VAPOR XT-ONE
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAPOR XT-ONE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for True Fitness VAPOR XT-ONE

Summary of Contents for True Fitness VAPOR XT-ONE

  • Page 1 VAPOR XT-ONE OWNER’S MANUAL AND ASSEMBLY GUIDE...

  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 3: Reporting Freight Claims Or Parts Damage

    Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.

  • Page 4: Table Of Contents

    COMPLIANCES................9 PROPER USE.................10 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................14 PRODUCT FEATURES BASE OVERVIEW................25 CONSOLE OVERVIEW..............26 CARE AND MAINTENANCE INSPECTION................28 CLEANING THE EQUIPMENT............28 LEVELING THE MACHINE..............28 PREVENTATIVE MAINTENANCE............29 LONG TERM STORAGE..............29 ADDITIONAL INFORMATION TROUBLESHOOTING..............30 © 2025 TRUE Fitness All Rights Reserved.

  • Page 5: Safety Instructions

    Do not move the equipment by lifting the console. Do not use the console as a • Close supervision is necessary when used near children under the age of 15, handlebar during a workout. or disabled persons. © 2025 TRUE Fitness All Rights Reserved.
  • Page 6 110V AC input and 9V DC 1.5 amp output for console operation only. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.

  • Page 7: Power Requirements

    XC4-XA-35 with the optional power supply. Up to 3 cross NEMA 6-15 Non-LED consoles require the trainers per 550 watts per 50/60Hz optional power supply. circuit—DO NOT cross trainer exceed © 2025 TRUE Fitness All Rights Reserved.

  • Page 8: Space Requirements

    MACHINE WEIGHT 395 lbs / 180 kg ◦ Footprint 75” x 33” (191cm x 84cm) • MAXIMUM USER WEIGHT Active Footprint ◦ 400 lbs / 181 kg 92” x 33” (234cm x 84cm) © 2025 TRUE Fitness All Rights Reserved.

  • Page 9: Warning Decals

    APPROVALS DATE DRAWN BY 12/5/2005 SCALE 1:1 DO NOT SCALE DRAWING SHEET 1 OF 1 This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.

  • Page 10: Proper Use

    Place the opposite foot on the other side platform (if equipped). • Step down to the floor. NOTE: The elliptical trainer is not equipped with a free wheel, therefore the moving parts are unable to stop immediately. © 2025 TRUE Fitness All Rights Reserved.

  • Page 11: Assembly Instructions

    IN BOX IN BOX #2 Phillips Torque Wrench 13mm (Qty 2) and Screwdriver (optional but 17mm Wrench recommended) 6mm Allen Wrench Rubber Mallet Ratchet Wrench with 6mm Socket Bit (optional but Wire Cutters recommended) © 2025 TRUE Fitness All Rights Reserved.

  • Page 12: Box Contents

    The right pedal is not attached. To avoid potential damage to the machine, keep the base on the bottom of box and the styrofoam around pedals until you are ready to start step 1. © 2025 TRUE Fitness All Rights Reserved.

  • Page 13: Hardware Kit Contents

    SCREW, M4.8 X 1.6 X 13 TYPE B, TYPE 1 CROSS RECESS PAN HEAD, ST BZ 102135-001 SCREW, M5 X 0.8 X 10, PAN HEAD, TYPE 1 CROSS RECESSED, SS 100924-001 WRENCH, HEX, M6 © 2025 TRUE Fitness All Rights Reserved.

  • Page 14: Assembly Steps

    IMPORTANT! Complete steps A-E before removing the base from the box. A. Using a #2 Phillips screwdriver, remove and set aside the four screws B. Remove and set aside the top shroud assembly. securing the top shroud assembly to the base. © 2025 TRUE Fitness All Rights Reserved.
  • Page 15 D. Attach the right pedal to the 3-pivot link using the bolt and nut. F. Using two people, carefully roll the unit off the front of the box. when using a torque wrench = 23 N-M (17 FT-LB) © 2025 TRUE Fitness All Rights Reserved.
  • Page 16 D. Slide the tray shroud back in place. Using a #2 Phillips screwdriver, reattach the four previously removed screws to secure the tray shroud to the base. © 2025 TRUE Fitness All Rights Reserved.
  • Page 17 NOTE: You might need a rubber mallet to lightly tap the arm on to the shaft. when using a torque wrench = 40 N-M (30 FT-LB) © 2025 TRUE Fitness All Rights Reserved.
  • Page 18 E. Line up the slot of the left handlebar cover with the left button control moving handlebar and press into cables place. NOTE: Handlebar covers are labeled L and R for left and right. heart rate cables © 2025 TRUE Fitness All Rights Reserved.
  • Page 19 (00567800). I/O data PVS power power coaxial button heart rate control ground do not connect power here NOTE: Depending on the installation, PVS power may not be used. power I/O data © 2025 TRUE Fitness All Rights Reserved.
  • Page 20 A. Connect battery cables. C. Reattach the top shroud assembly using the previously set aside four screws from step 1. B. Connect the power supply if using a touch screen or PVS console. battery cables © 2025 TRUE Fitness All Rights Reserved.
  • Page 21 A. Wrap the mast boot around the base of the mast. B. Attach one left and one right frame end cover around each frame end and secure in place using six M5 screws (3 per side). © 2025 TRUE Fitness All Rights Reserved.
  • Page 22 IMPORTANT! Do not adjust the leveling feet to such a height that they detach or unscrew from the machine. B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock lock leveling leveling foot foot © 2025 TRUE Fitness All Rights Reserved.
  • Page 23 CAUTION: AVOID DAMAGE TO THE MACHINE! ALWAYS VERIFY THE CORRECT BASE MODEL HAS BEEN CONFIGURED TO THE CONSOLE. THE CORRECT BASE MODEL FOR THIS MACHINE IS VAPOR XT-ONE Please follow the instructions included with your console for important configuration steps.
  • Page 24 © 2025 TRUE Fitness All Rights Reserved.

  • Page 25: Product Features Base Overview

    Patented, one-of-the-kind converging path and multigrip handlebars to better engage the upper body and fit every exerciser comfortably. Check heartrate without wearing a wireless chest strap. H. Stationary Handlebars Helps to stabilize the upper body during lower body only exercises. © 2025 TRUE Fitness All Rights Reserved.

  • Page 26: Console Overview

    CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
  • Page 27 UNITE LED Eight Dedicated Data Points Manually Adjust Stride Manually Adjust Level Dedicated Message Center Bright White LEDs Keypad Manually Adjust Incline Choose Workout © 2025 TRUE Fitness All Rights Reserved.

  • Page 28: Care And Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any parts of the machine. Allow the machine to dry completely before using. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation.

  • Page 29: Preventative Maintenance

    TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...

  • Page 30: Additional Information Troubleshooting

    Obtain set top box from video provider Verify video type with provider; analog (NTCS), digital air (ATCS), digital cable (QAM) Channels or format type not correct Rescan TV channels Tuner Invalid Contact TRUE Product Support © 2025 TRUE Fitness All Rights Reserved.
  • Page 31 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.

  • Page 32: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or 1 Year Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.

  • Page 33: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...

  • Page 34: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.

  • Page 35: Warranty Registration

    St. Louis, MO 63366 WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
  • Page 36 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-XC4-XA-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
