Acrosser Technology AND-DNV3N1 Series User Manual

Networking micro box, intel denverton soc, 8 or 4 gbe copper 1-pair bypass, 2 sfp+
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AND-DNV3N1
Networking Micro Box
®
• Intel
Denverton
• 8 or 4 GbE Copper (1-pair bypass)
• 2 SFP+
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
®
SoC
AND-DNV3N1 Series
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AND-DNV3N1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acrosser Technology AND-DNV3N1 Series

Summary of Contents for Acrosser Technology AND-DNV3N1 Series

  • Page 1 AND-DNV3N1 Series AND-DNV3N1 Series Networking Micro Box ® ® • Intel Denverton • 8 or 4 GbE Copper (1-pair bypass) • 2 SFP+ User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AND-DNV3N1 Series Table of Contents 1. System Introduction ..............5 1.1. Model Description ....................... 5 1.2. Specifications ......................6 1.3. Package Contents ...................... 8 1.4. System Dissection ...................... 9 1.4.1. Dimensions ..................... 9 1.4.2. Front I/O Panel ....................10 1.4.3. Rear I/O Panel ....................11 2.
  • Page 4 Q 1. Where is the serial number located on my system? ..........45 Q 2. How to active the second SIM card SIERRA EM7455/EM7430 ? ......45 Q 3. How to active the second SIM card Quectel EM06-A/EM06-E 4G ? ......45 Acrosser Technology Co., Ltd.

  • Page 5: System Introduction

    AND-DNV3N1 Series System Introduction AND-DNV3N1 is an entry level networking appliance. In a small box, this appliance equip a powerful Intel Atom C3000 SoC. This SoC supports multi-core CPU computing and support QAT, USB 3.0 and LAN controller which can be 10GbE capable.

  • Page 6: Specifications

    Front Panel • 8x Ethernet Link/Act LED • 8x Ethernet 1000M LED • 2x SFP+ Link LED • 2x SFP+ Act LED • 1x Sys Power LED (12V) • 1x Storage LED • 1x LAN Bypass LED Acrosser Technology Co., Ltd.
  • Page 7 AND-DNV3N1 Series Rear Panel • 1x Reset button • 2x USB 3.0 • 1x RJ45 Console port • 2x SFP+(For C3558) • 8x or 4x GbE LAN (Copper) • 5x SMA for WLAN & WWAN (IEEE 802.11 a/b/g/n/ac & 4G LTE) •...

  • Page 8: Package Contents

    • IEC 60068-2-64, 5~500Hz, 3GRMS Drop Test • ISTA-2A 2006 1.3. Package Contents Check if the following items are included in the package. Item Q’ty AND-DNV3N1 System � Power Adapter (12V) � Power Cord � Screw Pack � Acrosser Technology Co., Ltd.

  • Page 9: System Dissection

    AND-DNV3N1 Series 1.4. System Dissection 1.4.1. Dimensions (Unit: mm) www.acrosser.com...

  • Page 10: Front I/O Panel

    LAN 1~8 IEEE802.3 Status LED LED Light Display Green Link with Activity Yellow 1000Mbps • SFP+ 1~2 SFP+ 1~2 Link/Active LED LED Light Display Green LINK LED Yellow ACTIVE LED • SIM CARD Standard SIM Card Socket Acrosser Technology Co., Ltd.

  • Page 11: Rear I/O Panel

    AND-DNV3N1 Series 1.4.3. Rear I/O Panel AND-DNV3N1-04F AND-DNV3N1-4C AND-DNV3N1-4C1 AND-DNV3N1-02 • WIFI 1~3, 4G 1~2 SMA Antenna Hole. Reserved for optional Wi-Fi / BT, 4G LTE antenna. • RESET Reset Button • DC 12V DC12V Power Input www.acrosser.com...
  • Page 12 Green (Blink) Link with Activity 10Mbps Right Yellow 100Mbps Green 1000Mbps • SFP1 ~ SFP2 Standard SFP+ Connector for 10G LAN • Console Console Port (RJ45) Pin # Signal Pin # Signal • Standard USB Port Acrosser Technology Co., Ltd.

  • Page 13: Components Assembly

    AND-DNV3N1 Series Components Assembly Please follow the instruction to install the inner modules. 2.1. SIM Card Installation Step 1: Remove the screw on the SIM Card cover plate. Step 2: Take down the SIM Card cover plate. Step 3: Insert the SIM card .
  • Page 14 Step 4: Push the SIM card into the socket until it docks in locked position. Step 5: Put the the SIM Card cover plate back. Step 6: Lock the SIM Card cover plate with screw . Acrosser Technology Co., Ltd.

  • Page 15: Open Up Top Cover

    AND-DNV3N1 Series 2.2. Open up Top Cover Step 1: Remove the screw that lock the bottom cover. Bottom Cover Step 2: Remove the screws that lock at the front side . Step 3: Push forward the top cover to open it.
  • Page 16 AND-DNV3N1 Series Step 4: Opem up the top cover. Acrosser Technology Co., Ltd.

  • Page 17: Memory Module Installation

    AND-DNV3N1 Series 2.3. Memory Module Installation Step 1: Insert the memory module into the slot. www.acrosser.com...
  • Page 18 AND-DNV3N1 Series Step 2: Push the module down into the slot until it docks in locked position. Acrosser Technology Co., Ltd.

  • Page 19: Wifi Module Installation

    AND-DNV3N1 Series 2.4. 4G & WiFi Module Installation Step 1: Insert the 4G module into socket and lock with screw. Step 2: Connect with RF Cables. www.acrosser.com...
  • Page 20 Step 4: Connect with RF Cables. Step 5: Insert antennas according to the panel allocation . 4G 1, 4G 2 attach with 4G LTE antenna . WiFi 1, WiFi 2, and WiFi 3 attach with WiFi antenna. Acrosser Technology Co., Ltd.

  • Page 21: Hard Disk & Top Cover Installation

    AND-DNV3N1 Series 2.5. Hard Disk & Top Cover Installation Step 1: Install hard disk with screws through the cushsion pad onto the disk bracket . Step 2: Connect with SATA and POWER cables. Step 3: Take care the cables not to tangle with the heatsink.
  • Page 22 Step 4: Use cable tie to bundle SATA cable and power cable. Step 5: Close the top cover. Push the top cover inward until it docks into the slot. Step 6: Lock the chassis with screws. Acrosser Technology Co., Ltd.

  • Page 23: Bios Settings

    AND-DNV3N1 Series BIOS Settings This chapter describes the BIOS menu displays and explains how to perform common tasks needed to get the system up and running. It also gives detailed explanation of the elements found in each of the BIOS menus. The following topics are covered: •...
  • Page 24 System Time using the arrow keys. Enter new values using the keyboard. Press the key or the arrow keys to move between fields. The date must be entered in MM/DD/ YYYY format. The time is entered in HH:MM:SS format. Acrosser Technology Co., Ltd.

  • Page 25: Advanced Setup

    AND-DNV3N1 Series 3.2. Advanced Setup Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Main Advanced IntelRCSetup Security Boot Save & Exit OnBoard Bypass Controller OnBoard Bypass Controller W83627DHG Super IO Configuration W83627DHG HW Monitor Serial Port Console Redirection...

  • Page 26: Advanced Setup: W83627Dhg Super Io Configuration

    Change Settings [Auto] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2020 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 27: Advanced Setup: W83627Dhg Hw Monitor

    AND-DNV3N1 Series • Serial Port Select Enabled to enable the onboard serial port. • Change Settings This option specifies the base I/O port address and the interrupt Request address of Serial Port. Select [Auto] to let the BIOS automatically assign the base l/O and IRQ address.
  • Page 28 If CPU temp ishigherer than target temp+tolerance, the fan will run at full fan speed. [Manual Mode] : You can set fixed fan speed. • FAN Target Temperature Input a target temperature between 0 ~ 127°C. • FAN Tolerance Input a target temperature tolerance. Acrosser Technology Co., Ltd.

  • Page 29: Advanced Setup: Serial Port Console Redirection

    AND-DNV3N1 Series 3.2.4. Advanced Setup: Serial Port Console Redirection Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Advanced Console Redirection COM0 Enable or Disable. Console Redirection [Enabled] Console Redirection Settings →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt.
  • Page 30 Use this item to enable or disable Recorder Mode to capture terminal data and send it astext messages. • Resolution 100x31 Use this item to enable or disable extended terminal resolution support. • Putty KeyPad Use this item to select Function Key and Keypad on Putty. Acrosser Technology Co., Ltd.

  • Page 31: Advanced Setup: Network Stack Configuration

    AND-DNV3N1 Series 3.2.5. Advanced Setup: Network Stack Configuration Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Advanced Network Stack [Enabled] Enable/Disable UEFI Ipv4 PXE Support [Disabled] Network Stack Ipv4 HTTP Support [Disabled] Ipv6 PXE Support [Disabled] Ipv6 HTTP Support...

  • Page 32: Advanced Setup: Csm Configuration

    Use this item to control the Legacy/UEFI memory sequence. Options are: [UEFI and Legacy], [Legacy only], [UEFI only]. • Network This item provides control of the operation UEFI and regular PXE/Storage/Video, ramdomly read memory (OpROM). Options are: [UEFI], [Legacy], [Do not Launch]. Acrosser Technology Co., Ltd.

  • Page 33: Advanced Setup: Usb Configuration

    AND-DNV3N1 Series 3.2.7. Advanced Setup: USB Configuration Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option USB Module Version disables legacy support if no USB devices are Boot option filter [UEFI only] connected.

  • Page 34: Intelrcsetup

    [Enable] [Enable] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2020 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 35: Intelrcsetup: South Bridge Chipset Configuration

    AND-DNV3N1 Series • Turbo This feature allows processor cores to run faster than marked frequency in specific conditions. • Enable or Disable Intel Virtual Machine Extensions (VMX) for IA-32 processors that ® support Intel Vanderpool Technology. 3.3.2. IntelRCSetup: South Bridge Chipset Configuration Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc.

  • Page 36: Intelrcsetup: Sata Port

    SKU. →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2020 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 37: Security Setup

    AND-DNV3N1 Series • Enable/disable port Enables/Disables SATA Controller port if supported by current cpu SKU. 3.4. Security Setup Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Main Advanced IntelRCSetup Security Boot Save & Exit Password Description Reset the system after saving the changes.

  • Page 38: Boot Setup

    OEM logo instead of the normal POST messages. • Boot Option Priorities This feature allows the user to specify which devices are boot devices and the order of priority from which the systems boots from during startup. Acrosser Technology Co., Ltd.

  • Page 39: Save & Exit Setup

    AND-DNV3N1 Series 3.6. Save & Exit Setup Aptio Setup Utility - Copyright (C) 2020 American Megatrends, Inc. Main Advanced IntelRCSetup Security Boot Save & Exit Save Options Reset the system after Save Changes and Reset saving the changes. Discard Changes and Reset...

  • Page 40: Software Installation And Programming Guide

    4.1.1. Environment This test utility develop is based on kernel 4.8 above (Ubuntu 18.04.1 Server 64bit). 4.1.2. GPIO The AND-DNV3N1 series provides GPIO interface. Users can use the GPIO APIs to control GPO Pin. 4.1.3. Watchdog The AND-DNV3N1 series provides a Watchdog Timer. Users can use the Watchdog APIs to configure and to access the Watchdog timer.

  • Page 41: File Descriptions

    AND-DNV3N1 Series 4.2. File Descriptions 4.2.1. GPIO/Watchdog/LAN Bypass Subsystem Module 1. TestUtility.exe The GPIO, Watchdog, Lan Bypass Subsystem bin binary. 2. Libw83627.h This file includes the declarations of the APIs and macro definitions. 3. Libw83627.a The static library for linux.

  • Page 42: Watchdog

    16 character array. Return Value: 0: Successful, -1: fail. Syntax: int set_bypass_wdt(int pair, int time) Description: This function can set which pair bypass Wdt timer. Parameters: pair: 1-4 , time: 1-255(sec), 0:stop. Return Value: 0: Successful, -1: fail. Acrosser Technology Co., Ltd.
  • Page 43 AND-DNV3N1 Series Syntax: int set_bypass_wdt_action(int pair, int action) Description: This function can set which pair bypass Wdt time up action. Parameters: pair: 1-4 , action: 0:bypass, 1:normal Return Value: 0: bybpass, 1: normal, -1: fail. Syntax: int get_bypass_wdt_action(int pair) Description: This function can get which pair bypass Wdt time up action.

  • Page 44: Notes

    Parameters: None. Return Value: None. Note: If you want to control the LAN module bypass on the LAN card purchased from Accrosser, be sure to take “7” Module H as the module reference for programming. Acrosser Technology Co., Ltd.

  • Page 45: Faq

    AND-DNV3N1 Series Q 1. Where is the serial number located on my system? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) Q 2. How to active the second SIM card SIERRA EM7455/EM7430 ? •...
  • Page 46 AND-DNV3N1 Series • AT+QDSIM? +QDSIM: 1 //Enable SIM error reports • The configuration will be automatically saved to NVRAM. • This function takes effect after restart. Acrosser Technology Co., Ltd.
  • Page 47 AND-DNV3N1 Series Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 48 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
