Page 1: Table Of Contents
TABLE OF CONTENTS Introduction FOR YOUR SAFETY COMPONENTS How to use the Laser System Powering the Laser RC602 Radio Remote Control Turning On/Off the RC602 LASER SETUP Turning On/Off the Laser Features and functions Standard Features X-Y-grade entering mode Using the Rotation mode Manual mode Special MENU Features Menu Functions (Radio controlled) -
Page 2: Introduction
Introduction Thank you for choosing one of the Spectra Precision Lasers from the Trimble family of precision lasers. The grade laser is an easy-to-use tool that offers accurate horizontal, vertical and sloped laser reference up to 1300 ft (400 m) away using a receiver. -
Page 3: How To Use The Laser System
HOW TO USE THE LASER SYSTEM POWERING THE LASER Batteries WARNING Ni-MH batteries may contain small amounts of harmful substances. Be sure to charge the battery before using it for the first time, and after not using it for an extended length of time. Charge only with specified chargers according to device manufacturer‘s instructions. Do not open the battery, dispose of in fire or short circuit; it may ignite, explode, leak or get hot causing personal injury. Dispose in accordance with all applicable federal, state, and local regulations. Keep the battery away from children. If swallowed, do not induce vomiting. Seek medical attention immediately Recharging the Batteries The laser is shipped with a rechargeable Ni-MH battery pack. Note: The approximate charge of the batteries is shown at the left top side of the LCD. The charger requires approx. 10 hours to charge empty rechargeable batteries. For charging, connect the plug of the charger to the recharge jack of the battery pack. New or long-time out-of-use rechargeable batteries reach their best performance after being charged and recharged five times. For Indoor applications the charger can be used as a power supply for the GL. -
Page 4: Laser Setup
LASER SETUP Position the laser horizontally (tripod mount and rubber feet downward!) on a stable platform, wall mount or tripod at the desired elevation. The laser recognizes automatically whether it is used horizontally or vertically when switched on. Turning On/Off the laser Press the power button to turn On/Off the laser. -
Page 5: Standard Features
Standard Features X-Y-grade entering – Step and Go mode Quickly press and release button 2 starts the grade entering mode. Both grade values will be shown. Press/release button 1 a grade reverse Y Press/release button 2 a grade reverse X (only GL622) Press/release button 3 a return to the standard display Quickly press and release button 4 to confirm the selected grade value and return to the standard display Press and hold button 6 or 7 (left/right) to change X- axis grade value (only GL622) after the comma; press and hold buttons 6 + 7 simultaneously starts X-axis quick change mode where the grade value in front of the comma will be set to 0% and then starts changing in 1% increments. -
Page 6: Using The Rotation Mode
Use button 1 or 2 (Plus or Minus) to set the desired digit. The laser will self-level to the required grade position after confirming the grade change with button 4. Note: The bubble symbols at the laser’s LCD will flash until the laser has been self-leveled to the requested grade position. Using the Rotation mode Repeatedly pressing the button 4 toggles through 300, 600, 900 rpm regardless if the unit is in automatic or manual mode. Manual mode Pressing and releasing button 3 at the Standard Display activates/deactivates the manual mode regardless if set up horizontal or vertical. Manual mode is indicated by horizontal lines next to the axes symbols. In Manual mode (horizontal), the Y-axis can be sloped by pressing the Up-(5) and Down-Arrow-(8) buttons on the laser‘s keypad or the remote control. Additionally, the X-axis can be sloped by pressing the Left-(6) and Right-(7) Arrow-buttons on the laser or remote control. -
Page 7: Menu Functions (Radio Controlled)
Menu functions when set up horizontal Menu functions when set up vertical Note: Pairing function is needed to pair an already paired remote with a new transmitter. The new transmitter has to be set to the pairing dialog for this operation. Otherwise the pairing can not be successful processed. -
Page 8: Automatic Planelok Mode
Automatic PlaneLok mode The PlaneLok mode can be activated in horizontal and vertical automatic and manual mode. In PlaneLok mode when set up horizontal, the beam will be locked to a fixed elevation point (up to 80 m (260 ft) located on one axis at each side of the laser. For keeping vertical alignments fixed to a direction point, PlaneLok can be used in both directions on the X-axis. 1. Set up the laser over the reference point. 2. A ttach the HL750 receiver to a grade rod. Place the receiver at the second point and adjust it to the On-grade position. The receiver should be permanently mounted at this location and at the desired elevation. -
Page 9: Automatic Grade Match
Automatic Grade Match The Grade Match mode can be activated in horizontal automatic and manual mode. In Grade Match mode, the laser can be used to measure the existing grade value between two known elevation points (up to 80 m (260 ft) located on one axis at each side of the laser 1. Set up the laser over the reference point. 2. A ttach the HL750 receiver to a grade rod. Check the laser’s elevation next to the laser then position the receiver at the second point WITHOUT changing the receiver’s elevation on the rod. 3. U se the sighting guides on the top of the laser to align the laser to the receiver. Turn the laser on the tripod until it is roughly aligned to the receiver’s position (the alignment range for both axes is +/-40°). 4. Press and release the MENU button at the Standard Display and select Grade Match. 5. S elect the desired Grade Match axis (X- only GL622) then press button 4 to start Grade Match. Note: The laser starts to search for the receiver. A flashing Receiver and angle symbol appears at the selected axis and disappears when Grade Match has been completed. -
Page 10: Automatic Axis Alignment (Only Gl622)
Automatic Axis Alignment (only GL622) Automatic Axis Alignment mode adjusts automatically the direction the grade axis is pointing to the receiver’s location by an electronically simulation of rotating the unit on its base to match the hub. Using Axis Alignment, the laser axis can be aligned to one direction hub (up to 80 m (260 ft) located on one axis at each side of the laser. 1. Set up the laser over the reference point. 2. P lace the grade rod with the attached HL750 receiver at the desired direction hub. 3. U se the sighting guides on the top of the laser to align the laser to the receiver. Turn the laser on the tripod until it is roughly aligned to the receiver’s position (the alignment range for both axes is +/-40°). 4. Press and release the MENU button at the Standard Display and select Axis Align. 5. Select the desired axis then press button 4 to start Axis Align. Note: Adjusting the receiver into the beam before starting the automatic Axis Alignment reduces the time needed for finishing the alignment. -
Page 11: Info
Info Press and release the MENU button at the Standard Display and select Info. Buttons 6/7 can be used to toggle between GL, RC and Runtime. Press and release button 4 to confirm the selection. The GL/RC information (software version, ID, etc.) or the runtime of the GL will be displayed. Service Press and release the MENU button at the Standard Display and select Service. Buttons 6/7 can be used to toggle between Calibration Y and Calibration X OR Calibration Z when set up vertically. Press and release button 4 to confirm the selection. The calibration at the selected axis starts the field calibration procedure. -
Page 12: Special Features - Vertical Setup
Special Features - Vertical Setup Line Scan Line Scan centers the rotor horizontally and can be used to align the plumb beam to a desired horizontal position. Press and release the MENU button at the Standard Display and select Line Scan. Pressing and releasing button 4 activates the Line Scan mode while the rotor checks the limits of the X- axis and stops at the center position. -
Page 13: Pairing The Transmitter With Remote Control
Pairing the transmitter with remote control The chain symbol at button 1 indicates the remote has never been paired before which means no radio connectivity is given. Pressing the pairing button 1 will initiate a pairing request. The transmitter has to be in pairing mode as shown above. Note: Make sure that pairing mode is selected only at one transmitter which is within the radio range of the remote during a pairing request. Otherwise pairing procedure can be confused. Pairing the transmitter with receiver To pair the transmitter and the receiver select Settings and press and release button 4 to open the Pairing menu. The display shows the currently paired units (up to 2 receivers). If already 2 receivers have been paired, one or both of them have to be deleted using button 1 (CLR). -
Page 14: Grade Entry
Grade Entry Select the Grade Entry icon and press and release button 4 to open the Grade Entry menu. Buttons 6/7 can be used to toggle between Step and Go and Digit Select. Press and release button 4 to confirm the selection. Step and Go Digit Select Grade Display Select the Grade Display icon and press and release button 4 to open the Grade Display menu. The desired Grade Display Mode (Percent/ Permille/Degree) can be selected using the buttons 6/7. Press and release button 4 to confirm the selected display mode. Sensitivity Selection Select the Sensitivity icon and press and release button 4 to open the Sensitivity menu. The desired Sensitivity: Low, Mid (Default) and High) can be selected using the buttons 6/7. -
Page 15: User Name
User Name Select the User name icon and press and release button 4 to open the User name menu. One row for typing names in big font (15) and one row in small font (18) for letters or numbers are available. Button 5 and 8 can be used to toggle between both rows. Changing the characters can be done using the buttons 1 and 2. Press and release button 4 to confirm the selected user name. The display falls back to the main menu. Any time the unit will be powered up, the User info will be displayed for couple seconds. Set Password Select the Set Password icon and press and release button 4 to open the Password menu. Use Button 1 to 8 to type in a password containing of 4 digits and repeat the password at the second row. -
Page 16: Select Language
Select Language Select the Language icon and press and release button 4 to open the Language menu.Use button 5 to 8 to select the required local language (EN, DE, IT, FR, ES, PT, NL, DA, NO, SV, FI, PL, TR, CZ). Press and release button 4 to store the selected Language; unit falls back to the standard menu. CALIBRATION Checking Calibration of the Y- and X-Axes 1. Set up the laser 30 m (100 ft) from a wall and allow it to level. 2. Set the grade to 0.000% in both axes. -
Page 17: Troubleshooting
Troubleshooting Any error message can be deleted with a short press of button 4 (OK). The table shows the related description and possible solutions. The next service center should be contacted if a different error message as shown at the table will be displayed. Error codes Description Solution Temporary EEprom problem Repeat pairing and re-enter the customer settings HI alert - Unit Heigt changed Check laser beam elevation after deleting the HI alert Mechanical Limit during Axis Re-align the closer to the Alignment, Grade Match or Spot alignment point; check if existing Match slope is above +/-25% Rake Angle Limit Re-align the unit closer to the alignment point... -
Page 18: Protecting The Unit
PROTECTING THE UNIT Do not expose the unit to extreme temperatures or temperature changes (do not leave inside the car). The unit is very robust and can resist damage if dropped even from tripod height. Before continuing your work, always check the leveling accuracy. See Checking Calibration section. The laser is water proof and can be used indoors and outdoors. CLEANING AND MAINTENANCE Dirt and water on the glass parts of laser or prism will influence beam quality and operating range considerably. Clean with cotton swabs. Remove dirt on the housing with a lint-free, warm, wet and smooth cloth. Do not use harsh cleansers or solvents. Allow the unit to air dry after cleaning it. PROTECTING THE ENVIRONMENT The unit, accessories and packaging ought to be recycled. This manual is made of non-chlorine recycling paper. All plastic parts are marked for recycling according to material type. Do not throw used batteries into the garbage, water or fire. Remove them in compliance with environmental requirements.Hinweis für Kunden in der EU Notice to Our European Union Customers For product recycling instructions and more information, please go to:... -
Page 19: Technical Data
TECHNICAL DATA GL622/GL612 Leveling accuracy ± 0.5 mm/10 m, 1/16“ @ 100 ft, 10 arc seconds Grade accuracy ± 1.0 mm/10 m, 1/8“ @ 100 ft, 20 arc seconds Rotation: 300, 600, 900 rpm Operational area appr. 400 m (1300 feet) radius with detector Laser type: red diode laser 650 nm Laser class: class 2, <3.2 mW Self-leveling range: appr. ± 14° Grade range (Y, X-GL622): ± 25% both axes (not simultaneously) Leveling indicators: LCD indications and LED flashes Radio range (HL750): up to 80 m (260 ft) Power source: NiMH battery pack Battery life 35 hours NiMH; 40 hours alkaline Operating temp.: -20°C to 50°C (-4°F to 122°F) Storage temp.: -20°C to 70°C (-4°F to 158°F) Tripod attachments: 5/8 x 11 horizontally and vertically Dust and Water proof: IP67 Weight: 3.1 kg (6.8 lbs) Low voltage indication: LCD battery indicator Low voltage disconnection: unit shuts off... -
Page 20: Electromagnetical Compatibility
ELECTRO-MAGNETIC COMPATIBILITY Compliance statement (part 15.19) This device complies with part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning (part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This in particular is applicable for the antenna which has been delivered with the GL622/GL612 and RC602 Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for succesful communication. 130533trimble_GL622_00_Buch 20 29.05.13 07:15...
