Jet BD-11G Operating Manual page 42

DESCRIPTION
Magnetic Contactor
Fwd/0/Rev - Switch
Contactor
Transformer
Transformer (Optional) 230V-24V/20VA
Emergency stop
Gear Guard Switch
Chuck Guard Switch
Light Switch (Optional) KCD1-101
Work light
Pump Switch (Optional) LAY5-BE101
Main Motor
Pump (Optional)
BD-11G Electrical Parts List
TYPE
IP-55 AC-1 18A Ue250V
KJD17GF
AC-3 15A CE
Ue 250V IEN 12A 5E4
ZH-A
CE
UI 690V IEN 20A
LC1K0910
CE
20VA 230VAC
230V/24V/20VA
CE
20VA 230VAC
CE
AE-15 240V IEN 10A
LAY5
CE
AC-15 14A 250V IP54
QKS8
CE
AC-15 3A IP62 Ue380V
LXW5-11Q1
CE
6A AC250V CE
5W AC12-24V
24V
CE
Ue220V IEN3.3A AC-15 CE
1.1Kw AC230V 6.4A IP54
YLJ90L4-12A
CE
40W AV230V 0.9A IP54
DB-12A
CE
SPECIFICATION
42
Qty. Part No.
1 BD-11GV-E1
1 BD-11GV-E2
1 BD-11GV-E3
1 BD-11GV-E4
1 BD-11GV-E5
1 BD-11GV-E6
1 BD-11GV-E7
1 BD7VS-151
1 BD-11GV-E9
1 BD-11GV-E10
1 BD7VS-910
1 MS9024
1 BD7VS-908
