GRAVITY RECUMBENT ELLIPTICAL
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRAVITY XC2-RA-35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for True Fitness GRAVITY XC2-RA-35

Summary of Contents for True Fitness GRAVITY XC2-RA-35

  • Page 1 GRAVITY RECUMBENT ELLIPTICAL OWNER’S MANUAL AND ASSEMBLY GUIDE...

  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefi tness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2024 TRUE Fitness All Rights Reserved.

  • Page 3: Reporting Freight Claims Or Parts Damage

    fi le a claim if the carrier is not notifi ed in a timely manner. Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefi tness.com | 800.883.8783) or TRUE sales support (sales@truefi tness.com | 800.426.6570) Monday-Friday during normal business hours. © 2024 TRUE Fitness All Rights Reserved.

  • Page 4: Table Of Contents

    COMPLIANCES................9 PROPER USE.................10 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................14 PRODUCT FEATURES BASE OVERVIEW................27 CONSOLE OVERVIEW..............28 CARE AND MAINTENANCE INSPECTION................30 CLEANING THE EQUIPMENT............30 LEVELING THE MACHINE..............30 PREVENTATIVE MAINTENANCE............31 LONG TERM STORAGE..............31 ADDITIONAL INFORMATION TROUBLESHOOTING..............32 © 2024 TRUE Fitness All Rights Reserved.

  • Page 5: Safety Instructions

    Do not move the equipment by lifting the console. Do not use the console as a humidity including extreme temperature changes. handlebar during a workout. • Close supervision is necessary when used near children under the age of 15, or disabled persons. © 2024 TRUE Fitness All Rights Reserved.
  • Page 6 110V AC input and 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2024 TRUE Fitness All Rights Reserved.

  • Page 7: Power Requirements

    XC2-RA-35 with the optional power supply. NEMA 6-15 Up to 5 units per Non-LED consoles require the 350 watts per 50/60Hz circuit—DO NOT optional power supply. machine exceed © 2024 TRUE Fitness All Rights Reserved.

  • Page 8: Space Requirements

    71” x 35” x 57” (180.3cm x 88.9cm x 143.9cm) Active Footprint ◦ 71” x 35” x 57” (180.3cm x 88.9cm x 143.9cm) • MACHINE WEIGHT 268 lbs / 122 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2024 TRUE Fitness All Rights Reserved.

  • Page 9: Warning Decals

    To replace any worn or missing decals contact TRUE product support (service@truefi tness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefi tness.com. © 2024 TRUE Fitness All Rights Reserved.

  • Page 10: Proper Use

    Stop pedaling by slowing leg motion and applying slight resistance to the upper exercise arms. • Remove feet from pedals and place on the fl oor. • Exit the machine from either side. © 2024 TRUE Fitness All Rights Reserved.

  • Page 11: Assembly Instructions

    #2 Phillips Ratchet Wrench with Screwdriver 13mm Socket 6mm Allen Wrench Wire Cutters Ratchet Wrench with Torque Wrench 6mm Socket Bit and (optional but Extension (optional recommended) but recommended) 13mm and 17mm Wrench © 2024 TRUE Fitness All Rights Reserved.

  • Page 12: Box Contents

    Seat Back Assembly Seat Pad Stationary Handlebar Left Cup Holder Right Cup Holder Left Moving Handlebar Right Moving Handlebar Moving Handlebar Covers Leveler Covers Mast Boot Top Shroud Left Pedal Right Pedal Hardware Kit Manual © 2024 TRUE Fitness All Rights Reserved.

  • Page 13: Hardware Kit Contents

    SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1 CROSS STEEL RECESSED, BZ, SPRING WSHR-FLAT WSHR 103212-001 WASHER, M8, 8.3 X 16.0 X 1.6, STAINLESS STEEL 8100355 CAP, XR650 PEDAL HUB, BLACK 8100251 CAP, UPPER LINK, BLACK © 2024 TRUE Fitness All Rights Reserved.

  • Page 14: Assembly Steps

    C. Using a 6mm allen wrench, securely fasten all six M8 hex screws. When using a torque wrench fasten to 40 n-m (30 ft-lb). when using a torque wrench = 40 N-M (30 FT-LB) © 2024 TRUE Fitness All Rights Reserved.
  • Page 15 Slide the axle out the left side of the machine. NOTE: The cup holders are labeled left (L) and right (R). © 2024 TRUE Fitness All Rights Reserved.
  • Page 16 When using a torque wrench fasten to 23 n-m (17 ft-lb). handlebar heart rate cable tilt handle base heart height rate adjust cable handle damper when using a torque wrench seat = 23 N-M (17 FT-LB) carriage © 2024 TRUE Fitness All Rights Reserved.
  • Page 17 Place the damper from the seat assembly in between the bracket on the seat carriage. Using the previously removed M8 hex screw, washers, and nut, securely fasten the damper to the seat carriage. © 2024 TRUE Fitness All Rights Reserved.
  • Page 18 B. Using a 6mm allen wrench, securely fasten the hardware. When using a into. torque wrench fasten to 40 n-m (30 ft-lb). notch when using a torque wrench = 40 N-M (30 FT-LB) © 2024 TRUE Fitness All Rights Reserved.
  • Page 19 40 n-m (30 ft-lb). D. Repeat for right handlebar. IMPORTANT! Handlebars must be set to the same position for proper function. when using a torque wrench = 40 N-M (30 FT-LB) © 2024 TRUE Fitness All Rights Reserved.
  • Page 20 (00567700). ground 00567800 network 00567700 I/O data PVS power power heart coaxial rate heart rate ground coaxial NOTE: Depending on the installation, PVS power may not be used. © 2024 TRUE Fitness All Rights Reserved.
  • Page 21 PVS. If an LED console is being used without a PVS, switch the power connection in the base to self-gen. leave external power connected for touchscreen consoles or PVS self-gen power external power © 2024 TRUE Fitness All Rights Reserved.
  • Page 22 COVER, MAST BOOT, DARK A. Attach the top shroud and secure to the base using a B. Wrap the mast boot around the console mast. #2 Phillips screwdriver and two M5 Phillips screws. © 2024 TRUE Fitness All Rights Reserved.
  • Page 23 = 40 N-M (30 FT-LB) lower hardware. When using a torque wrench fasten to 40 n-m (30 ft-lb). E. Press one pedal cap over the lower right pedal hub. F. Repeat steps A-E for the left pedal. © 2024 TRUE Fitness All Rights Reserved.
  • Page 24 B. Verify both lock nuts are securely tightened and fl ush against the bottom of the frame. C. Press both level covers into place on both sides of the machine. lock lock leveling leveling foot foot © 2024 TRUE Fitness All Rights Reserved.
  • Page 25 APEX UPRIGHT BIKE LAUNCH RECUMBENT BIKE VAPOR STRYKER APEX RECUMBENT ELLIPTICAL LAUNCH UPRIGHT BIKE VAPOR ALPINE RUNNER GRAVITY ELLIPTICAL VAPOR PALISADE VAPOR SPECTRUM GRAVITY RECUMBENT BIKE VAPOR XT-ONE GRAVITY UPRIGHT BIKE VAPOR LATERAL X © 2024 TRUE Fitness All Rights Reserved.
  • Page 26 © 2024 TRUE Fitness All Rights Reserved.

  • Page 27: Product Features Base Overview

    Adjustable feet to aid in leveling the machine. G. Pedals Engage the lower body during exercise. H. Moving Handlebars Engage the upper body during exercise. Stationary Handlebars with Contact Heartrate Grips Check heartrate without wearing a wireless chest strap. © 2024 TRUE Fitness All Rights Reserved.

  • Page 28: Console Overview

    CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2024 TRUE Fitness All Rights Reserved.
  • Page 29 UNITE LED Eight Dedicated Data Points Manually Adjust Level Dedicated Message Center Bright White LEDs Keypad Choose Workout © 2024 TRUE Fitness All Rights Reserved.

  • Page 30: Care And Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any parts of the machine. Allow the machine to dry completely before using. Frequently vacuum the fl oor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation.

  • Page 31: Preventative Maintenance

    TRUE recommends that quarterly scheduled maintenance be performed by a qualifi ed service technician. Please contact your dealer or visit www.truefi tness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certifi ed service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...

  • Page 32: Additional Information Troubleshooting

    Obtain set top box from video provider Verify video type with provider; analog (NTCS), digital air (ATCS), digital cable (QAM) Channels or format type not correct Rescan TV channels Tuner Invalid Contact TRUE Product Support © 2024 TRUE Fitness All Rights Reserved.
  • Page 33 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2024 TRUE Fitness All Rights Reserved.

  • Page 34: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or Ethernet connections, and safety key. Cables and Linear 1 Year Bearings See Warranty Details for terms, conditions, and complete coverage details. Labor** 1 Year Wear Items*** 90 Days © 2024 TRUE Fitness All Rights Reserved.

  • Page 35: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of commercial CARDIO equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial equipment for limited-use commercial or WARRANTY VAPOR, GRAVITY in-home use may receive alternative warranty coverage, provided they meet...

  • Page 36: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specifi ed period of time.

  • Page 37: Warranty Registration

    St. Louis, MO 63366 number location WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2024 TRUE Fitness All Rights Reserved.
  • Page 38 CONTACT US service@truefi tness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC2-RA-35 Owner’s Manual and Assembly Guide REV02 © 2024 TRUE Fitness All Rights Reserved.
