SSD here. NGFF_B_2 is allocated to SIM2. Acrosser Technology Co., Ltd.
  • Page 15 AND-DNV3Bx NGFF_E_1 M.2E connector for Wi-Fi 2T2R module The Wi-Fi antenna is SMA female type. Please connect to the socket marked with Wi-Fi on the panel and have it fastened. NGFF_B_1 M.2B connector with USB 2.0+3.0 signal & SATA3, for 4G/5G module or 2242 SSD The 4G/5G antenna is SMA male type.

  • Page 16: Hard Disk Installation

    SATA power cable taken out from the accessory bag, and then fixed it to the top cover. When using HDD 7mm, please place the front side facing the mainboard and fix screws at 4 sides. Acrosser Technology Co., Ltd.
  • Page 17 AND-DNV3Bx Step 3: Before fixing the hard disk, stuff the yellow anti-vibration wire loop into the big circle first, and then use a cross screwdriver to fix the hard disk with screws on 4 sides. The yellow anti-vibration wire loop and the screws are included in the accessory bag.

  • Page 18: Module Installation

    As there are fifferent module interfaces, like M.2 B key, M.2 E key, or mPCIE, please comply with the one the system specification specified. • As there are fifferent module specifications, like Half size, Full size, 3042, or 3052, please comply with the one the system specification specified. Acrosser Technology Co., Ltd.

  • Page 19: Rf Cable Installation

    AND-DNV3Bx 2.5. RF Cable Installation Step 1: Connect the RF plug to the module connector. Notes: • Wi-Fi: Support 2 RF cables at least. • 4G LTE: Support 1 RF cable at least, up to 3 RF cables. • 5G: Support 2 RF cables at least. Step 2: The foolproof position and shape of the joint should correspond with the opening of the system panel.
  • Page 20 For the connector marked as GNSS or GPS, please install it on the system panel where the GPS antenna is located. • The connector marked as MAIN or AUX is a 4G connector, please install it on the system panel marked 4G or 5G antenna. Use the MAIN connector first. Acrosser Technology Co., Ltd.

  • Page 21: Antenna Installation

    AND-DNV3Bx 2.6. Antenna Installation Connect your antennas according to your system configuration. Wi-Fi: Connect female type antenna to the male type socket Wi-Fi 2 or Wi-Fi 1. GPS: Connect male type antenna tail cable to the female type socket GPS. 4G/5G: Connect male type antenna to the female type socket marked with For the second 4G or 5G module, connect antenna to the socket located at both...

  • Page 22: Bios Settings

    Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. Note: Listed at the bottom of the menu are the control keys. If you need any help with the item fields, you can press <F1> key, and it will display the relevant information. Acrosser Technology Co., Ltd.
  • Page 23 AND-DNV3Bx • Total Memory This item displays the total size of memory available in the system. • System Date/System Time Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys. Enter new values using the keyboard. Press the key or the arrow keys to move between fields.

  • Page 24: Advanced Setup

    Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. • Security Device Suppor Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Acrosser Technology Co., Ltd.

  • Page 25: Advanced Setup: Onboard Bypass Controller

    AND-DNV3Bx • Pending operation Schedule an Operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change state of Security Device. • Platform Hierarchy Enable or Disable Platform Hierarchy. • Storage Hierarchy Enable or Disable Storage Hierarchy. •...

  • Page 26: Advanced Setup: W83627Dhg Super Io Configuration

    F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. • Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). • Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMA). Acrosser Technology Co., Ltd.
  • Page 27 AND-DNV3Bx Aptio Setup Utility - Copyright (C) 2022 American Megatrends, Inc. Advanced Serial Port 1 Configuration Enable or Disable Serial Port (COM) Serial Port [Enabled] Device Settings IO=3F8h; IRQ=4; Change Settings [Auto] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt.

  • Page 28: Advanced Setup: W83627Dhg Hw Monitor

    Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. • Smart Fan Mode [Thermal Cruise Mode] : You can adjust FAN Target Temperatur and FAN Tolerance manually. If CPU temp is lower than target temp-tolerance, the fan will run at low fan Acrosser Technology Co., Ltd.

  • Page 29: Advanced Setup: Serial Port Console Redirection

    AND-DNV3Bx speed. If CPU temp ishigherer than target temp+tolerance, the fan will run at full fan speed. [Manual Mode] : You can set fixed fan speed. • FAN Target Temperature Input a target temperature between 0 ~ 127°C. • FAN Tolerance Input a target temperature tolerance.
  • Page 30 Whensending data, if the receiving bufers are full, a “stop” signal can be sent to stop the datalow. Once the bufers are empty, a “start” signal can be sent to restart the low. Hardwarelow uses two wires to send start/stop signals. he options include [None] and [HardwareRTS/CTS]. Acrosser Technology Co., Ltd.

  • Page 31: Advanced Setup: Network Stack Configuration

    AND-DNV3Bx • VT-UTF8 Combo Key Support Use this item to enable or disable the VT-UTF8 Combo Key Support for ANSI/VT100 terminals. • Recorder Mode Use this item to enable or disable Recorder Mode to capture terminal data and send it astext messages. •...

  • Page 32: Advanced Setup: Csm Configuration

    Use this item to control the Legacy/UEFI memory sequence. Options are: [UEFI and Legacy], [Legacy only], [UEFI only]. • Network This item provides control of the operation UEFI and regular PXE/Storage/Video, ramdomly read memory (OpROM). Options are: [UEFI], [Legacy], [Do not Launch]. Acrosser Technology Co., Ltd.

  • Page 33: Advanced Setup: Usb Configuration

    AND-DNV3Bx 3.2.8. Advanced Setup: USB Configuration Aptio Setup Utility - Copyright (C) 2022 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option USB Module Version disables legacy support if no USB devices are USB Controllers: connected. DISABLE 1 XHCI option will keep USB USB Devices:...

  • Page 34: Intelrcsetup

    [Enable] [Enable] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 35: Intelrcsetup: South Bridge Chipset Configuration

    AND-DNV3Bx • Turbo This feature allows processor cores to run faster than marked frequency in specific conditions. • Enable or Disable Intel Virtual Machine Extensions (VMX) for IA-32 processors that ® support Intel Vanderpool Technology. 3.3.2. IntelRCSetup: South Bridge Chipset Configuration Aptio Setup Utility - Copyright (C) 2022 American Megatrends, Inc.

  • Page 36: Intelrcsetup: Sata Port

    F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2022 American Megatrends, Inc. • Enable/disable port Enables/Disables SATA Controller port if supported by current cpu SKU. Acrosser Technology Co., Ltd.

  • Page 37: Intelrcsetup: M.2 Sata Port

    AND-DNV3Bx 3.3.4. IntelRCSetup: M.2 SATA Port Aptio Setup Utility - Copyright (C) 2022 American Megatrends, Inc. IntelRCSetup M.2 SATA Port Enables/Disables SATA Device Information: [Not Installed] Controller port if Device Size: [Unknown] supported by current Enable/disable port [Enabled] cpu SKU. →←: Select Screen ↑↓: Select Item Enter: Select...

  • Page 38: Boot Setup

    OEM logo instead of the normal POST messages. • Boot Option Priorities This feature allows the user to specify which devices are boot devices and the order of priority from which the systems boots from during startup. Acrosser Technology Co., Ltd.

  • Page 39: Save & Exit Setup

    AND-DNV3Bx 3.6. Save & Exit Setup Aptio Setup Utility - Copyright (C) 2022 American Megatrends, Inc. Main Advanced IntelRCSetup Security Boot Save & Exit Save Options Reset the system after Save Changes and Reset saving the changes. Discard Changes and Reset Restore Defaults Boot Override →←: Select Screen...

  • Page 40: Software Installation And Programming Guide

    4. Get bypass wdt action. 5. Set bypass power on action. 6. Get bypass power on action. 7. Set bypass power off action. 8. Get bypass power off action. 9. Set bypass current action. 10. Get bypass current action. Acrosser Technology Co., Ltd.

  • Page 41: File Descriptions

    AND-DNV3Bx 4.2. File Descriptions 4.2.1. GPIO/Watchdog/LAN Bypass Subsystem Module 1. TestUtility.exe The GPIO, Watchdog , Lan Bypass. Console user interface bin binary. 2. Libw83627.h This file includes the declarations of the APIs and macro definitions. 3. Libw83627.a The static library for linux. 4.

  • Page 42: Watchdog

    16 character array. Return Value: 0: Successful, -1: fail. Syntax: int set_bypass_wdt(int pair, int time) Description: This function can set which pair bypass Wdt timer. Parameters: pair: 1-4 , time: 1-255(sec), 0:stop. Return Value: 0: Successful, -1: fail. Acrosser Technology Co., Ltd.
  • Page 43 AND-DNV3Bx Syntax: int set_bypass_wdt_action(int pair, int action) Description: This function can set which pair bypass Wdt time up action. Parameters: pair: 1-4 , action: 1:bypass, 0:normal Return Value: 0: Successful, -1: fail. Syntax: int get_bypass_wdt_action(int pair) Description: This function can get which pair bypass Wdt time up action.

  • Page 44: Notes

    Parameters: None. Return Value: None. Note: If you want to control the LAN module bypass on the LAN card purchased from Accrosser, be sure to take “7” Module H as the module reference for programming. Acrosser Technology Co., Ltd.

  • Page 45: Faq

    AND-DNV3Bx Q 1. Where is the serial number located on my system ? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) Q 2. How to active the second SIM card SIMCOM SIM8202G 5G ? •...
  • Page 46 FSN: LF543632720310 +GCAP: +CGSM AT!ENTERCND="A710" Enable access to password-protected commands  AT!CUSTOM? Display customizations that are currently enabled  !CUSTOM: GPSENABLE0x01 GPSSEL0x01 SIMLPM0x01 USBSERIALENABLE0x01 SINGLEAPNSWITCH0x01 AT!CUSTOM=? !CUSTOM: "GPSENABLE" "GPSLPM" "GPIOSARENABLE" "GPSSEL" "GPSREFLOC" "IMSWITCHHIDE" "IMCONFIG" "IPV6ENABLE" "WAKEHOSTEN" "SIMHOTSWAPDIS" Acrosser Technology Co., Ltd.
  • Page 47 AND-DNV3Bx "CFUNPERSISTEN" "QMIDETACHEN" "UIM2ENABLE" "NETWORKNAMEFMT" "SIMLPM" "USBSERIALENABLE" "PCSCDISABLE" "DHCPRELAYENABLE" "FLOWNOTIDISABLE" "FASTENUMEN" "CSVOICEREJECT" "IPCHANNELRATEEN" "SINGLEAPNSWITCH" AT!CUSTOM="UIM2ENABLE",1 Enable USIM2 identity  AT!CUSTOM? !CUSTOM: GPSENABLE0x01 GPSSEL0x01 UIM2ENABLE0x01 SIMLPM0x01 USBSERIALENABLE0x01 SINGLEAPNSWITCH0x01 AT+CPIN? +CPIN: READY AT!UIMS? Request USIM setting (USIM1 or USIM2)  !UIMS: 0 USIM1 is active ...
  • Page 48 AND-DNV3Bx AT+CIMI Request international mobile subscriber  466924000182599 AT!UIMS=1 Active USIM2  AT!UIMS? Request USIM setting (USIM1 or USIM2)  !UIMS: 1 USIM2 is active  AT+CPIN? +CPIN: READY AT+CIMI Request international mobile subscribe  222013068883994 Acrosser Technology Co., Ltd.

  • Page 49: Technical Support Form

    AND-DNV3Bx Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 50 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241402新北市三重區重新路5段609巷4號3樓之8 江苏省南京市江宁区天元东路228号504室 Rm. 8, 3F., No. 4, Ln. 609, Sec. 5, Chongxin Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241402, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887...
