GL412/422– Quick Card
Same coloured solid lines indicate the buttons have to be pressed simultaneously
Sensitivity Selection
Wind mode (Default)
and High sensitive (S)
Mask Mode
First one arrow button
then within <1 sec
the manual button
Manual Mode On/Off
Red Manual LED
flashes once a second
Changing grade value
Arrow button Up/Down => Y-Axis;
Reight/Left => X-Axis (GL522)
Standby Mode On/Off
Press and hold 3 seconds
Red LED flashes every 4 sec.
Trimble Construction Tools Division
8261 State Route 235
Dayton, Ohio 45424-6383
U.S.A.
+1 937 245 5600 Phone
Advertisement
Related Manuals for Spectra GL412
Summary of Contents for Spectra GL412
- Page 1 GL412/422– Quick Card Same coloured solid lines indicate the buttons have to be pressed simultaneously Sensitivity Selection Changing grade value Wind mode (Default) Arrow button Up/Down => Y-Axis; and High sensitive (S) Reight/Left => X-Axis (GL522) Mask Mode First one arrow button then within <1 sec...
- Page 2 Manual Grade Match (Y-axis), Rotation Speed Press and release 2 times; 300, 600 and (0 rpm – GL422) G appears at LCD (GL422), manual and leveling LEDs flash Fine alignment of the stopped simultaneously and both grade beam with sighting guides (GL422) values will be set to 0% Pairing Laser with Remote control...
