ANR-ICEDA1
ANR-ICEDA1
1U Rackmount Network Appliance
®
®
• Intel
Xeon
D-1713NT Processor
(ICE-Lake-D LCC Platform)
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANR-ICEDA1 and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology ANR-ICEDA1

Summary of Contents for Acrosser Technology ANR-ICEDA1

  • Page 1 ANR-ICEDA1 ANR-ICEDA1 1U Rackmount Network Appliance ® ® • Intel Xeon D-1713NT Processor (ICE-Lake-D LCC Platform) User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    ANR-ICEDA1 Table of Contents 1. Product Specifications ..............5 1.1. Specifications ......................5 1.2. Package Contents ...................... 7 2. Hardware Information ..............8 2.1. Dimensions ......................... 8 2.2. Jumpers and Connectors ..................11 2.3. List of Jumpers ......................12 2.3.1. Clear CMOS (CN5) ..................12 2.4.
  • Page 4 3.6.1.1. Key Management ................48 3.7. Setup submenu: Boot ....................49 3.8. Setup submenu: Save & Exit ..................50 4. FAQ ....................51 Q 1. Where is the serial number located on my system? ..........51 Acrosser Technology Co., Ltd.

  • Page 5: Product Specifications

    ANR-ICEDA1 Product Specifications ® The ANR-ICEDA1 is an 1U rackmount network appliance product. Powered by Intel ® ® Xeon D-1713NT Processor (Intel code name “Ice Lake”) and runs on Intel with integrated Ethernet in high-density Ball-Grid Array packages, it delivers server- class computing, hardware-based security, and high-bandwidth I/Os for networking applications at the edge.
  • Page 6 • 1.5 g rms/ 5 ~ 500Hz / non operation Shock • 10 G peak acceleration (11 m sec. duration), operation • 20 G peak acceleration (11 m sec. duration), non- operation Certification • CE / FCC class A Acrosser Technology Co., Ltd.

  • Page 7: Package Contents

    ANR-ICEDA1 1.2. Package Contents Check if the following items are included in the package. Item Q’ty Remark ANR-ICEDE0 � Console cable � Ear bracket (pair) � SATA cable � SATA power cable � HDD kit � www.acrosser.com...

  • Page 8: Hardware Information

    ANR-ICEDA1 Hardware Information 2.1. Dimensions (Unit: mm) System: Acrosser Technology Co., Ltd.
  • Page 9 Board ANR-ICEDA1 Component Side Component Side: www.acrosser.com...
  • Page 10 ANR-ICEDA1 Solder Side Solder Side: Acrosser Technology Co., Ltd.

  • Page 11: Jumpers And Connectors

    Jumpers and Connectors ANR-ICEDA1 Component Side 2.2. Jumpers and Connectors Component Side: www.acrosser.com...

  • Page 12: List Of Jumpers

    1Gb RJ45 Port CN20 M.2 B-Key slot CN21 Micro SIM CN22 M.2 E-Key slot CN23 USB3.1 + RJ45 Connector (IPMI Ethernet) CN24 Serial Port CN25, CN27 FAN1/FAN2 CN26, CN28 CN30 Console CN31, CN32 ATX Power Connector Acrosser Technology Co., Ltd.

  • Page 13: Battery Holder (Cn4)

    ANR-ICEDA1 Label Function M1, M2, M3, M4 10Gb SFP+ M1, M2, M3, M4 10Gb SFP+ SATA1, SATA2, SATA3 SATA Connector SATA1, SATA2, SATA3 SATA Connector IPMI1 IPMI Slot Software Programmable Button Note 1: Bypass Function on CN13. Note 2: PCIe*8 on GF1 is for NIM riser card PER-R40X only, not for standard PCIe signal.

  • Page 14: B-Key Slot (Cn20)

    2.4.5. M.2 B-Key Slot (CN20) Pin # Signal Pin # Signal CFG3 +3.3V +3.3V PWR_OFF USB2DN W_DISABLE USB2DP CFG0 PCIE1RXP UIMRST PCIE1RXN UIMCLK UIMDAT PCIE1TXN UIMPWR PCIE1TXP DEVSLP PCIE0RXP PCIE0RXN PCIE0TXN PCIE0TXP PLTRST# PCIECLKDN WAKE# PCIECLKDP SIMDET 32K_SUSCLK CFG1 +3.3V Acrosser Technology Co., Ltd.

  • Page 15: E-Key Slot (Cn22)

    ANR-ICEDA1 Pin # Signal Pin # Signal +3.3V +3.3V CFG2 2.4.6. M.2 E-Key Slot (CN22) Pin # Signal Pin # Signal +3.3V +3.3V PCIE0TXP PCIE0TXN PCIE0RXP PCIE0RXN PCIECLK0DP PCIECLK0DN 32K_SUSCLK PLTRST# CLKREQ# DIS2# WAKE# DIS1# PCIE1TXP PCIE1TXN www.acrosser.com...

  • Page 16: Serial Port (Cn24)

    ANR-ICEDA1 Pin # Signal Pin # Signal PCIE0RXP PCIE0RXN PCIECLK1DP +3.3V PCIECLK1DN +3.3V 2.4.7. Serial Port (CN24) Pin # Signal Pin # Signal DCD2 DSR2 RXD2 RTS2 TXD2 CTS2 DTR2 Acrosser Technology Co., Ltd.

  • Page 17: Hardware Installation

    ANR-ICEDA1 2.5. Hardware Installation This section details the hardware assembly steps for the ANR-ICEDA1. Please read this section thoroughly before beginning installation and ensure you have all necessary components ready. A Phillips head screwdriver is required. 2.5.1. 2.5” Hard Disk Drive Installation Step 1: Unscrew the upper lid.
  • Page 18 ANR-ICEDA1 Step 4: Connect the SATA cable and power cable to the main board. Step 5: Connect the SATA cable and power cable into the Hard Disk and put hard drive bracket on the chassis. Acrosser Technology Co., Ltd.
  • Page 19 ANR-ICEDA1 Step 6: Connect the SATA cable and power cable into the Hard Disk and put hard drive bracket on the chassis. www.acrosser.com...

  • Page 20: Heat Sink Installation

    ANR-ICEDA1 2.5.2. Heat Sink Installation Step 1: Loosen the screw and remove the fan duct. Step 2: Cover the Heatsink on the CPU and ensure the direction of the Heatsink does not obstruct the airflow. Acrosser Technology Co., Ltd.

  • Page 21: Nim Installation

    ANR-ICEDA1 Step 3: Fasten the screw to lock the air duct. 2.5.3. NIM Installation Step 1: Loosen the screws on the bottom of chassis. www.acrosser.com...
  • Page 22 ANR-ICEDA1 Step 2: Remove the null Module cover or existing LAN module. Step 3: Insert the LAN Module and fasten the screws. Acrosser Technology Co., Ltd.

  • Page 23: Ami Bios Setup

    ANR-ICEDA1 AMI BIOS Setup 3.1. System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal. The system can usually continue the boot up sequence with non-fatal errors.

  • Page 24: Setup Submenu: Main

    ANR-ICEDA1 3.3. Setup Submenu: Main ARM-ICEDA1 V1.0 (xx/xx/2023) 3.4. Setup Submenu: Advanced Acrosser Technology Co., Ltd.

  • Page 25: Trusted Computing

    ANR-ICEDA1 3.4.1. Trusted Computing • Security Device Support Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. • SHA-1 PCR Bank Enable or Disable SHA-1 PCR Bank •...

  • Page 26: Hardware Monitor

    TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 devices, Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. 3.4.2. Hardware Monitor Acrosser Technology Co., Ltd.

  • Page 27: System Fan Setting

    ANR-ICEDA1 3.4.3. System Fan Setting • Manual PWM Setting Fan will work with this Manual PWM Value. www.acrosser.com...

  • Page 28: Sio Configuration

    Fan will full speed when temperature higher than this limit. • Fan start PWM Fan will full start with this PWM value. • PWM SLOPE SETTING PWM SLOPE Selection. Slope = PWM value / °C 3.4.4. SIO Configuration Acrosser Technology Co., Ltd.

  • Page 29: Serial Port 0 Configuration

    ANR-ICEDA1 3.4.5. Serial Port 0 Configuration • Use This Device Enable/Disable this Logical Device. • Possible Allow user to change Device’s Resource settings. New settings will be reflected on This Setup Page after System restarts. www.acrosser.com...

  • Page 30: Serial Port 1 Configuration

    ANR-ICEDA1 3.4.6. Serial Port 1 Configuration • Use This Device Enable/Disable this Logical Device. • Possible Allow user to change Device’s Resource settings. New settings will be reflected on This Setup Page after System restarts. Acrosser Technology Co., Ltd.

  • Page 31: Parallel Port Configuration

    ANR-ICEDA1 3.4.7. Parallel Port Configuration • Use This Device Enable/Disable this Logical Device • Possible Allow user to change Device’s Resource settings. New settings will be reflected on This Setup Page after System restarts. • Mode Change Parallel Port mode. Some of the Modes required a DMA resource. After Mode changing, Reset the System to reflect actual device settings.

  • Page 32: Serial Port Console Redirection

    ANR-ICEDA1 3.4.8. Serial Port Console Redirection • Console Redirection Console Redirection Enable or Disable. • Console Redirection EMS Console Redirection Enable or Disable. Acrosser Technology Co., Ltd.

  • Page 33: Console Redirection Settings

    ANR-ICEDA1 3.4.9. Console Redirection Settings • Terminal Type Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.

  • Page 34: Legacy Console Redirection Settings

    Enables or disables extended terminal resolution. • Putty KeyPad Select FunctionKey and KeyPad on Putty. 3.4.10. Legacy Console Redirection Settings • Redirection COM Port Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. Acrosser Technology Co., Ltd.

  • Page 35: Power Management

    ANR-ICEDA1 • Resolution On Legacy OS, the Number of Rows and Columns supported redirection. 3.4.11. Power Management • Power Mode Select power supply mode. • Restore AC Power Loss Select power state when power is re-applied after a power failure.

  • Page 36: Digital Io Port Configuration

    ANR-ICEDA1 3.4.12. Digital IO Port Configuration • Set DIO as Input or Output. • Output Level Set output level when DIO pin is output. Acrosser Technology Co., Ltd.

  • Page 37: Lan Bypass Configuration

    ANR-ICEDA1 3.4.13. LAN Bypass Configuration • Lan Bypass Status LED Configure LAN Bypass status LED. • Mode for Power-on Configure LAN kit behavior when system is in power-on state. (Bypass/Pass Through) • Mode for Power-off Configure LAN kit behavior when system is in power-off state. (Bypass/Pass Through) •...

  • Page 38: Case Open Configuration

    ANR-ICEDA1 3.4.14. Case Open Configuration • Case Open Warning Case Open detecting function. Acrosser Technology Co., Ltd.

  • Page 39: Setup Submenu: Chipset

    ANR-ICEDA1 3.5. Setup submenu: Chipset 3.5.1. PCH-IO Configuration www.acrosser.com...

  • Page 40: Sata Configuration

    ANR-ICEDA1 3.5.2. SATA Configuration 3.5.3. Controller 3 SATA Configuration • SATA Configuration SATA test setting Acrosser Technology Co., Ltd.

  • Page 41: General Me Configuration

    ANR-ICEDA1 3.5.4. General ME Configuration 3.5.5. Socket Configuration www.acrosser.com...

  • Page 42: Processor Configuration

    ANR-ICEDA1 3.5.6. Processor Configuration • Hyper-Threading [ALL] Enables Hyper Threading (Software Method to Enable/Disable Logical Processor threads. 3.5.7. Memory Configuration Acrosser Technology Co., Ltd.

  • Page 43: Memory Topology

    ANR-ICEDA1 3.5.8. Memory Topology 3.5.9. IIO Configuration www.acrosser.com...

  • Page 44: Socket0 Configuration

    ANR-ICEDA1 3.5.10. Socket0 Configuration • IOU0 (IIO PCIe Port 1) Selects PCIe port Bifurcation for selected slot(s). 3.5.11. Advanced Power Management Configuration Acrosser Technology Co., Ltd.

  • Page 45: Hardware Pm State Control

    ANR-ICEDA1 3.5.12. Hardware PM State Control • Hardware P-States Disable: Hardware chooses a P-state based on OS Request (Legacy P-States). Native Mode: Hardware chooses a P-state based on OS guidance. Out of Band Mode: Hardware autonomously chooses a P-state (no OS guidance).

  • Page 46: Setup Submenu: Security

    Press Enter again to set the password. • Removing the Password Select the password you want to remove and enter the current password. At the next dialog box press Enter to disable password protection. Acrosser Technology Co., Ltd.

  • Page 47: Secure Boot

    ANR-ICEDA1 3.6.1. Secure Boot • Secure Boot Secure Boot feature is Active if Secure Boot is Enabled, Platform Key (PK) is enrolled, and the System is in User mode. The mode change requires platform reset. • Secure Boot Mode In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication.

  • Page 48: Key Management

    Enroll SHA256 Hash certificate of a PE image into Authorized Signature Database (db) • Secure Boot VariableS Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) Acrosser Technology Co., Ltd.

  • Page 49: Setup Submenu: Boot

    ANR-ICEDA1 c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image (SHA256) Key Source: Default, External, Mixed 3.7. Setup submenu: Boot • Quiet Boot Enable / Disable Quiet Boot option. • Network Stack Enable/Disable UEFI Network Stack.

  • Page 50: Setup Submenu: Save & Exit

    ANR-ICEDA1 3.8. Setup submenu: Save & Exit Acrosser Technology Co., Ltd.

  • Page 51: Faq

    ANR-ICEDA1 Q 1. Where is the serial number located on my system? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) www.acrosser.com...

  • Page 52: Technical Support Form

    ANR-ICEDA1 Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
