- Page 2 DG813 DG613/DG613G ST802 SF803 RC803...
- Page 3 Standard Display Laser and RC803 RC803 Radio/IR Remote Control Powering the RC803 Turning On/Off the Radio/IR Remote Control Pairing the RC803 with the DG813/DG613/DG613G Components SpotFinder SF803 Powering the SF803 SF803 - Features and Functions Pairing the Spot Finder SF803 with the DG813...
- Page 4 Settings Info Service Setting menu details Grade Entry Grade Display Sensitivity Selection User Name Set Password Password On/Off Radio Channel Select Language Position Info Calibration PROTECTING THE UNIT CLEANING AND MAINTENANCE PROTECTING THE ENVIRONMENT TECHNICAL DATA DECLARATION OF CONFORMITY...
- Page 5 Introduction Thank you for choosing one of the Spectra Precision Lasers from the Trimble family of precision pipe lasers. The pipe laser is an easy-to-use tool that provides underground contractors line, elevation, and grade control for installing storm, sanitary, or other gravity-flow pipe. This system can also be used for tunneling, boring, pipe alignment, or any other application requiring line, elevation, and grade control.
- Page 6 Features and Functions Laser 12 Power Button 1 Battery Compartment 13 M - Menu Button 2 Battery Door Latches 14 E - Enter Button 3 LCD Graphic Display 15 Escape/Lock Button 4 Grade Axis Pivot Marker 16 Left Line Control Button 5 Line-Axis Pivot Marker and LED 17 Plus Button 6 Handle...
- Page 7 Powering the Laser Recharging the Batteries The laser is shipped with a rechargeable Ni-MH battery pack, it is keyed to prevent mis-insertion. Note: The approximate charge of the batteries is shown at the top of the LCD when pressing the E button. The charger requires approx.
- Page 8 Features and Functions 1. Battery Compartment – holds the NiMH battery pack. (D-Cell alkaline batteries can be used as a backup.) 2. Battery Door Latches – locks/unlocks and holds the battery compartment in place. 3. LCD Graphic Display - shows the power, grade, battery, out-of-level, beam position and status of the laser.
- Page 9 Features and Functions 7. Axis Alignment Markers - used to align the laser when the line system is centered. 8. Mounts for scope adapter – attach the optional scope adapter for the „Over the Top“ application 9. 5/8”-11 Threaded Mount – to attach the laser to various setup accessories 10.
- Page 10 Features and Functions 12. Power Button - turns the laser On/Off (To turn off the laser, press and hold the button for 2 seconds). 13. M – Menu Button - Quickly press and release starts the menu entry. Use the 2 to 5 buttons to toggle through the menu.
- Page 11 Features and Functions 16. Left Line Control Button - moves the laser beam to the left. (Simultaneously pressed with the Right Line Button, centers the line.) 17. Plus Button - increases the grade. 18. Minus Button - decreases the grade. 19.
- Page 12 Laser Setup Position the laser at the manhole invert or on bottom of the trench at the desired elevation. Turning On/Off the laser Press the power button to turn On the laser; the LCD shows Initialization for one second (red and green LEDs are on - diagnostic mode).
- Page 13 Features and Functions Standard Display Laser and RC803 The remote control mirrors the functionality of the pipe laser keypad Automatic mode Beam line position related to the housing +/- buttons locked actual grade value line buttons locked Beam position at SF803 1 - Escape/Lock Button 2 - Left Line Control Button 3 - Plus Button...
- Page 14 To turn off the radio remote control, press and hold the power button for two seconds. Note: 5 minutes after the last button press, the remote control turns off automatically. Pairing the RC803 with the DG813/DG613/DG613G - First, make sure the transmitter and the remote control are turned off.
- Page 15 Components Spot Finder SF803 1 - SF803 2 - Target Plate for Spot Finder 3 - Center Hole 4 - Power Button 5 - Bubble Vial 6 - Battery LED 7 - Mode LED 8 - Red Direction LEDs 9 - IR transmitters/receivers 10 - Marking notches (front and back) 11 - M6 Clamp Mount 12 - Battery door...
- Page 16 Powering the SF803 1. Open the battery door pulling the battery door latch. The SF803 will be shipped with alkaline batteries. Rechargeable batteries can be used optional but need to be charged externally 2. Insert four AA batteries noting the plus (+) and minus (-) diagrams inside on the battery door. 3.
- Page 17 OK / yellow flashing: none or lost radio signal Pairing the Transporter ST802 with the DG813 /DG613/DG613G First, make sure the transmitter and the Transporter are turned off. Then press and hold the Escape/Lock button and turn on the transmitter.
- Page 18 Transporter ST802 – DG applications DG813/613/613G at the manhole => ST802 => RC803 ST802 offers radio connection between RC803 and DG813/613/613G also inside the open trench at the end of the pipe. up to 100 m /330 ft DG813/613/613G at the tripod => ST802 => RC803 ST802 extends the radio operating range between DG813/613/613G and RC803 working at „Over the Top“...
- Page 19 Press and release the 2 to 5 buttons until the desired function at the selected menu row is marked. Press and release button E to open the submenu OR start the selected function. Menu functions available at the DG813 Menu functions available at the DG613/DG613G...
- Page 20 Note: If a remote is paired with a transmitter the IR signals of the remote (in case of an interrupted radio connection) will be transmitted in a private mode so that only the paired transmitter can receive these IR commands. IR-menu functions available at the DG813 IR-menu functions available at the DG613/DG613G...
- Page 21 – changing the grade value in Step + Go or Digit Select mode. Entering Grade Press and release the M (Menu) button; Grade Edit will be highlighted. Press/release button E The grade value will be shown. Press/release button M escape/return to the standard display. Note: when ‘Step + Go Mode’...
- Page 22 Automatic Spot Align (only DG813) - The Spot Finder SF803 guides the beam to the target point in the horizontal axis, while the Z-axis grade value will be maintained. Press and release the M button at the standard display and select Spot Align using the (+)/(-) and left/right buttons.
- Page 23 Automatic Spot Match (only DG813) - Automatic-Spot-Match can be used for measuring an unknown grade value in an existing pipe or open trench. Press and release the M button at the standard display and select Spot Match using the (+)/(-) and left/right buttons. Press/release button M ...
- Page 24 Manual Spot Search Mode (only DG813) - The Spot Search mode is used for pipe laying by detecting the beam manually using the Spot Finder SF803 and can be activated in automatic and manual mode. Using the “Over the Top” application, the Spot Finder detects the fan beam while the remote control’s display provides the information to position the pipe correctly at the required direction and elevation.
- Page 25 Line Scan - For a faster second day setup, line scan enables complete automatically movement of the laser beam to the left and right limits. Press and release the M button at the standard display and select Line Scan using the (+)/(-) and left/right buttons. Press/release button M ...
- Page 26 Start Reference Check – Before starting some sensitive pipe work, an additional Reference Check can be started manually. Press and release the M button at the standard display and select Reference Check using the (+)/(-) and left/right buttons. Press/release button M escape/return to the standard display. Pressing and releasing E button starts the Reference Check considering the current temperature inside the housing.
- Page 27 Settings – offers the different setting features. Please see the Setting Menu details at the following pages. Info - The DG/RC information (software version, ID, etc.) or the runtime of the DG will be displayed. Press and release the M button at the standard display and select Info using the (+)/(-) and left/right buttons.
- Page 28 Setting Menu Details – offers the different setting features. Press and release the M button at the standard display and select Settings using the (+)/(-) and left/right buttons. Press/release M button escape/return to the standard display. Pressing and releasing E button opens the Setting’s menu. (+) / (-) and left/right buttons can be used to select the desired Setting function then press button E to open the selected submenu.
- Page 29 Sensitivity Selection – offers three different sensitivity options. Press and release left/right buttons until Sensitivity is displayed. Press/release M button escape/return to the main menu. Pressing and releasing E button opens the submenu. Use the left/right buttons to toggle between Low, Mid (Default) and High. Press the E button to confirm the selection.
- Page 30 User Name – offers the activation of the user name. Press and release (+)/(-) and left/right buttons until User Name is displayed. Press/release M button escape/return to the main menu. Pressing and releasing E button opens the submenu; cursor flashes. Use the ESC button to toggle between both lines.
- Page 31 Password ON/OFF – activating/deactivating Password function. Press and release (+)/(-) and left/right buttons until Password On/Off is displayed. Press/release M button escape/return to the main menu. Pressing and releasing E button opens the submenu. Use the left/right buttons to toggle between Password On and Password Off. Press the E button to confirm the selection.
- Page 32 Select Language – offers language selection for main menu text. Press and release (+)/(-) and left/right buttons until Language is displayed. Press/release M button escape/return to the main menu. Pressing and releasing E button opens the submenu. Use the (+)/(-) and left/right buttons to toggle between the different language options. Press the E button to confirm the selection.
- Page 33 Troubleshooting DG813/DG613/DG613G Any error message can be deleted with a short press of the E button. The table shows the related description and possible solutions. The next service center should be contacted if a different error message as shown at the table will be displayed.
- Page 34 Calibration Checking Calibration...
- Page 35 Checking the calibration of your pipe laser is easy. All you need is an engineer’s rule and your pipe laser. 1. Select a level road, packing lot or field whose rise is not more than 4 inches in 100 feet (10 cm/30 m).
- Page 36 8. Accurately measure the elevation to the center of the beam at point B and record the elevation as B1. 9. Move the pipe laser behind point B and aim the laser beam so that it passes over points A and B. Allow the pipe laser to self-level.
- Page 37 Grade Check After the first 25 – 50 feet (8 – 15 m) of pipe has been laid, it is recommended that you make a grade check to insure that the setup is correct, and that the system is properly operating. The illustration shows a method for checking grade.
- Page 38 Example: Feet / Tenths Metric Rod Reading at “A” 15.74 feet 4.801 m Rod Reading at “B” 12.289 feet 3.749 m Rise or Difference (A – B) 3.451 feet 1.052 m Distance from A to B 145 feet 44.196 m Rise divided by Run 0.0238 0.0238...
- Page 39 PROTECTING THE UNIT Do not expose the unit to extreme temperatures or temperature changes (do not leave inside the car). The unit is very robust and can resist damage if dropped even from tripod height. Before continuing your work, always check the leveling accuracy. See Checking Calibration section. The laser is water proof and can be used indoors and outdoors.
- Page 40 Warranty Trimble warrants the DG813/DG613 to be free of defects in material and workmanship for a period of five years (DG613G: 3 years). Trimble or its authorized service center will repair or replace, at its option, any defective part, or the entire product, for which notice has been given during the warranty period. If required, travel and per diem expenses to and from the place where repairs are made will be charged to the customer at the prevailing rates.
- Page 41 ± 1.5 mm/30 m, 1/16“ @ 100 ft, 10 arc seconds Accuracy, Self-Leveling (level) Operational area up to 150 m (500 feet) Laser type: DG613/DG813: 600 - 680 nm DG613G: 510 – 540 nm Laser class : Class 3A/3R, <5mW OR class 2 Self-leveling range:...
- Page 42 TECHNICAL DATA Remote Control RC803 1,4,5 Radio operating range (Over the Top) up to 130 m (425 ft) IR operating range (front) up to 150 m (500 ft) Power source: 2 x 1.5V AA alkaline batteries Battery life 130 hours Dust and Water proof: IP66 Weight (incl.
- Page 43 Following is the valid declaration: Trimble Kaiserslautern GmbH Declare under our sole responsibility that the products DG813/DG613/DG613G and RC803; SF803; ST802 To which this declaration relates is in conformity with the following directives: EMC 2014/30/EU, RED 2014/53/EU, RoHS 2011/65/EU Relevant harmonized standards: EN 55014-1:2006 + A1:2009 + A2:2011, EN 55014-2:1997 + A1:2001 + A2:2008, EN 60825-1:2014, EN 60950- 1:2006 + Amdts, ETSI EN 301 489-01 V1.9.2, ETSI EN 301 489-17 V2.2.1...
- Page 44 FCC / IC General information 4131A-TK46BL FCC ID PWR-TK46BL Contains IC: 4131A-TK42RF Contains FCC ID: PWR-TK42RF This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 45 FCC Compliance Statement: FCC Compliance Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
