DG511 – Quick Card
Same coloured dashed lines indicate the
buttons have to be pressed simultaneously
Display shows - LASER ON
DG511 => inside self-leveling range
Roll Right and Roll Left - direction for correct setup
Left Line Control Button
Line Position
Press and hold,
related to the housing
faster movement after 6 Sec.
Right Line Control Button
Press and hold,
Backlight/Lock Button
faster movement after 6 Sec.
On / Off
On / Off
Lock / Unlock function
Quick => Battery-/Statusdisplay
One of the arrow buttons or
+ / – button with
Turn Off => press and hold for
Line Center
Backlight/Lock button
2 seconds
Press and hold quickly
PN 022507-202
