- Page 1 ACM-TGLUE0-Ax ACM-TGLUE0-Ax COM Express Mini Module Type 10 ® with Intel Tiger Lake U User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
- Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Table Of Contents
ACM-TGLUE0-Ax Table of Contents 1. Introduction ..............5 1.1. Specifications ......................5 1.2. Packing List ........................ 6 1.3. Block Diagram ......................7 2. Hardware Information ...........8 2.1. Mainboard Layout ....................... 8 2.2. Row A/B Pin Assignments ..................9 2.3. Board Dimension ...................... 13 3. - Page 4 5.1.2. Memory Address Map ................... 43 5.1.3. Large Memory Address Map ................ 43 5.1.4. IRQ Mapping Chart ..................44 6. FAQ ................55 Q 1. Where can I find the serial number of this product? ..........55 Acrosser Technology Co., Ltd.
-
Page 5: Introduction
ACM-TGLUE0-Ax Introduction ACM-TGLUE0-A0 (Intel 11 Core i7-1185GRE ) +16GB RAM ACM-TGLUE0-A1 (Intel 11 Core i7-1187G7E ) +16GB RAM ACM-TGLUE0-A2 (Intel 11 Core i5-1145G7E ) +16GB RAM ACM-TGLUE0-A3 (Intel 11 Core i3-1115G4E ) +8GB RAM 1.1. Specifications ® ™ • 11th Generation Intel Core Processor Family (formerly Tiger Lake UP3) -
Page 6: Packing List
84 mm x 55 mm (3.31" x 2.17") COM Express type 10 Safety • CE, FCC Class A 1.2. Packing List Check if the following items are included in the package. Item Q’ty ACM-TGLUE0 � CPU Cooler � Acrosser Technology Co., Ltd. -
Page 7: Block Diagram
ACM-TGLUE0-Ax 1.3. Block Diagram www.acrosser.com... -
Page 8: Hardware Information
ACM-TGLUE0-Ax Hardware Information 2.1. Mainboard Layout Top View Acrosser Technology Co., Ltd. -
Page 9: Row A/B Pin Assignments
ACM-TGLUE0-Ax Bottom View 2.2. Row A/B Pin Assignments Pin # Row A Pin # Row B GND (FIXED) GND (FIXED) GBE0_MDI3- GBE0_ACT# GBE0_MDI3+ LPC_FRAME# GBE0_LINK100# LPC_AD0 GBE0_LINK1000# LPC_AD1 GBE0_MDI2- LPC_AD2 GBE0_MDI2+ LPC_AD3 GBE0_LINK# N.C. GBE0_MDI1- N.C. A10 GBE0_MDI1+ B10 LPC_CLK A11 GND (FIXED) B11 GND (FIXED) A12 GBE0_MDI0-... - Page 10 A41 GND (FIXED) B41 GND (FIXED) A42 USB2- B42 USB3- A43 USB2+ B43 USB3+ A44 USB_2_3_OC# B44 USB_0_1_OC# A45 USB0- B45 USB1- A46 USB0+ B46 USB1+ A47 VCC_RTC B47 N.C. A48 N.C. B48 N.C. A49 N.C. B49 SYS_RESET# Acrosser Technology Co., Ltd.
- Page 11 ACM-TGLUE0-Ax Pin # Row A Pin # Row B A50 LPC_SERIRQ B50 CB_RESET# A51 GND (FIXED) B51 GND (FIXED) A52 N.C. B52 N.C. A53 N.C. B53 N.C. A54 GPI0 B54 GPO1 A55 N.C. B55 N.C. A56 N.C. B56 N.C. A57 GND B57 GPO2 A58 PCIE_TX3+ B58 PCIE_RX3+...
- Page 12 B102 FAN_TACHIN A103 LID# B103 SLEEP# A104 VCC_12V B104 VCC_12V A105 VCC_12V B105 VCC_12V A106 VCC_12V B106 VCC_12V A107 VCC_12V B107 VCC_12V A108 VCC_12V B108 VCC_12V A109 VCC_12V B109 VCC_12V A110 GND (FIXED) B110 GND (FIXED) Acrosser Technology Co., Ltd.
-
Page 13: Board Dimension
ACM-TGLUE0-Ax 2.3. Board Dimension (Unit: mm) www.acrosser.com... - Page 14 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
-
Page 15: Bios Settings
ACM-TGLUE0-Ax BIOS Settings The AMI BIOS ROM has a pre-installed Setup program that allows users to modify basic system configurations, which is stored in the battery-backed CMOS RAM and BIOS NVRAM so that the information is retained when the power is turned off. To enter BIOS Setup, press <Del>... -
Page 16: Advanced Setup
ACM-TGLUE0-Ax 3.2. Advanced Setup 3.2.1. Graphics Configuration • VBT Select Select VBT for GOP Driver. Acrosser Technology Co., Ltd. -
Page 17: Cpu Configuration
ACM-TGLUE0-Ax 3.2.2. CPU Configuration • Active Processor Cores Number of cores to enable in each processor package. • Turbo Mode Enable/Disable processor Turbo Mode (requires EMTTM enabled too). AUTO means enabled. • Hyper-Threading Enable or Disable Hyper-Threading Technology. • Intel(R) SpeedStep(tm) Allows more than two frequency ranges to be supported. -
Page 18: Memory Configuration
BIOS stolen memory regions. • In-Band ECC Operation Mode 0: Functional Mode protects requests based on the address range, 1: Makes all requests non-protected and ignore range checks, 2: Makes all requests protected and ignore range checks Acrosser Technology Co., Ltd. -
Page 19: On-Module H/W Monitor
ACM-TGLUE0-Ax 3.2.4. On-Module H/W Monitor 3.2.4.1. Fan 1 Mode Configuration Fan 1: Full Mode www.acrosser.com... - Page 20 Smart Fan Mode Select. • PWM signal Select output PWM of inverting or non-inverting signal. Fan 1: Manual Mode by PWM • Manual Setting Set Fan at fixed Duty-Cycle Min = 0 Max = 100 Please input Dec number: Acrosser Technology Co., Ltd.
- Page 21 ACM-TGLUE0-Ax Fan 1: Auto Mode by PWM • Monitor Thermal Select monitor thermal source • Temperature Of Start Temperature Of Start • Temperature of Off Temperature of Off • Start PWM Start PWM • Slope (PWM) Slope (PWM) www.acrosser.com...
-
Page 22: Pch-Fw Configuration
ACM-TGLUE0-Ax 3.2.5. PCH-FW Configuration 3.2.5.1. Firmware Update Configuration • Me FW Image Re-Flash Enable/Disable Me FW Image Re-Flash function. Acrosser Technology Co., Ltd. -
Page 23: On-Module Configuration
ACM-TGLUE0-Ax • Local FW Update Enable/Disable ME FW Update function 3.2.6. On-Module Configuration • Battery Management Enable to support battery in ACPI OS by I2C_CK, I2C_DAT (B33, B34) • EC-SMB-HC Support SMBus Host Controller Interface via Embedded Controller. www.acrosser.com... -
Page 24: Power Management
RTC wake system from S5 Fixed Time: System will wake on the hr:min:sec specified. Dynamic Time: System will wake on the current time + Increase minute(s) Bypass: BIOS will not control RTC wake function during system shutdown Acrosser Technology Co., Ltd. -
Page 25: Bios Robot
ACM-TGLUE0-Ax 3.2.8. BIOS Robot • Sends watch dog before BIOS POST Enabled - Robot set Watch Dog Timer (WDT) right after power on, before BIOS start POST process. And then Robot will clear WDT on completion of POST. WDT will reset system automatically if it is not cleared before its timer counts down to zero. -
Page 26: System I/O Setup
ACM-TGLUE0-Ax 3.3. System I/O Setup 3.3.1. PCI Express Configuration Acrosser Technology Co., Ltd. - Page 27 ACM-TGLUE0-Ax • PCI Express Root Port 1 Control the PCI Express Root Port. • PCIe Speed Configure PCIe Speed. • Hot Plug PCI Express Hot Plug Enable/Disable. • PCIe 0_3 Select PCIE Controller Selection. • PCI Express 0 Control the PCI Express Root Port. •...
-
Page 28: Storage Configuration
Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. • Port 1 Enable or Disable SATA Port. • Hot Plug Designates this port as Hot Pluggable. • SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. Acrosser Technology Co., Ltd. -
Page 29: Hd Audio Configuration
ACM-TGLUE0-Ax 3.3.3. HD Audio Configuration • HD Audio Control Detection of the HD-Audio device. Disabled: HD-Audio will be unconditionally disabled. Enabled: HD-Audio will be unconditionally enabled. www.acrosser.com... -
Page 30: Digital Io Port Configuration
ACM-TGLUE0-Ax 3.3.4. Digital IO Port Configuration • GPI* Set DIO as Input or Output. • GPO* Set DIO as Input or Output. • Output Level Set output level when DIO pin is output. Acrosser Technology Co., Ltd. -
Page 31: Legacy Logical Devices Configuration
ACM-TGLUE0-Ax 3.3.5. Legacy Logical Devices Configuration 3.3.5.1. Serial Port 1 Configuration • Use This Device Enable or Disable this Logical Device. www.acrosser.com... -
Page 32: Serial Port 2 Configuration
3.3.5.2. Serial Port 2 Configuration • Use This Device Enable or Disable this Logical Device. • Possible Allows the user to change the device resource settings. New settings will be reflected on this setup page after system restarts. Acrosser Technology Co., Ltd. -
Page 33: Serial Port Console Redirection
ACM-TGLUE0-Ax 3.3.6. Serial Port Console Redirection • Console Redirection Console Redirection Enable or Disable. • Console Redirection EMS Console Redirection Enable or Disable. www.acrosser.com... -
Page 34: Security Setup
Press Enter again to set the password. • Removing the Password Select the password you want to remove and enter the current password. At the next dialog box press Enter to disable password protection. Acrosser Technology Co., Ltd. -
Page 35: Trusted Computing
ACM-TGLUE0-Ax 3.4.1. Trusted Computing • Security Device Support Enables or Disables BIOS support for security device. O.S. will not show Security Device. TGU EFI protocol and INT1A interface will not be available. • SHA-1 PCR Bank Enable or Disable SHA-1 PCR Bank •... -
Page 36: Secure Boot
System mode is in User mode. Changing the mode requires platform reset. • Secure Boot Mode Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication. Acrosser Technology Co., Ltd. -
Page 37: Key Management
ACM-TGLUE0-Ax 3.4.2.1. Key Management • Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. www.acrosser.com... -
Page 38: Boot Setup
ACM-TGLUE0-Ax 3.5. Boot Setup • Quiet Boot Enables or disables Quiet Boot option. • Network Stack Enable/ Disable UEFI Network Stack Acrosser Technology Co., Ltd. -
Page 39: Save & Exit Setup
ACM-TGLUE0-Ax 3.6. Save & Exit Setup www.acrosser.com... -
Page 40: Drivers Installation
4. Run the Wired_driver_26.3_x64.exe file in the folder 5. Follow the instructions, drivers will be installed automatically. ® 6. After installing the LAN driver, install Intel PROSet package (optional) 7. Open the Wired_PROSet_26.3_x64 folder 8. Run the Wired_PROSet_26.3_x64.exe file in the folder Acrosser Technology Co., Ltd. - Page 41 ACM-TGLUE0-Ax 9. Follow the instructions 10. Drivers will be installed automatically ® • Intel Active Management Technology Drivers (Windows 10) 1. Open the folder where you unzipped the Intel AMT Drivers 2. Drivers must be installed manually, refer to Windows guidance to complete steps. ®...
-
Page 42: Appendix
ACM-TGLUE0-Ax Appendix 5.1. I/O Information 5.1.1. I/O Address Map Acrosser Technology Co., Ltd. -
Page 43: Memory Address Map
ACM-TGLUE0-Ax 5.1.2. Memory Address Map 5.1.3. Large Memory Address Map www.acrosser.com... -
Page 44: Irq Mapping Chart
ACM-TGLUE0-Ax 5.1.4. IRQ Mapping Chart Acrosser Technology Co., Ltd. - Page 45 ACM-TGLUE0-Ax www.acrosser.com...
- Page 46 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
- Page 47 ACM-TGLUE0-Ax www.acrosser.com...
- Page 48 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
- Page 49 ACM-TGLUE0-Ax www.acrosser.com...
- Page 50 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
- Page 51 ACM-TGLUE0-Ax www.acrosser.com...
- Page 52 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
- Page 53 ACM-TGLUE0-Ax www.acrosser.com...
- Page 54 ACM-TGLUE0-Ax Acrosser Technology Co., Ltd.
-
Page 55: Faq
ACM-TGLUE0-Ax Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. www.acrosser.com... - Page 56 ACM-TGLUE0-Ax Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
- Page 57 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241402新北市三重區重新路5段609巷4號3樓之8 江苏省南京市江宁区天元东路228号504室 Rm. 8, 3F., No. 4, Ln. 609, Sec. 5, Chongxin Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241402, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
