APEX ELLIPTICAL
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APEX XC1-0A-35 and is the answer not in the manual?

Questions and answers

Related Manuals for True Fitness APEX XC1-0A-35

Summary of Contents for True Fitness APEX XC1-0A-35

  • Page 1 APEX ELLIPTICAL OWNER’S MANUAL AND ASSEMBLY GUIDE...

  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 3: Reporting Freight Claims Or Parts Damage

    Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.

  • Page 4: Table Of Contents

    WARRANTY DETAILS ..............53 ASSEMBLY INSTRUCTIONS WARRANTY REGISTRATION ............54 PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................15 PRODUCT FEATURES BASE OVERVIEW................36 CONSOLE OVERVIEW..............38 CARE AND MAINTENANCE INSPECTION................40 CLEANING THE EQUIPMENT............40 LEVELING THE MACHINE..............41 PREVENTATIVE MAINTENANCE............42 LONG TERM STORAGE..............42 © 2025 TRUE Fitness All Rights Reserved.

  • Page 5: Safety Instructions

    Do not use this product outdoors, near water, while wet, or in areas of high • Do not move the equipment by lifting the console. Do not use the console as a humidity including extreme temperature changes. handlebar during a workout. © 2025 TRUE Fitness All Rights Reserved.
  • Page 6 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.

  • Page 7: Power Requirements

    NOTE: The plug configuration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. © 2025 TRUE Fitness All Rights Reserved.

  • Page 8: Space Requirements

    66” x 34” x 64” (167cm x 86cm x 163cm) ◦ Active Footprint 73” x 34” x 64”(185cm x 86cm x 163cm) • MACHINE WEIGHT 375 lbs / 170 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.

  • Page 9: Warning Decals

    To replace any worn or missing decals contact TRUE product support (service@truefitness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.

  • Page 10: Proper Use

    Place the opposite foot on the other side platform. • Step down off the machine. NOTE: The elliptical trainer is not equipped with a free wheel, therefore the moving parts are unable to stop immediately. © 2025 TRUE Fitness All Rights Reserved.

  • Page 11: Assembly Instructions

    INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 5mm Allen Wrench #2 Phillips Screwdriver 6mm Allen Wrench Wire Cutters 5/16” Allen Wrench Plastic Pry Tape Measure 17mm Wrench 17mm Socket Wrench © 2025 TRUE Fitness All Rights Reserved.
  • Page 12 RIGHT UPPER EXERCISE ARM LEFT EXERCISE ARM COVER RIGHT EXERCISE ARM COVER PEDAL TUBES ROCKER TUBE COVERS CONSOLE MAST CONSOLE MAST COVER REAR CONSOLE COVER FRONT GUARD TUBE FOOT PADS HARDWARE BAG(S) MANUAL © 2025 TRUE Fitness All Rights Reserved.
  • Page 13 XC90051 WASHER, M8 X 14MM OD X 2MM XCS90091 SCREW, PAN HEAD, M5 X 0.8 X 30, SS CX0102 PHMS, M3-0.5 X 12MM, CX0511 PHMS, M4-0.7 X 16MM SX0004 PHMS, M5-0.8X12MM, CRE, RE © 2025 TRUE Fitness All Rights Reserved.
  • Page 14 M8 X 16MM, LP, ZP CX0079 PHMS, M5-0.8 X 12MM, CX0063 PHMS, M5-0.8 X 8MM, LP, BLK, ZP STEP 11 (NOTE: Bag may be labeled Step 10.) ITEM DESCRIPTION VC90167 BHCS, M8-1.25 X 12MM, © 2025 TRUE Fitness All Rights Reserved.

  • Page 15: Assembly Steps

    Set the base on the foam or the feet only. NOTE: The base can be set on its left side, but only with the attached foam packaging underneath it. © 2025 TRUE Fitness All Rights Reserved.
  • Page 16 C. Connect the cables coming from the right pedestal to the corresponding cables coming out of the frame. IMPORTANT! DO NOT pinch the cables. D. Securely tuck away the pedestal cables. Network I/O Data Power Coaxial © 2025 TRUE Fitness All Rights Reserved.
  • Page 17 XCS9020-71 GASKET XC900 XPS0078 TRUSS HD TAPPING SCREW, M4 X 16MM CX0501 PHMS, M5-0.8 X 12MM XCS90091 SCREW, PAN HEAD, M5 X 0.8 X 30, SS CX0511 PHMS, M4-0.7 X 16MM © 2025 TRUE Fitness All Rights Reserved.
  • Page 18 6 12mm screws, 6 16mm screws, and 2 long pan head screws. C. Slide the black rubber gaskets down the pedestal uprights until they are flush against the shrouds. © 2025 TRUE Fitness All Rights Reserved.
  • Page 19 C. Attach the bottoms of the drawbars to the base using 8 hex screws and 8 curved washers, but do not tighten. D. Using a 6mm allen wrench, tighten the 8 hex screws and 8 curved washers. © 2025 TRUE Fitness All Rights Reserved.
  • Page 20 Step 3—Attach Drawbars and Drawbar Covers Continued E. Using a #2 Phillips screwdriver, attach the left and right drawbar covers using 6 screws and 4 larger screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 21 IMPORTANT! Be sure to switch power cable connections before installing the optional auxiliary power supply. A. Using a plastic pry and a #2 Phillips screwdriver, remove the right rear plastic covers using 2 plugs and 6 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 22 D. Connect the input and output plugs to the power supply. IMPORTANT! DO NOT plug the power supply into the battery charge port. Power cable connections for consoles requiring optional power supply Power cable connections for self generating consoles Battery charge port © 2025 TRUE Fitness All Rights Reserved.
  • Page 23 E. Secure the power supply to the bracket using 1 zip tie. NOTE: Tuck excess cables into the shroud opening. F. Using a #2 Phillips screwdriver, reattach the right rear covers using the 6 screws and 2 plugs you removed previously. © 2025 TRUE Fitness All Rights Reserved.
  • Page 24 2 bolts and 2 nuts. NOTE: Ensure that the pedal tubes are centered on the crankshaft rollers before tightening. B. Using a #2 Phillips screwdriver, attach the rocker arm covers using 8 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 25 Item Part Description XCS0059 FOOT SKATE 00597000 FOOT PAD, MERAMEC - XCS900 Insert and press down the foot pads into the plastic foot skates and ensure they are secured by the fastening strips. © 2025 TRUE Fitness All Rights Reserved.
  • Page 26 PHMS, M5-0.8 X 8MM, LP, BLK NOTE: The upper exercise arms are labeled L for left and R for right. B. Using a #2 Phillips screwdriver, attach the exercise arm covers using 8 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 27 IMPORTANT! DO NOT pinch the cables. C. Using a 6mm allen wrench, attach the side arms to the pedestal using 4 hex screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 28 SHCS, M8-1.25 X 16MM, LP, XCS0097 A. Slide the console cables through the console mast. IMPORTANT! DO NOT pinch the cables. B. Using a 6mm allen wrench, attach the console mast using 4 hex screws. Cable © 2025 TRUE Fitness All Rights Reserved.
  • Page 29 A. Using a #2 Phillips screwdriver, attach TRUSS HD TAPPING SCREW, the console mast cover to the console XPS0078 M4 X 16MM mast using 2 screws. CX0079 PHMS, M5-0.8 X 12MM, BLK, ZP © 2025 TRUE Fitness All Rights Reserved.
  • Page 30 D. Using a #2 Phillips screwdriver, secure ground the console to the console mast using do not the four screws (00567800). connect power here NOTE: Depending on the installation, power PVS power may not be used. I/O data © 2025 TRUE Fitness All Rights Reserved.
  • Page 31 Step 10—Attach Console and Rear Console Cover Continued E. Using a #2 Phillips screwdriver, attach the rear console cover to the console mast using 2 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 32 Item Part Description 5mm Allen Wrench XCS9038-35 TUBE, FRONT EXTENDED VC90167 BHCS, M8-1.25 X 12MM, SS Using a 5mm allen wrench, attach the front guard tube to the base using 4 hex screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 33 B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock nut lock nut leveling feet © 2025 TRUE Fitness All Rights Reserved.
  • Page 34 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2025 TRUE Fitness All Rights Reserved.
  • Page 35 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 36: Product Features Base Overview

    NOTE: Power warnings, grounding instructions, and power requirements are only NOTE: The battery charge port only applies for machines that are self-generated. applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply.* © 2025 TRUE Fitness All Rights Reserved.
  • Page 37 To charge the unit’ s battery, plug the optional power supply (BZ80060) into the battery charge port. NOTE: The battery charge port only applies for machines that are self-generated. Right rear shroud cover Right rear shroud cover BZ80060 Battery charge port © 2025 TRUE Fitness All Rights Reserved.

  • Page 38: Console Overview

    CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
  • Page 39 UNITE LED Eight Dedicated Data Points Manually Adjust Level Dedicated Message Center Bright White LEDs Keypad Choose Workout © 2025 TRUE Fitness All Rights Reserved.

  • Page 40: Care And Maintenance

    CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the elliptical as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.

  • Page 41: Leveling The Machine

    B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock nut lock nut leveling feet © 2025 TRUE Fitness All Rights Reserved.

  • Page 42: Preventative Maintenance

    TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...

  • Page 43: Additional Information Troubleshooting

    Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2025 TRUE Fitness All Rights Reserved.
  • Page 44 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.

  • Page 45: Wiring Diagram Self Generating Power

    WIRING DIAGRAM SELF GENERATING POWER Self Genera�ng POWER PLATE VIEW XCS0123 XCS0122 XCS0079 XCS0084 © 2025 TRUE Fitness All Rights Reserved.

  • Page 46: Wiring Diagram Optional Power Supply

    WIRING DIAGRAM SELF GENERATING POWER CONSOLE VIEW XCS9031 XCS9030 XCS9032 XCS9030 XCS9030 XCS0127 XCS0127 © 2025 TRUE Fitness All Rights Reserved.
  • Page 47 WIRING DIAGRAM SELF GENERATING POWER XCS0127- Contact HR Cable XCS9030- HR Cable XCS9032- Upper XCS9032- DC Data PWR UPPER XCS0080- LWR DATA 00588900 - Fuse XCS0029-Break Cable - Generator XCS0102 – XCS0029-Break Cable - Resistance © 2025 TRUE Fitness All Rights Reserved.
  • Page 48 WIRING DIAGRAM OPTIONAL POWER SUPPLY POWER PLATE VIEW Power Supply XCS0123 XCS0122 XCS0079 XCS0084 XCS0121 © 2025 TRUE Fitness All Rights Reserved.
  • Page 49 WIRING DIAGRAM OPTIONAL POWER SUPPLY CONSOLE VIEW XCS9031 XCS9030 XCS9032 XCS9030 XCS9030 XCS0127 XCS0127 © 2025 TRUE Fitness All Rights Reserved.
  • Page 50 XCS0127- Contact HR Cable XCS9030- HR Cable XCS9032- Upper XCS9032- DC Data PWR UPPER XCS0080- LWR DATA XCS0010 XCS0012 XCS0121 00588900 - Fuse XCS0029-Break Cable - Generator XCS0102 – XCS0029-Break Cable - Resistance © 2025 TRUE Fitness All Rights Reserved.

  • Page 51: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.

  • Page 52: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...

  • Page 53: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.

  • Page 54: Warranty Registration

    St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
  • Page 55 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC1-0A-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
