- Page 1 OTT HydroMet brand CHP1 and SHP1 Pyrheliometer Operational Manual...
- Page 2 2628 XH Delft The Netherlands +31 15 2755 210 solar-info@otthydromet.com www.otthydromet.com All rights reserved. All content is the intellectual property of OTT HydroMet. Reprinting, duplication and translation (even as excerpts) are only permitted with the prior written consent of OTT HydroMet. Subject to technical change.
-
Page 3: Table Of Contents
Table of contents Scope of supply Order numbers and variant code Product variants Accessories and spare parts About this manual Other applicable documents General signs and symbols Explanation of warnings General safety instructions Intended use Potential misuse Personnel qualification Operator obligations Personnel obligations Correct handling Certification... - Page 4 Instrument set-up Operation Making and saving measurements Collecting data Maintenance 10.1 Maintenance schedule 10.2 Replacing desiccant Troubleshooting 11.1 Error elimination Repair 12.1 Customer support Notes on disposing of old devices Technical data 14.1 Optical and electrical data 14.2 Dimensions and weight <4>...
-
Page 5: Scope Of Supply
1 Scope of supply The following items are included with delivery: – Pyrheliometer – Rain shield – Test reports – Instruction sheet – 2 desiccant bags <5>... -
Page 6: Order Numbers And Variant Code
2 Order numbers and variant code 2.1 Product variants Variant Order number CHP1 Pyrheliometer, 10 K + Pt-100, no plug, no cable 0368900-030 SHP1-V Smart Pyrheliometer, 0 to 1 V version, no plug, no cable 0375900-100 SHP1-A Smart Pyrheliometer, 4 to 20 mA version, no plug, no cable 0375900-200 2.2 Accessories and spare parts Data logging... -
Page 7: About This Manual
3 About this manual 3.1 Other applicable documents The following documents contain further information on installation, maintenance and calibration: 3.2 General signs and symbols The signs and symbols used in the operational manual have the following meaning: Practical tip This symbol indicates important and useful information. Action ü... -
Page 8: General Safety Instructions
4 Do not change or convert the product in any way. 4 Do not perform any repairs yourself. 4 Get OTT HydroMet to examine and repair any defects. 4 Ensure that the product is correctly disposed of. Do not dispose of it in household waste. -
Page 9: Certification
4.7 Certification CE (EU) The equipment meets the essential requirements of EMC Directive 2014/30/EU. FCC (US) FCC Part 15, Class "B" Limits This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. -
Page 10: Product Description
5 Product description 5.1 Design and function The pyrheliometer is designed to measure the direct short-wave irradiance (radiant flux, W/m ) which results from the radiant flux from a solid angle of 5 degrees. As standard CHP1 comes fitted with 10 kΩ thermistor and Pt-100 and temperature sensors; so that the small temperature dependency of sensitivity can be corrected in post-processing using the supplied test data. -
Page 11: Transport, Storage, And Unpacking
6 Transport, storage, and unpacking 6.1 Transport 4 Transport the product always in its original packaging. 4 Ensure that the product is not mechanically stressed during transport. 6.2 Storage 4 Store within specified temperature ranges. 4 Store in dry area. 4 Store in original box where possible. -
Page 12: Installation
7 Installation 7.1 Mechanical installation 7.1.1 Preparatory work 4 Check the desiccant and replace if necessary. 4 If using the digital output of the SHP1 pyrheliometer, set the Modbus ® address before visiting the site. Otherwise a computer and RS-485 / USB converter is required during installation. 7.1.2 Required tools and aids The following tools and aids are required: –... -
Page 13: Electrical Connections Of Shp Pyrheliometer
The use of attenuator circuits to modify the calibration factor is not recommended because the temperature response will also be affected. A high input bias current at the readout equipment can produce several micro-Volts across the impedance of the instrument and cable. The zero offset can be verified by replacing the instrument impedance at the readout equipment input terminals with a resistor. - Page 14 7.2.2.1 Power connection The minimum power supply voltage for the instrument is 5 V DC. 5-volt-power can only be used with a short cable, maximum 10 m. To ensure reliable performance, a voltage of 12 V DC is recommended. For the output of the power supply, it is recommended to protect it with a fast blowing fuse of maximum 250 mA rating. 7.2.2.2 Power consumption Typical power consumption SHP1-V for maximum output (1 V) Voltage (V DC)
- Page 15 7.2.2.4 Analog current output The SHP1-A (current version) is factory set to 0 to 1600 W/m for 4 to 20 mA. Negative inputs will make the output go below 4 mA. The irradiance value (E ) for the default setting can be calculated as shown below: solar ↓...
-
Page 16: Grounding Instrument
7.2.3 Grounding instrument Lightning can induce high voltages in the shield but these will be led off at the instrument or readout equipment. The shield of the cable is connected to the aluminum housing of the instrument through the plug body. 4 If there is no good ground connection at the instrument, connect the shield at the cable end to the ground at the readout equipment. -
Page 17: Commissioning
8 Commissioning 8.1 Instrument set-up The Smart Explorer software allows to configure a smart sensor and to collect real-time data. The factory default communication parameters are as follows: – Modbus ® baud rate: 19200 – Parity: even – Data bits: 8 –... -
Page 18: Operation
9 Operation 9.1 Making and saving measurements The instruments require suitable sources of power and radiation (light) to operate and make measurements. 4 To save the measurements, connect the instrument to a readout or data storage device. The instrument has no internal data memory. -
Page 19: Maintenance
4 Check all cables for damage. 4 Check the instrument mounting. 2 years 4 Check sensitivity or have a recalibration performed. OTT HydroMet 10.2 Replacing desiccant The desiccant can be replaced with the following steps: 4 Unscrew the drying cartridge from the instrument housing. If the cartridge is tight, then use a 16 mm or ⅝"... -
Page 20: Troubleshooting
4 Replace the desiccant, if water is deposited on the inside of the window. 4 Report any malfunctions or damage to the representative of OTT HydroMet. For CHP1 pyrheliometer: 4 Check the impedance. See specifications for expected values. -
Page 21: Repair
12 Repair 12.1 Customer support 4 Have repairs carried out by OTT HydroMet service personnel. 4 Only carry out repairs yourself, if you have first consulted OTT HydroMet. 4 Contact your local representative: www.otthydromet.com/en/contact-us 4 Include the following information: – instrument model –... -
Page 22: Notes On Disposing Of Old Devices
In accordance with the German Electrical and Electronic Equipment Act (ElektroG; national implementation of EU Directive 2012/19/EU), OTT HydroMet takes back old devices in the Member States of the European Union and disposes of them in the proper manner. The devices that this concerns are labeled with the following symbol: 4 For further information on the take-back procedure contact OTT HydroMet: OTT HydroMet B.V. -
Page 23: Technical Data
14 Technical data 14.1 Optical and electrical data Specification CHP1 SHP1 Response time (63 %) 1.7 s 0.7 s < < Response time (95 %) 5 s 2 s < < Zero offset, temperature change (5 K/ 1 W/m 1 W/m < < Non-stability (change/year) 0.5 % 0.5 % < < Non-linearity (0 to 1000 W/m 0.2 % 0.2 %... -
Page 24: Dimensions And Weight
14.2 Dimensions and weight 322 mm 74 mm 195.6 mm CHP1 and SHP1, 900 g <24>... - Page 25 <25>...
- Page 26 <26>...
- Page 27 <27>...
- Page 28 Contact Information...
