User Manual
Rechargeable Li-ion Battery System
Lynx Home A Series
V1.0-2023-08-25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lynx Home A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Goodwe Lynx Home A Series

Summary of Contents for Goodwe Lynx Home A Series

  • Page 1 User Manual Rechargeable Li-ion Battery System Lynx Home A Series V1.0-2023-08-25...
  • Page 2 Copyright Statement User Manual V1.0-2023-08-25 Trademarks and other GOODWE trademarks are trademarks of GoodWe Technologies Co.,Ltd. All other trademarks or registered trademarks mentioned in this manual are owned by the company. NOTICE The information in this user manual is subject to change due to product updates or other reasons.

  • Page 3: Table Of Contents

    Content User Manual V1.0-2023-08-25 CONTENT 1 About This Manual ............... 01 1.1 Applicable Model ..................01 1.2 Target Audience ..................01 1.3 Symbol Definition ..................01 1.4 Updates ......................01 2 Safety Precaution ................. 02 2.1 General Safety ..................... 02 2.2 Battery Safety ....................
  • Page 4 Content User Manual V1.0-2023-08-25 7.3 Setting the Battery Parameters ..............25 7.4 Indicator Status ................... 27 8 Maintenance ................. 28 8.1 Power OFF the Battery System ..............28 8.2 Routine Maintenance ................. 29 8.3 Troubleshooting ..................29 9 Technical Parameters ..............32...

  • Page 5: About This Manual

    All the installers and users have to be familiar with the product features, functions, and safety precautions. This manual is subject to update without notice. For more product details and latest documents, visit https://en.goodwe.com/. 1.1 Applicable Model This manual applies to the listed models below: •...

  • Page 6: Safety Precaution

    • Strictly follow the installation, operation, and configuration instructions in this manual. The manufacturer shall not be liable for equipment damage or personal injury if you do not follow the instructions. For more warranty details, please visit: https://www.goodwe.com/support-service/warranty-related.

  • Page 7: Battery Safety

    02 Safety Precaution User Manual V1.0-2023-08-25 2.2 Battery Safety DANGER • Power off the battery system before any operations to avoid danger. Strictly follow all safety precautions outlined in this manual and safety labels on the equipment during the operation. •...
  • Page 8 02 Safety Precaution User Manual V1.0-2023-08-25 Label Description Symbol Description Symbol Description Potential risks exist. Wear proper Keep the equipment away from open flame or ignition source. PPE before any operations. HIGH VOLTAGE HAZARD. High voltage exists during the equipment's running. Keep the equipment away from Ensure the equipment is power children.

  • Page 9: Emergency Measures

    • The fire cannot be put out by water or ABC dry powder extinguisher. Firefighters are required to wear full protective clothing and self-contained breathing apparatus. 2.4 EU Declaration of Conformity GoodWe Technologies Co., Ltd. hereby declares that the inverter without wireless communication modules sold in the European market meets the requirements of the following directives: •...

  • Page 10: Product Introduction

    • LX A5.0-10 Model LX A 5.0-10 Referring to Explanation Series code Lynx Home A Series. Usable energy 5.0: The usable energy of the battery system is 5 kWh. Version code 10: Version of the battery system is 1.0. Usable energy description NOTICE •...

  • Page 11: Appearance

    03 Product Introduction User Manual V1.0-2023-08-25 3.2 Appearance Parts Descriptions Hanger Used to move the battery. PE Terminals Used to connect grounding cables to the battery for protection. Used to connect DC cables of the battery system. Each battery Power Input & has 2 BAT+ ports, 2 BAT - ports, and each are functionally Output Ports identical.

  • Page 12: Check And Storage

    03 Product Introduction User Manual V1.0-2023-08-25 Dimension 420 mm 4 Check and Storage 4.1 Check Before Receiving Check the following items before receiving the product. 1. Check the outer packing box for damage, such as holes, cracks, deformation, and other signs of equipment damage.

  • Page 13: Storage

    04 Storage and Package User Manual V1.0-2023-08-25 Battery Combiner Box (BCB-11-WW-0) (Optional) 360 A Battery M6 Battery (OT Terminal 25-8) x 18 Combiner Box x 1 Combiner Box x 4 (OT Terminal 70-10) x 2 Battery Combiner Box (BCB-22-WW-0) (Optional) 720 A Battery M6 Battery (OT Terminal 25-8) x 36...

  • Page 14: System Installation

    05 System Installation User Manual V1.0-2023-08-25 5 System Installation 5.1 Installation Requirements Installation Environment Requirements 1. Do not install the equipment in a place near flammable, explosive, or corrosive materials. 2. Do not install the equipment in a place that is easy to touch, especially within children’s reach. High temperature exists when the equipment is working.
  • Page 15 05 System Installation User Manual V1.0-2023-08-25 ALT: 3000m Mounting Support Requirements • The mounting support shall be nonflammable and fireproof. • Install the equipment on a surface that is solid enough to bear the product weight. Installation Angle Requirements Install the equipment horizontal, no tilt or upside down.

  • Page 16: Installing The Battery System

    05 System Installation User Manual V1.0-2023-08-25 5.2 Installing the Battery System 5.2.1 Moving the Equipment CAUTION • Operations such as transportation, turnover, installation and so on must meet the requirements of the laws and regulations of the country or region where it is located. •...

  • Page 17: Cabinet Installation

    05 System Installation User Manual V1.0-2023-08-25 1.4N·m 1.4N·m 5.2.3 Cabinet Installation NOTICE • A 19 inch standard cabinet is recommended. The physical length and width of a cabinet can be 600 * 800mm or above. The height that can be selected based on the number of parallel led batteries.
  • Page 18 05 System Installation User Manual V1.0-2023-08-25 IFpP52/161/120[16S] M/-10+50/90 LX A5.0-10 100 Ah 5.0 kWh 60 Ad.c. 60 Ad.c. 47.5~57.6 Vd.c. IP21 0000000000 IFpP52/161/120[1 6S]M/-10+50/90 LX A5.0-10 100 Ah 5.0 kWh 60 Ad.c. 60 Ad.c. 47.5~57.6 Vd.c. IP21 0000000000 6N·m...

  • Page 19: Electrical Connection

    06 Electrical Connection User Manual V1.0-2023-08-25 6 Electrical Connection 6.1 Safety Precaution DANGER • Power off the battery system before any operations to avoid danger. Strictly follow all safety precautions outlined in this manual and safety labels on the equipment during the operation.

  • Page 20: Direct Connection Mode

    Ethernet Cable [1]: The specification of cable should be decided by the normal charging and discharging current of inverters. [2]: If use non-GoodWe battery combiner box, please make the cable according to the guide of Chapter 6.5 of this manual.
  • Page 21 06 Electrical Connection User Manual V1.0-2023-08-25 360 A Battery Combiner Box Battery System Operation System Operation Note Current (A) Power (kW) Quantity n < n*60 Since the maximum bearable current of the battery combiner box is 360 A, please ensure that n≥6 the total battery charging and discharging power by the inverter does not exceed 18 kW.
  • Page 22 06 Electrical Connection User Manual V1.0-2023-08-25 720 A Battery Combiner Box Battery System Operation System Operation Note Current (A) Power (kW) Quantity n < n*60 Since the maximum bearable current of the battery combiner box is 720 A, please ensure that n≥12 the total battery charging and discharging power by the inverter does not exceed 36 kW.
  • Page 23 06 Electrical Connection User Manual V1.0-2023-08-25 DC Bus Battery Quantity n System Operation Current (A) System Operation Power (kW) n*60 ..L:Length Slave Main Inverter • L1=L2= L3 ... =L16 Inverter • L17=L18=L19 ... =L30 1≤n • L31=L32=L33=L34 BAT+ BAT- BAT+ BAT- L31 L32 DC Bus +...

  • Page 24: Connecting The Pe Cable

    06 Electrical Connection User Manual V1.0-2023-08-25 6.3 Connecting the PE cable NOTICE • Connect the PE cable first before installing the equipment. Disconnect the PE cable at last when dismantle the equipment. • Use a hydraulic plier to crimp the battery grounding terminal. Recommended hydraulic plier model: YQK-70.
  • Page 25 06 Electrical Connection User Manual V1.0-2023-08-25 Crimping Power Cable L=L1+ （ 1 ~ 2） mm L1=13.5±0.5 mm Connecting Cable of Batteriess Power Input & Output Ports 25-8 OT Terminal 6N·m Connecting Cable between Battery Combiner Box and Inverter 6N·m N·m Connection Rated Power of OT Terminal...

  • Page 26: Connecting The Communication Cable

    NOTICE Battery to inverter communication cable: • When the junction box is not used or when a GoodWe junction box is used, the commmmunication cable included in the inverter delivery can be used. • If use non-GoodWe battery combiner box, you need to short-circuit Pin3 and Pin8 to make a special communication cable according to the Non-GoodWe Battery Combiner Box Mode below.
  • Page 27 06 Electrical Connection User Manual V1.0-2023-08-25 GoodWe Battery Combiner Box Mode 1 2 3 4 5 6 7 8 Battery Battery Battery Inverter Combiner Combiner Port Port 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...

  • Page 28: Equipment Commissioning

    07 Equipment Commissioning User Manual V1.0-2023-08-25 7 Equipment Commissioning 7.1 Check Before Power ON Check the following items before power on to avoid the battery system being damaged. Checking Item The system is firmly installed in a clean place where is well-ventilated and easy to operate.

  • Page 29: Setting The Battery Parameters

    07 Equipment Commissioning User Manual V1.0-2023-08-25 7.3 Setting the Battery Parameters NOTICE Select the battery model via SolarGo app after powering on the battery system. So that the battery system can work properly. Step 1: Download SolarGo app. SolarGo SolarGo App Step 2: Connect inverter.
  • Page 30 07 Equipment Commissioning User Manual V1.0-2023-08-25 Step 3: Go to homepage, then click More >Quick Setting >Battery Access to enter the parameter setting page. Follow the prompts on the interface to enter the battery model selection interface and set the battery model. NOTICE •...

  • Page 31: Indicator Status

    07 Equipment Commissioning User Manual V1.0-2023-08-25 7.4 Indicator Status Normal status SOC indicator status Button Indicator status Battery system status SOC indicator indicates SOC of the Green light blink 1 The battery system is in battery system. time/s standby status SOC<5% Green light blink 2 5%≤SOC<25%...

  • Page 32: Maintenance

    08 Maintenance User Manual V1.0-2023-08-25 8 Maintenance 8.1 Power OFF the Battery System DANGER • Power off the battery system before operations and maintenance. Otherwise, the equipment may be damaged or electric shocks may occur. • Strictly follow the power off requirements to avoid damaging the system. NOTICE •...

  • Page 33: Routine Maintenance

    08 Maintenance User Manual V1.0-2023-08-25 8.2 Routine Maintenance WARNING • Contact the after-sales service for help if you find any problems that may influence the battery or the hybrid inverter. Disassemble without permission is strictly forbidden. • Contact after-sale service for help if the copper conductor is exposed. Do not touch or disassemble privately because the high voltage danger exists.
  • Page 34 08 Maintenance User Manual V1.0-2023-08-25 SOC indicator Fault Solutions status Battery Power off and wait for 2 hours. Contact the after-sale Overvoltage service if the problem persists. Battery Contact the after-sale service. Undervoltage High Cell Power off and wait for 2 hours. Contact the after-sale Temperature service if the problem persists.
  • Page 35 09 Technical Parameters User Manual V1.0-2023-08-25 Air Switch Contact the after-sale service. Adhesion Restart the battery. Contact the after-sale service if the Precharge Failure problem persists. Relay Power off and wait for 2 hours. Contact the after-sale Overtemperature service if the problem persists. Current Diverter Power off and wait for 2 hours.

  • Page 36: Technical Parameters

    09 Technical Parameters User Manual V1.0-2023-08-25 9 Technical Parameters Technical Parameters LX A5.0-10 2*LX A5.0-10 n*LX A5.0-10 Usable Energy （ kWh） * n×5 Battery Module LX A5.0-10： 51.2V 5.0kWh Number of Modules Cell Type LFP (LiFePO Nominal Voltage （ V） 51.2 Operating Voltage Range （...
