Page 1 GRAVITY ELLIPTICAL OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@trueﬁ tness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2024 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
ﬁ le a claim if the carrier is not notiﬁ ed in a timely manner. Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@trueﬁ tness.com | 800.883.8783) or TRUE sales support (sales@trueﬁ tness.com | 800.426.6570) Monday-Friday during normal business hours. © 2024 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
WARRANTY DETAILS ..............46 WARRANTY REGISTRATION ............47 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................15 PRODUCT FEATURES BASE OVERVIEW................34 CONSOLE OVERVIEW..............36 CARE AND MAINTENANCE INSPECTION................38 CLEANING THE EQUIPMENT............38 LEVELING THE MACHINE..............39 PREVENTATIVE MAINTENANCE............40 LONG TERM STORAGE..............40 © 2024 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Use this equipment only for its intended use as described in this manual. • Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered. Such substances create the danger of combustion and explosion. © 2024 TRUE Fitness All Rights Reserved.
Page 6 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2024 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
NOTE: The plug conﬁ guration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. © 2024 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
63” x 32” x 64” (160cm x 81cm x 163cm) Active Footprint ◦ 74” x 32” x 64” (188cm x 81cm x 163cm) • MACHINE WEIGHT 340 lbs / 154 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2024 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
To replace any worn or missing decals contact TRUE product support (service@trueﬁ tness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.trueﬁ tness.com. © 2024 TRUE Fitness All Rights Reserved.
Page 10: Proper Use
Place the opposite foot on the other side platform. • Step down off the machine. NOTE: The elliptical trainer is not equipped with a free wheel, therefore the moving parts are unable to stop immediately. © 2024 TRUE Fitness All Rights Reserved.
Page 11: Assembly Instructions
TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 6mm Ball End Allen Wrench #2 Phillips Screwdriver 10mm Allen Wrench Wire Cutters Plastic Pry 17mm Wrench Tape Measure 17mm Socket Wrench © 2024 TRUE Fitness All Rights Reserved.
Page 12 RIGHT EXERCISE COVER PEDAL TUBES ROCKER ARM COVERS CONSOLE MAST FRONT LOWER CONSOLE COVER REAR CONSOLE COVER FRONT GUARD TUBE LEFT PEDESTAL BASE COVER RIGHT PEDESTAL BASE COVER TRANSPORT HANDLES HARDWARE BAG(S) MANUAL © 2024 TRUE Fitness All Rights Reserved.
Page 13 ROUNDED HEAD SCREW SX0004 PHMS, M5-0.8X12MM, STEP 5 CRE, RE ITEM DESCRIPTION SX0115 HHS, M10-1.5 X 81.5MM XP0154 WASHER, FLAT, 10.2MMID, 35MMOD, 2T SX0116 NUT, HEX, M10, ZP SX0004 PHMS, M5-0.8X12MM, CRE, RE © 2024 TRUE Fitness All Rights Reserved.
Page 14 XCS0050009 HEX KEY, 6MM, BALL XCS0389 PHMS, W/WASHER, M5X12 CX0079 PHMS, M5-0.8 X 12MM, BLK ZP STEP 7 ITEM DESCRIPTION XCS0388 M8X20 SOCKET HEAD BOLT XPS0078 M4X16 TRUSS HD TAPPING SCREW (FOR SHROUD) © 2024 TRUE Fitness All Rights Reserved.
Page 15: Assembly Steps
B. Carefully remove the machine from the pallet. C. After placing the machine in its ﬁ nal location, remove the transport handles from the machine and store them with the owner’ s manual for future use. © 2024 TRUE Fitness All Rights Reserved.
Page 17 8 hex screws and 2 larger hex screws. Coaxial C. Connect the cables coming from the right pedestal to the corresponding cables in the base. IMPORTANT! DO NOT pinch the cables. © 2024 TRUE Fitness All Rights Reserved.
Page 18 C. Switch the power cable connection from the self- generated connection to the power supply connection. Power cable connections for consoles requiring Power cable optional power connections for self supply generating consoles © 2024 TRUE Fitness All Rights Reserved.
Page 19 Optional Step —Install Auxiliary Power Supply Continued D. Connect the input and output plugs to the power supply. E. Secure the power supply to the bracket using 2 zip ties. NOTE: Tuck excess cables into the shroud opening. © 2024 TRUE Fitness All Rights Reserved.
Page 20 Optional Step —Install Auxiliary Power Supply Continued F. Using a #2 Phillips screwdriver, reattach the right rear step and the rear access plastic on the right side of the machine using the 9 screws you removed previously. © 2024 TRUE Fitness All Rights Reserved.
Page 21 ﬂ at washers SX0004 PHMS, M5-0.8X12MM, CRE, RE B. Using a 6mm ball end allen M3X12 PHILLIPS ROUNDED HEAD CX0102 wrench, attach the bottoms of the SCREW drawbars to the base using 8 hex screws. © 2024 TRUE Fitness All Rights Reserved.
Page 24 8 hex screws. NOTE: The upper exercise arms are labeled L for left and R for right. B. Using a #2 Phillips screwdriver, attach the exercise arm covers using 6 screws. © 2024 TRUE Fitness All Rights Reserved.
Page 25 2 bolts and 2 nuts. NOTE: Ensure that the pedal tubes are centered on the crankshaft rollers before tightening. B. Using a #2 Phillips screwdriver, attach the rocker arm covers using 8 screws. © 2024 TRUE Fitness All Rights Reserved.
Page 26 PHMS, W/WASHER, M5X12 console mast. CX0079 PHMS, M5-0.8 X 12MM, BLK ZP IMPORTANT! DO NOT pinch the cables. B. Using a 6mm ball end allen wrench, attach the console mast using 4 hex screws. Cable © 2024 TRUE Fitness All Rights Reserved.
Page 27 Step 6—Attach Console Mast and Console Continued C. Using a #2 Phillips screwdriver, attach the front lower console cover to the console mast using 2 screws. © 2024 TRUE Fitness All Rights Reserved.
Page 28 F. Using a #2 Phillips screwdriver, ground power here secure the console to the console NOTE: Depending on the installation, mast using the four screws PVS power may not be used. power I/O data (00567800). © 2024 TRUE Fitness All Rights Reserved.
Page 30 A. Using a 6mm ball end allen wrench, attach the front guard tube to the base using 4 hex screws. B. Using a #2 Phillips screwdriver, attach the pedestal base covers to the base using 4 screws. © 2024 TRUE Fitness All Rights Reserved.
Page 32 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2024 TRUE Fitness All Rights Reserved.
Page 33 APEX UPRIGHT BIKE LAUNCH RECUMBENT BIKE VAPOR STRYKER APEX RECUMBENT ELLIPTICAL LAUNCH UPRIGHT BIKE VAPOR ALPINE RUNNER GRAVITY ELLIPTICAL VAPOR PALISADE VAPOR SPECTRUM GRAVITY RECUMBENT BIKE VAPOR XT-ONE GRAVITY UPRIGHT BIKE VAPOR LATERAL X © 2024 TRUE Fitness All Rights Reserved.
Page 34: Product Features Base Overview
NOTE: Power warnings, grounding instructions, and power requirements are only NOTE: The battery charge port only applies for machines that are self-generated. applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply.* © 2024 TRUE Fitness All Rights Reserved.
Page 35 The battery charge port is used to charge the unit’ s internal battery. To charge the unit’ s battery, plug the optional power supply (BZ80060) into the battery charge port on the outer left shroud as shown below. NOTE: The battery charge port only applies for machines that are self-generated. BZ80060 Battery charge port © 2024 TRUE Fitness All Rights Reserved.
Page 36: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2024 TRUE Fitness All Rights Reserved.
Page 38: Care And Maintenance
CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the elliptical as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.
Page 40: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualiﬁ ed service technician. Please contact your dealer or visit www.trueﬁ tness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certiﬁ ed service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 41: Additional Information Troubleshooting
Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2024 TRUE Fitness All Rights Reserved.
Page 42 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2024 TRUE Fitness All Rights Reserved.
Page 43: Wiring Diagrams
Lower Power - XCS0010 Upper Data - XCS4031 Power Inlet - XCS0101 Lower Coaxial - XCS0043 Lower Control Board - XCS0045 Lower Ethernet - XCS0131 Battery Charge Port - XCS0102 Battery Fuse - 00588900 © 2024 TRUE Fitness All Rights Reserved.
Page 44: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or Ethernet connections, and safety key. Cables and Linear 1 Year Bearings See Warranty Details for terms, conditions, and complete coverage details. Labor** 1 Year Wear Items*** 90 Days © 2024 TRUE Fitness All Rights Reserved.
Page 45: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of commercial CARDIO equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial equipment for limited-use commercial or WARRANTY VAPOR, GRAVITY in-home use may receive alternative warranty coverage, provided they meet...
Page 46: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the speciﬁ ed period of time.
Page 47: Warranty Registration
St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2024 TRUE Fitness All Rights Reserved.
Page 48 CONTACT US service@trueﬁ tness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC2-0A-35 Owner’s Manual and Assembly Guide REV02 © 2024 TRUE Fitness All Rights Reserved.
