LAUNCH ELLIPTICAL

OWNER'S MANUAL AND ASSEMBLY GUIDE

Table of Contents

Need help?

Do you have a question about the LAUNCH XC3-0A-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness LAUNCH XC3-0A-35

Page 1 LAUNCH ELLIPTICAL OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
WARRANTY DETAILS ..............42 WARRANTY REGISTRATION ............43 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................15 PRODUCT FEATURES BASE OVERVIEW................30 CONSOLE OVERVIEW..............32 CARE AND MAINTENANCE INSPECTION................34 CLEANING THE EQUIPMENT............34 LEVELING THE MACHINE..............35 PREVENTATIVE MAINTENANCE............36 LONG TERM STORAGE..............36 © 2025 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Use this equipment only for its intended use as described in this manual. • Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered. Such substances create the danger of combustion and explosion. © 2025 TRUE Fitness All Rights Reserved.
Page 6 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
NOTE: The plug configuration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. © 2025 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
42” x 30” x 64” (107cm x 76cm x 163cm) ◦ Active Footprint 70” x 30” x 64” (177cm x 76cm x 163cm) • MACHINE WEIGHT 275 lbs / 125 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
To replace any worn or missing decals contact TRUE product support (service@truefitness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.
Page 10: Proper Use
Place the opposite foot on the other side platform. • Step down off the machine. NOTE: The elliptical trainer is not equipped with a free wheel, therefore the moving parts are unable to stop immediately. © 2025 TRUE Fitness All Rights Reserved.
Page 11: Assembly Instructions
TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 4mm Allen Wrench #2 Phillips Screwdriver 6mm Allen Wrench 17mm Wrench 17mm Box End Wrench Wire Cutters Phillips Screwdriver © 2025 TRUE Fitness All Rights Reserved.
Page 12 LEFT MIDDLE PIVOT COVER RIGHT MIDDLE PIVOT COVER LEFT PEDAL TUBE RIGHT PEDAL TUBE LOWER PIVOT COVERS LEFT UPPER EXERCISE ARM RIGHT UPPER EXERCISE ARM LEFT UPPER PIVOT COVER RIGHT UPPER PIVOT COVER HARDWARE PACK MANUAL © 2025 TRUE Fitness All Rights Reserved.
Page 13 PLASTIC M4-0.7 X 16MM XM0236 BHCS, M10 X 85MM X P1.5, XM0168 BHCS, M6 X 15MM, BLK BLK BED SX0124 BHCS, M10 X 20MM X P1.5, BLK ZP PS0105 SCREW, MACHINE M5X0.8 X 12MM BLK © 2025 TRUE Fitness All Rights Reserved.
Page 14 HARDWARE PACK CONTENTS XC3-0A-35 HARDWARE PACK ITEM DESCRIPTION XM0139_003 17MM WRENCH, BOX END XM0139_004 ALLEN KEY, 4MM XM0139_005 ALLEN KEY, 6MM XM0139_006 PHILLIPS SCREWDRIVER © 2025 TRUE Fitness All Rights Reserved.
Page 15: Assembly Steps
6 hex screws and 3 lock nuts. NOTE: At least one person should hold the console mast, while another installs the console mast. IMPORTANT! DO NOT fully tighten the hardware until step 4. © 2025 TRUE Fitness All Rights Reserved.
Page 16 Using a Phillips screwdriver, attach the lower frame cover to the base using 6 screws. NOTE: Position the cables between the lower frame cover and the console mast. IMPORTANT! DO NOT pinch the cables. © 2025 TRUE Fitness All Rights Reserved.
Page 17 A. Connect the bullhorn and console mast cables. IMPORTANT! DO NOT pinch the cables. B. Using a 4mm allen wrench, attach the bullhorn to the console mast using 5 screws. NOTE: Tighten the front screw first. © 2025 TRUE Fitness All Rights Reserved.
Page 18 C. Using a 6mm allen wrench and a 17mm box end wrench, fully tighten the hardware from step 1. NOTE: Tighten the 3 hex screws on the back of the base first. © 2025 TRUE Fitness All Rights Reserved.
Page 19 D. Using a #2 Phillips screwdriver, attach the middle pivot covers to the swing arm assembly using 6 screws.Using a #2 Phillips screwdriver, attach the left and right drawbar covers using 6 screws and 4 larger screws. © 2025 TRUE Fitness All Rights Reserved.
Page 20 A. Using a 6mm allen wrench and a 17mm box end wrench, attach the pedal tubes using 2 bolts and 2 nuts. NOTE: Ensure that the pedal tubes are aligned on the center of the crankshaft rollers before tightening. © 2025 TRUE Fitness All Rights Reserved.
Page 22 SCREW, COARSE PLASTIC M3-0.5 X XM0128 swing arm assembly using 12 hex 16MM BLK screws. B. Using a Phillips screwdriver, attach the upper pivot covers to the swing arm assembly using 10 screws. © 2025 TRUE Fitness All Rights Reserved.
Page 23 Non-LED consoles require the optional power supply. A. Remove the right step pad from the base. B. Using a #2 Phillips screwdriver, remove the top right shroud from the base using 4 screws. © 2025 TRUE Fitness All Rights Reserved.
Page 24 D. Connect the input and output plugs to the power supply. NOTE: Disconnect the DC power cord from the lower board and plug it into the power supply. E. Secure the power supply to the battery using 2 zip ties. © 2025 TRUE Fitness All Rights Reserved.
Page 25 Optional Step 7—Install Auxiliary Power Supply Continued F. Using a #2 Phillips screwdriver, reattach the top right shroud and right step pad using the 4 screws you removed previously. © 2025 TRUE Fitness All Rights Reserved.
Page 26 C. Using a #2 Phillips screwdriver, ground secure the console to the console do not mast using the four screws connect (00567800). power here NOTE: Depending on the installation, PVS power may not be used. power I/O data © 2025 TRUE Fitness All Rights Reserved.
Page 27 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2025 TRUE Fitness All Rights Reserved.
Page 29 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 30: Product Features Base Overview
NOTE: Power warnings, grounding instructions, and power requirements are only NOTE: The battery charge port only applies for machines that are self-generated. applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply.* © 2025 TRUE Fitness All Rights Reserved.
Page 31 The battery charge port is used to charge the unit’ s internal battery. To charge the unit’ s battery, plug the optional power supply (BZ80060) into the battery charge port on the outer left shroud as shown below. NOTE: The battery charge port only applies for machines that are self-generated. BZ80060 Battery charge port © 2025 TRUE Fitness All Rights Reserved.
Page 32: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
Page 34: Care And Maintenance
CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the elliptical as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.
Page 36: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 37: Additional Information Troubleshooting
Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2025 TRUE Fitness All Rights Reserved.
Page 38 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
Page 39: Wiring Diagrams
POWER INLET TO POWER SWITCH TCS4032 (Load Wire) POWER INLET TO POWER SWITCH TCS4031 (Neutral Wire) LOAD LEG OF XM0253 ON POWER SWITCH Heart Rate XM0330 GROUND LEG OF XM0253 ON POWER INLET Heart Rate XM0329 © 2025 TRUE Fitness All Rights Reserved.
Page 40: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
Page 41: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
Page 42: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
Page 43: Warranty Registration
St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
Page 44 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC3-0A-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
