WCP C2128/C2636/C3545
CC C2128/C2636/C3545
Procedures Manual
CM01700
November 2004
Launch

Advertisement

loading
Need help?

Need help?

Do you have a question about the WCP C2128 and is the answer not in the manual?

Questions and answers

Related Manuals for Xerox WCP C2128

Summary of Contents for Xerox WCP C2128

  • Page 1 WCP C2128/C2636/C3545 CC C2128/C2636/C3545 Procedures Manual CM01700 November 2004 Launch...

  • Page 2: Revision Control List

    Issue While every care has been taken in the preparation of this manual, no lia- bility will be accepted by Xerox aris- ing out of the use of this Carrier Manual including, but not limited to, inaccuracies or omissions. This manual is for informational purposes only.

  • Page 3: Table Of Contents

    CONTENTS 0.0.1 General Information ........ 3 Preparing the Office Finisher (URE), if present ..........61 Product Codes and Part Numbers ..3 Preparing the Advanced (TWE) and Product Weights and Sizes ....3 Professional (TWF) Finishers .... 64 Serial Plate Location ......5 Preparing the Scanner .......
  • Page 4 U.S.A. Canada Xerox Europe Install Product AO (60 Hz) AO (50 Hz) (60 Hz) (60 Hz) (50 Hz) Responsibility WCP/CC IOT Scanner w/DADF VALO Scanner w/Platen VALO Scanner Stand VALO 1 Tray Module w/Cabinet VALO 3 Tray Module VALO High Capacity Feeder...

  • Page 5: General Information

    General Information - Product Codes and Part Numbers Packaged Weight Packaged Size (L x W x H) Product Code/ Stack Install Part Number Height Strategy* 889 x 762 x 1347 35 x 30 x 53 1167 x 737 x 610 42 x 29 x 24 851 x 788 x 1613 33.5 x 31 x 63.5...
  • Page 6 General Information - Product Weights and Sizes Unpackaged Weight Unpackaged Size (L x W x H) Product Code/ Part Number 966 x 788 x 1143 38 x 31 x 45 559 x 610 x 1016 22 x 24 x 40 559 x 610 x 1016 22 x 24 x 40 * Install strategy will either be Drop-off (DO) or Carrier Install (CI)

  • Page 7: Serial Plate Location

    General Information - Serial Plate Location 1.3.1 1.3.2 1.3.3 1.3.4 1.3.0 Serial Plate Location 1.3.1 WCP/CC C2128/C2636/ C3545 1.3.2 Scanner, under the platen glass 1.3.3 Office Finisher 1.3.4 Advanced Finisher and Professional Finisher Launch - November 2004 WCP/CC C2128/C2636/C3545...

  • Page 8: Location Of The Power Switch

    General Information - Location of the Power Switch 15 Amp 1.4.1 1.5.1 1.4.0 Location of the Power Switch 1.4.1 The power switch is located on the front right cor- ner of the WCP/CC C2128/ C2636/C3545 1.5.0 Product Amp Identification 1.5.1 This is a 15 Amp machine.

  • Page 9: Warehouse

    Warehouse - Unpacking the WCP/CC C2128/C2636/C3545 13 mm 2.2.1 2.3.1 2.3.2 2.3.3 2.0.0 Warehouse 2.3.3 Remove the plastic bag from around the machine. 2.1.0 Unpacking the WCP/ CC C2128/C2636/C3545 2.2.0 Tools and Materials Required 2.2.1 Tools and materials required to unpack the WCP/ CC C2128/C2636/C3545 are shown.
  • Page 10 Warehouse - Depalletizing the WCP/CC C2128/C2636/C3545 2.3.4 2.3.5 13 mm 2.3.6 2.3.7 2.3.4 Remove the tie-wrap securing the scanner stand to the machine. 2.3.5 Using a ramp remove the scanner and stand from the pallet by rolling it away from the machine.
  • Page 11 Warehouse - Depalletizing the WCP/CC C2128/C2636/C3545 2.3.8 2.3.9 2.3.10 2.3.11 2.3.8 Remove the four ship- ping brackets. 2.3.9 Recycle the four ship- ping brackets and eight bolts. 2.3.10 Remove the machine from the pallet using a ramp. Recycle the pallet. 2.3.11 The machine is deliv- ered to the Customer site taped as shown.
  • Page 12 Warehouse - Depalletizing the WCP/CC C2128/C2636/C3545 2.3.12 2.3.13 2.3.12 The scanner and stand are delivered to the Customer site as shown. 2.3.13 Place the bubble packed toner cartridges on the accessory pallet and secure with tape. WCP/CC C2128/C2636/C3545 Launch - November 2004...

  • Page 13: Unpack And Depalletize The Advanced/Professional Finisher, If Present

    Warehouse - Unpack and Depalletize the Advanced/Professional Finisher, if present 2.4.1 2.4.2 2.4.3 2.4.4 2.4.0 Unpack and Depalletize the Advanced/Professional Finisher, if present 2.4.1 Cut the bands securing the box to the pallet. 2.4.2 Remove the top of the box. 2.4.3 Remove the four plastic clips from the box.
  • Page 14 Warehouse - Unpack and Depalletize the Advanced/Professional Finisher, if present 2.4.5 2.4.6 2.4.7 2.4.8 2.4.5 Remove the four corner posts. 2.4.6 Remove the H-Trans- port box. 2.4.7 Remove the left side fin- isher cover box. 2.4.8 Remove the cardboard and styrofoam packing. WCP/CC C2128/C2636/C3545 Launch - November 2004...
  • Page 15 Warehouse - Unpack and Depalletize the Advanced/Professional Finisher, if present 2.4.9 2.4.10 2.4.11 2.4.12 2.4.9 Remove the boxed fin- isher tray. 2.4.10 Remove the boxed booklet maker tray, if present. 2.4.11 Remove the styrofoam shelf. WARNING: Due to its size and weight, two people are required to remove the finisher from the styrofoam supports.

  • Page 16: Preparing The Office Finisher, If Present

    Warehouse - Preparing the Office Finisher, if present 2.4.13 2.4.14 2.5.1 2.4.13 Tip the finisher and remove the second styro- foam support. 2.4.14 Depalletize the finisher using a ramp. 2.5.0 Preparing the Office Finisher, if present 2.5.1 The Office Finisher, if present, is delivered to the Customer site fully boxed.

  • Page 17: Delivery

    Delivery - Preparing for Delivery 501E3500 95E2940 3.1.1 3.1.2 501E3500 3.1.3 3.1.4 3.0.0 Delivery 3.1.0 Preparing for Delivery 3.1.1 Tools and materials required to move the WCP/CC C2128/C2636/C3545 to the Customer site are shown. 3.1.2 Move the depalletized machine to the truck. 3.1.3 Move the scanner stand to the truck.

  • Page 18: Strapping Procedures

    Delivery - Strapping Procedures 95E2940 95E2940 3.2.1 3.2.2 3.2.0 Strapping Procedures When positioning the printer under the scan- When positioning the ner stand, ensure the scanner stand into the rear of the printer is against truck, ensure the blan- the wall of the truck. ket covers the entire rear of the stand.
  • Page 19 Delivery - Strapping Procedures 9 in. 19 in. 3.2.3 3.2.4 3.2.5 3.2.6 When strapping the 3.2.4 Using two straps, secure WCP/CC C2128/ the machine and scanner C2636/C3545 into the stand into the truck. truck, ensure to run the straps only 9 inches down from the 3.2.5 Use a four wheel dolly to top of the printer, 19 inches up move the office finisher, if...
  • Page 20 Delivery - Strapping Procedures 501E3500 3.2.7 3.2.8 3.2.9 3.2.10 3.2.7 Remove the plastic bag from over the Advanced/Pro- fessional finisher, if present. 3.2.8 Attach two foam blocks on the left side of the finisher. 3.2.9 Replace the plastic bag over the finisher. 3.2.10 Position the finisher with the foam blocks facing the truck wall.
  • Page 21 Delivery - Strapping Procedures 3.2.11 3.2.12 3.2.13 3.2.14 3.2.11 Cover the finisher with a blanket. 3.2.12 Place corner boards at the two corners and secure the finisher to the truck wall with two straps. 3.2.13 Place the “C” finisher parts on a four wheel dolly and move them to the truck.

  • Page 22: Turning Radii

    Delivery - Turning Radii 3.3.1 Space Requirements for Room Dimension 2616 1727 25.4 Table 3.4.1 3.4.1 3.3.0 Turning Radii 3.3.1 The dimensions of the WCP/CC C2128/C2636/ C3545 modules are small enough that there will be no problems fitting through nar- row hallways.

  • Page 23: Unpacking The Wcp/Cc C2128/ C2636/C3545 Processor

    Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.1 3.5.2 3.5.3 3.5.4 3.5.0 Unpacking the WCP/ CC C2128/C2636/C3545 Processor 3.5.1 Remove the tape from the processor. 3.5.2 Lower the bypass tray remove the foam pack- ing material. 3.5.3 Open tray 2 and remove tray labels and power cord and set aside.
  • Page 24 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.5 3.5.6 3.5.7 3.5.8 3.5.5 Locate the four toner car- tridge locations. 3.5.6 Remove the yellow toner cartridge from the bubble packed bundle. 3.5.7 Shake the toner car- tridge. 3.5.8 Slide the yellow toner cartridge into position with the yellow tab on the right and the arrow on top.
  • Page 25 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.9 3.5.10 3.5.11 3.5.12 3.5.9 Turn the toner catridge clockwise until it hits the stop. 3.5.10 Load the magenta, cyan and black toner car- tridges by repeating step 3.5.7 through step 3.5.9. 3.5.11 Close the front door. 3.5.12 Remove the tape from the top of the scanner and document feeder.
  • Page 26 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.13 3.5.14 3.5.15 3.5.16 3.5.13 Open the document cover and remove the pack- ing material. Remove the configuration sheet from the platen glass. Close the doc- ument cover. 3.5.14 Fold the configura- tion sheet. Open tray 1.
  • Page 27 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.17 3.5.18 3.5.19 3.5.20 3.5.17 Ensure the controller 3.5.19 Connect the scanner data cable is secured to the cable to the controller and controller and the rear of the secure with thumbscrews. machine. Ensure the con- troller power cord is secured to 3.5.20 Connect the Scanner...
  • Page 28 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.21 3.5.22 3.5.23 3.5.24 3.5.21 Connect the FAX 3.5.24 Retrieve and unpack phone line to the controller in the rear wall, if present. the Line 1 jack. Connect the FAX line to the wall jack, if present.
  • Page 29 3.5.28 3.5.25 Retrieve the FAX logo, if FAX is present. 3.5.26 Attach the FAX logo to the FIB covering the XEROX logo. 3.5.27 With the rear wall on a flat surface press the FIB into the top of the rear wall.
  • Page 30 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.29 3.5.30 3.5.31 3.5.32 3.5.29 Tighten the screws securing the brackets to the stand. 3.5.30 Remove the plastic sheet from the touch screen. 3.5.31 Open the document cover. 3.5.32 Locate the two slots in the tray and the two hooks on the machine and...
  • Page 31 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.33 3.5.34 3.5.35 3.5.36 3.5.33 Secure the tray with the two thumbscrews taped to the tray. 3.5.34 Slide the long docu- ment support into the exit tray. 3.5.35 Unpack the left work surface. 3.5.36 Place the left work sur- face upsidedown on a flat sur- face.
  • Page 32 Delivery - Unpacking the WCP/CC C2128/C2636/C3545 Processor 3.5.37 3.5.38 3.5.37 Position the left work surface on the left side of the scanner and secure with five screws. 3.5.38 Close the document cover. WCP/CC C2128/C2636/C3545 Launch - November 2004...

  • Page 33: Unpacking And Installing The Office Finisher (If Present)

    Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.1 3.6.2 3.6.3 3.6.4 3.6.0 Unpacking and Installing the Office Finisher (if present) 3.6.1 Tools required to install the finisher are shown. 3.6.2 Open the finisher box. 3.6.3 Remove the finisher module box from the over pack box.
  • Page 34 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.5 3.6.6 3.6.7 3.6.8 3.6.5 Open the finisher parts box. 3.6.6 Remove the top card- board tray from the parts box. 3.6.7 Remove the foam tray from the parts box. 3.6.8 Remove the two side frames from the parts box.
  • Page 35 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.9 3.6.10 3.6.11 3.6.12 3.6.9 Ensure the processor is out from under the scanner as shown. 3.6.10 Remove the front rear side frames from their plastic bags. 3.6.11 Remove the black phil- lips head screw on the lower right rear of the machine.
  • Page 36 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.13 3.6.14 3.6.15 3.6.16 3.6.13 Locate the pins on the rear side frame and slots on the lower right side front of the machine. 3.6.14 Insert the pins into the slots and push down.
  • Page 37 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.17 3.6.18 3.6.19 3.6.20 3.6.17 Retrieve the bag with the two silver plates and remove the two white thumb- screws. 3.6.18 Secure the front and rear side plates to the machine using the two white thumbscrews.
  • Page 38 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.21 3.6.22 3.6.23 3.6.24 3.6.21 Locate the slots on the rear side frame. 3.6.22 Locate the slots on the front side frame. 3.6.23 Insert the hooks on the bottom shelf into the slots on the rear side frame.
  • Page 39 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.25 3.6.26 3.6.27 3.6.28 3.6.25 Remove the two foam blocks. 3.6.26 Remove the plastic bag. 3.6.27 Remove the finisher module from the box. 3.6.28 Carefully remove the tape and foam packing mate- rial from around the black actuator pulling the foam away from the finisher as shown.
  • Page 40 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.29 3.6.30 3.6.31 3.6.32 3.6.29 Remove the cardboard spacer. 3.6.30 Remove all exterior tape. 3.6.31 Remove the bubble pack from the end of the har- ness. 3.6.32 Open the finisher module front door and remove the tape.
  • Page 41 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.33 3.6.34 3.6.35 3.6.36 3.6.33 Locate and remove the foam packing material. Locate the twist-tie. 3.6.34 Remove the twist-tie securing the stapler unit in place. 3.6.35 Close the front door. 3.6.36 Position the finisher module on the base and slide to the right.
  • Page 42 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.37 3.6.38 3.6.39 3.6.40 3.6.37 Align the finisher mod- ule with the base. 3.6.38 Remove the two thumb- screws used to lock the rails in place for shipping. 3.6.39 Using the two screws removed in step 3.6.38, secure the side frames to the machine.
  • Page 43 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.41 3.6.42 3.6.43 3.6.44 3.6.41 Position the output tray on the finisher elevator as shown. 3.6.42 Secure the output tray using the white thumb screw, located in the bag with the sil- ver plates.
  • Page 44 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.45 3.6.46 3.6.47 3.6.48 3.6.45 Insert the tabs in the slots and rotate the cover until it snaps into place. 3.6.46 Slide the finisher mod- ule away from the machine 3.6.47 Check for a gap between the machine and the side frames.
  • Page 45 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.49 3.6.50 3.6.51 3.6.52 3.6.49 The side frames must be flush with the machine as shown. 3.6.50 Remove the two metal plates and three screws from the plastic bag. 3.6.51 Secure the two brack- ets to the right side of the machine as shown with the two thumbscrews.
  • Page 46 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.53 3.6.54 3.6.55 3.6.56 3.6.53 Raise the H-trans- port cover and remove the packing material. 3.6.54 Remove the H-trans- port exterior tape. 3.6.55 Remove the plastic from the ground strap. 3.6.56 Retrieve and unpack the angle bracket.
  • Page 47 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.57 3.6.58 3.6.59 3.6.60 3.6.57 Insert the angle bracket into the slot on the H-transport. 3.6.58 Align the H-transport angle bracket with the indent in the finisher module. 3.6.59 Locate the notch on the two arms on the H-transport 3.6.60 Place the notches over the pins in the finisher module.
  • Page 48 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.61 3.6.62 3.6.63 3.6.64 3.6.61 Ensure the gap is even between the H-transport and the finisher module, and that it is latched in place. 3.6.62 Retrieve the gate assembly and remove the bubble pack.
  • Page 49 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.65 3.6.66 3.6.67 3.6.68 3.6.65 Locate the exit area of the machine. 3.6.66 Locate the two slots on the right side of the exit area. 3.6.67 Insert the tabs on the gate assembly into the slots on the right side of the exit area.
  • Page 50 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.69 3.6.70 3.6.71 3.6.72 3.6.69 Push down on the left side of the gate assembly until it snaps into place. 3.6.70 Locate the H-transport alignment slots on the gate assembly. 3.6.71 Locate the alignment tabs on the H-transport.
  • Page 51 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.73 3.6.74 3.6.75 3.6.76 3.6.73 Connect the harness from the finisher to the H-transport. 3.6.74 Move the finisher away from the machine. 3.6.75 Connect the plug to the right side of the machine. 3.6.76 Move the finisher to the home position.
  • Page 52 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.77 3.6.78 3.6.79 3.6.80 The feet on the base of 3.6.78 Ensure the gap the finisher might need between the H-transport and to be raised to move exit assembly is even front to the machine into position back.
  • Page 53 Delivery - Unpacking and Installing the Office Finisher (if present) 3.6.81 3.6.82 3.6.83 3.6.84 3.6.81 Open the finisher front door. 3.6.82 Retrieve the staple car- tridge. 3.6.83 Slide the staple car- tridge into place. 3.6.84 Close the finisher front door. Launch - November 2004 WCP/CC C2128/C2636/C3545...

  • Page 54: Installing Advanced/Professional Finisher, If Present

    Delivery - Installing Advanced/Professional Finisher, if present 3.7.1 3.7.2 3.7.3 3.7.4 3.7.0 Installing Advanced/ Professional Finisher, if present 3.7.1 Open the left side door. 3.7.2 Open the H-Transport box and remove the H-Trans- port. 3.7.3 Remove the foam pack- ing material from the H-Trans- port.
  • Page 55 Delivery - Installing Advanced/Professional Finisher, if present 3.7.5 3.7.6 3.7.7 3.7.8 3.7.5 Position the H-Transport 3.7.8 Secure the H-Transport on top of the machine as to the machine with two shown. screws. CAUTION: Ensure the blue tab is down and against the left side of the top cover and the bottom of the H-Transport is flush and...
  • Page 56 Delivery - Installing Advanced/Professional Finisher, if present 3.7.9 3.7.10 3.7.11 3.7.12 3.7.9 Attach the H-Transport ground wire to the thumb screw of the controller cable. 3.7.10 Remove the two screws securing the right side cover. Attach the docking plate to the right side of the machine with two screws packed with the finisher.
  • Page 57 Delivery - Installing Advanced/Professional Finisher, if present 3.7.13 3.7.14 3.7.15 3.7.16 3.7.13 Fold the configura- tion sheet, if present. Open tray 1. Put configuration sheet behind plastic door. Close tray 1. 3.7.14 Attach the ground plate to the bottom frame of the fin- isher with one screw.
  • Page 58 Delivery - Installing Advanced/Professional Finisher, if present 3.7.17 3.7.18 3.7.19 3.7.20 3.7.17 Open the Booklet Maker Tray box, if present and remove the tray. 3.7.18 Start the screw at the lower part of the finisher. Set the tray on the screw and tighten the screw.
  • Page 59 Delivery - Installing Advanced/Professional Finisher, if present 3.7.21 3.7.22 3.7.23 3.7.24 3.7.21 Install the staple car- tridge. 3.7.22 Position the finisher up against the IOT docking plate. Secure the docking latch levers with the screw. 3.7.23 Ensure the gap between the finisher and IOT is parallel from top to bottom.

  • Page 60: Ready-To-Run

    Ready-To-Run - Tools Required 4.1.1 4.2.1 4.2.2 4.2.3 4.0.0 Ready-To-Run 4.2.2 Connect the power cord to the machine and then the wall outlet. 4.1.0 Tools Required 4.1.1 The tool required for 4.2.3 Switch on the main Ready to Run is shown. power switch.

  • Page 61: Functional Check

    Ready-To-Run - Functional Check 4.3.1 4.4.1 4.3.0 Functional Check Use the Functional Check located in the WCP/CC C2128/ C2636/C3545 driver’s check- list. 4.3.1 Perform the Functional Check. 4.4.0 Product Demonstration Use the Product Dem- onstration located in the WCP/CC C2128/ C2636/C3545 driver’s check- list.

  • Page 62: Simple Relocation

    Simple Relocation - Preparing the Processor 5.0.1 5.1.1 5.1.2 5.1.3 5.0.0 Simple Relocation bi-directional parallel cable from their computer. If the 5.0.1 The tool required for the WCP/CC C2128/C2636/ simple relocation of the WCP/ C3545 is connected to the net- CC C2128/C2636/C3545 is work, ask the Customer to dis- shown.

  • Page 63: Preparing The Office Finisher (Ure), If Present

    Simple Relocation - Preparing the Office Finisher (URE), if present 5.2.1 5.2.2 5.2.3 5.2.4 5.2.0 Preparing the Office Finisher (URE), if present 5.2.1 Disconnect the harness to the finisher H-transport. 5.2.2 Slide the finisher away from the machine. 5.2.3 Disconnect the finisher power plug from the machine.
  • Page 64 Simple Relocation - Preparing the Office Finisher (URE), if present 5.2.5 5.2.6 5.2.7 5.2.8 5.2.5 Lift the H-transport off the finisher module. 5.2.6 Remove the finisher lower cover by pushing up on the two tabs on the underside of the cover and rotate it up and out.
  • Page 65 Simple Relocation - Preparing the Office Finisher (URE), if present 5.2.9 5.2.10 5.2.11 5.2.12 5.2.9 Remove the two thumb- screws securing the finisher module to the lower side frames. 5.2.10 Screw the two thumb- screws into the rails to secure the rails.

  • Page 66: Preparing The Advanced (Twe) And Professional (Twf) Finishers

    Simple Relocation - Preparing the Advanced (TWE) and Professional (TWF) Finishers 5.3.1 5.3.2 5.3.0 Preparing the Advanced (TWE) and Professional (TWF) Finishers 5.3.1 Disconnect the data cable, IOT interface cable power cord. 5.3.2 Open the finisher front door and remove the screw securing the release latch.

  • Page 67: Preparing The Scanner

    Simple Relocation - Preparing the Scanner 5.4.1 5.4.2 5.4.3 5.4.4 5.4.0 Preparing the Scanner 5.4.1 Disconnect the scanner power cord from the rear of the machine. 5.4.2 Disconnect the scanner cable and USB cable from the controller. 5.4.3 Remove the screws securing the left work surface to the scanner stand and remove the left work sur-...

  • Page 68: Relocating The Modules

    Simple Relocation - Relocating the Modules 5.4.5 5.4.6 13 mm 5.4.7 5.5.1 5.4.5 Reinstall the two white thumbscrews into the right side of the scanner. 5.4.6 Remove the rear wall from the rear of the scanner stand. 5.4.7 Place the left shelf exit tray on top of the scanner and secure with...

  • Page 69: Reinstalling The Modules

    Simple Relocation - Reinstalling the Modules 5.5.2 5.5.3 5.5.4 5.6.1 5.5.2 Move the scanner and scanner stand to the new loca- tion. 5.5.3 Move the finisher mod- ule, lower cover, exit tray, and H-Transport, if present, to the new location. 5.5.4 Move the Advanced/Pro- fessional finisher to the new location, if present.
  • Page 70 Simple Relocation - Reinstalling the Modules 5.6.2 5.6.3 5.6.4 5.6.5 5.6.2 Connect the scanner cable and USB cable to the controller. 5.6.3 Position the left work surface on the left side of the scanner and secure with five screws. 5.6.4 Remove the two white thumbscrews located on the right side of the scanner.
  • Page 71 Simple Relocation - Reinstalling the Modules 5.6.6 5.6.7 5.6.8 5.6.9 5.6.6 Slide the rear wall onto the two brackets on the back of the scanner stand. Reinstall the Office Finisher (URE), if present 5.6.7 Position the finisher module on the base and slide to the right.
  • Page 72 Simple Relocation - Reinstalling the Modules 5.6.10 5.6.11 5.6.12 5.6.13 5.6.10 Retrieve and position the output tray on the finisher elevator as shown. 5.6.11 Secure the output tray using the white thumbscrew taped to the tray. 5.6.12 Retrieve the finisher module lower cover.
  • Page 73 Simple Relocation - Reinstalling the Modules 5.6.14 5.6.15 5.6.16 5.6.17 5.6.14 Insert the tabs in the slots and rotate the cover until it snaps into place. 5.6.15 Slide the finisher mod- ule away from the processor. 5.6.16 Locate the notch on the two arms on the H-transport.
  • Page 74 Simple Relocation - Reinstalling the Modules 5.6.18 5.6.19 5.6.20 5.6.21 5.6.18 Ensure the gap is even between the H-transport and the finisher module and that it is latched in place. 5.6.19 Locate the H-transport alignment slots on the gate assembly. 5.6.20 Locate the alignment tabs on the H-transport.
  • Page 75 Simple Relocation - Reinstalling the Modules 5.6.22 5.6.23 5.6.24 5.6.25 5.6.22 Connect the harness from the finisher to the H-transport. 5.6.23 Move the finisher away from the machine. 5.6.24 Connect the power plug to the right side of the machine. 5.6.25 Move the finisher to the home position.
  • Page 76 Simple Relocation - Reinstalling the Modules 5.6.26 5.6.27 5.6.28 5.6.29 5.6.26 Attach the H-transport ground strap to the scanner stand with the screw. 5.6.27 Open paper tray 1 remove the power cord. Close paper tray 1. 5.6.28 Connect the power cord to the rear of the proces- sor and then the wall outlet.
  • Page 77 Simple Relocation - Reinstalling the Modules 5.6.30 5.6.31 5.6.32 5.6.33 5.6.30 Adjust the feet to the 5.6.33 Connect the data finisher base so the side cable, IOT interface cable frames touch the processor power cord. right side cover, if present. Reinstall the Advance (TWE)/ Professional (TWF) Finisher, if present...
  • Page 78 Simple Relocation - Reinstalling the Modules 5.6.34 5.6.35 5.6.34 Switch the main power switch on. Use the Functional Check located in the WCP/CC C2128/ C2636/C3545 driver’s check- list. 5.6.35 Perform the Functional Check. WCP/CC C2128/C2636/C3545 Launch - November 2004...

  • Page 79: Complex Relocation

    Complex Relocation - Preparing the Office Finisher (URE), if present Perform all steps of “Simple Relocation” of the office finisher, page 61, except 95E67480 for relocating the finisher. 6.1.1 6.1.2 6.1.3 6.1.4 6.0.0 Complex 6.1.4 Place the finisher exit tray on the finisher module. Relocation Ensure the tray covers the black actuator to protect it from...
  • Page 80 Complex Relocation - Preparing the Office Finisher (URE), if present 6.1.5 6.1.6 6.1.7 6.1.8 6.1.5 Secure the tray to the fin- isher module with tape. 6.1.6 Wrap the finisher module in bubble pack. 6.1.7 Open the H-transport top cover. Use a screw driver to lift up on the black tab locking the L bracket in place slide the L bracket out...
  • Page 81 Complex Relocation - Preparing the Office Finisher (URE), if present 6.1.9 6.1.10 6.1.11 6.1.12 6.1.9 Secure the L bracket to the back of the H-transport with tape. Tape the ground strap to the H-transport. 6.1.10 Wrap the H-transport in bubble pack. 6.1.11 Wrap the finisher lower cover in bubble pack.
  • Page 82 Complex Relocation - Preparing the Office Finisher (URE), if present 6.1.13 6.1.14 6.1.15 6.1.16 6.1.13 Remove the thumb- screw securing the front side frame and remove the side frame. 6.1.14 Remove the thumb- screw securing the rear side frame and remove the side frame.
  • Page 83 Complex Relocation - Preparing the Office Finisher (URE), if present 6.1.17 6.1.18 6.1.19 6.1.20 6.1.17 Wrap the exit assembly in bubble pack. 6.1.18 Wrap the silvers spacers and all hardware in bubble pack. Attach the bubble packed hardware to the inside of the rear side frame.
  • Page 84 Complex Relocation - Preparing the Office Finisher (URE), if present 95E67480 6.1.21 6.1.22 6.1.23 6.1.24 6.1.21 Wrap the bottom shelf in bubble pack. 6.1.22 Retrieve a generic box 95E67480. Place three layers of bubble pack at the bottom of the box. 6.1.23 Place the finisher module in the box with the exit...
  • Page 85 Complex Relocation - Preparing the Office Finisher (URE), if present 6.1.25 6.1.26 6.1.27 6.1.28 6.1.25 Place the H-transport in the box on top of the finisher module. 6.1.26 Place the finisher bottom cover in the box. Place the bottom shelf in the box.

  • Page 86: Preparing The Advanced (Twe)/ Professional (Twf) Finisher, If Present

    Complex Relocation - Preparing the Advanced (TWE)/Professional (TWF) Finisher, if 6.1.29 6.2.1 Perform all steps of “Simple Relocation” of the finisher, page 75, except for relocating the finisher. 6.2.2 6.2.3 6.1.29 Close the box and seal with tape. 6.2.0 Preparing the Advanced (TWE)/ Professional (TWF) Finisher, if present...
  • Page 87 Complex Relocation - Preparing the Advanced (TWE)/Professional (TWF) Finisher, if 6.2.4 6.2.5 6.2.6 6.2.7 6.2.4 Remove the screw 6.2.7 Tape the middle tray securing the ground plate to and booklet maker tray, if the bottom of the finisher. present, to the top of the fin- Tape the screw to the plate.

  • Page 88: Preparing The Processor

    Complex Relocation - Preparing the Processor Perform all steps of “Simple Relocation” of the processor, page 60, except for relocating the processor. 6.3.1 6.3.2 6.3.3 6.4.1 6.3.0 Preparing the Processor 6.3.1 Materials required for the complex relocation of the pro- cessor are shown.

  • Page 89: Relocating The Modules

    Complex Relocation - Relocating the Modules Perform all steps of “Simple Relocation” of the scanner, page 65, except for relocating the scanner. 6.4.2 6.4.3 6.5.1 6.5.2 6.4.2 Perform all steps of “Simple Relocation” of the Scanner, page 65, except for relocating the scanner.
  • Page 90 Complex Relocation - Relocating the Modules 6.5.3 6.5.4 6.5.3 Move the WCP/CC C2128/C2636/C3545 to the truck. 6.5.4 Place the boxed fin- isher on a four wheel dolly. Move the boxed finisher, if present, to the truck. WCP/CC C2128/C2636/C3545 Launch - November 2004...

  • Page 91: Removal

    Removal - Relocating the Modules 95E2940 95E2940 7.0.1 7.0.2 7.0.0 Removal When positioning the printer under the scan- When positioning the ner stand, ensure the scanner stand into the rear of the printer is against truck, ensure the blan- the wall of the truck. ket covers the entire rear of the stand.
  • Page 92 Removal - Relocating the Modules 9 in. 19 in. 7.0.3 7.0.4 7.0.5 7.0.6 When strapping the 7.0.4 Cover the scanner WCP/CC C2128/ with a blanket. Using two C2636/C3545 into the straps, secure the machine truck, ensure to run the straps and scanner and stand into the only 9 inches down from the truck.
  • Page 93 Removal - Relocating the Modules 501E3500 7.0.7 7.0.8 7.0.9 7.0.10 7.0.7 Move the Advanced/Pro- fessional finisher to the truck, if present. 7.0.8 Attach two foam blocks on the left side of the finisher. 7.0.9 Position the finisher with the foam blocks facing the truck wall.

  • Page 94: Repack/Return To Sec

    Repack/Return to SEC - Tools and Materials Required 74K93850 13 mm 74K93850 8.1.1 8.2.1 8.2.2 8.2.3 8.0.0 Repack/Return to 8.2.3 Open the left side door. 8.1.0 Tools and Materials Required 8.1.1 Tools and materials required for repacking the WCP/CC C2128/C2636/ C3545 are shown.
  • Page 95 Repack/Return to SEC - Repacking the Processor 8.2.4 8.2.5 8.2.6 8.2.7 8.2.4 Remove the two screws securing the H-Transport to the machine. Secure the two screws to the H-Transport with tape. 8.2.5 Lift the H-Transport from the top of the machine and set aside.
  • Page 96 Repack/Return to SEC - Repacking the Processor 8.2.8 8.2.9 8.2.10 8.2.11 8.2.8 Palletize the WCP/CC C2128/C2636/C3545 using a ramp. 8.2.9 Position the four ship- ping brackets by inserting the tab at the top of the bracket in the slot at the bottom frame of the machine.
  • Page 97 Repack/Return to SEC - Repacking the Processor 8.2.12 8.2.13 8.2.14 8.2.15 WARNING: The scan- 8.2.15 Generate the bar code ner weighs 84 lb label. Cross off non-applicable (38 kg). Due to the codes. weight and size of the scanner, two people will be needed to remove the scanner from the scanner stand.

  • Page 98: Repacking The Scanner

    Repack/Return to SEC - Repacking the Scanner Serviceable 95E12780 8.2.16 8.3.1 95E12780 8.3.2 8.3.3 8.2.16 Apply the bar code 8.3.3 Set the scanner in the label to the stretch wrap at the box on the bubble pack pad. open end of the pallet. 8.3.0 Repacking the Scanner 8.3.1 Materials required to repack the scanner are shown.
  • Page 99 Repack/Return to SEC - Repacking the Scanner 8.3.4 8.3.5 Serviceable 8.3.6 8.3.7 8.3.4 Fill voids with bubble pack. 8.3.5 Close the box and secure with tape. 8.3.6 Band the box to any serviceable pallet. 8.3.7 Generate the bar code label. Cross off non-applicable codes.
  • Page 100 Repack/Return to SEC - Repacking the Scanner 8.3.8 8.3.8 Apply the bar code label to the box at the open end of the pallet. WCP/CC C2128/C2636/C3545 Launch - November 2004...

  • Page 101: Repacking The Office Finisher (Ure)

    Repack/Return to SEC - Repacking the Office Finisher (URE) Serviceable Serviceable 8.4.1 8.4.2 8.4.3 8.4.4 8.4.0 Repacking the Office Finisher (URE) 8.4.1 Tools and materials required to repack the finisher are shown. 8.4.2 Band the box, repacked by the driver, to any service- able pallet.

  • Page 102: Repacking The Advanced (Twe) And Professional (Twf) Finishers

    Repack/Return to SEC - Repacking the Advanced (TWE) and Professional (TWF) Finishers 48” x 42” 95E12780 Serviceable 8.5.1 8.5.2 8.5.3 8.5.4 8.5.0 Repacking the Advanced (TWE) and Professional (TWF) Finishers 8.5.1 Tools and materials required for repacking the Advanced and Professional Finisher are shown.
  • Page 103 Repack/Return to SEC - Repacking the Advanced (TWE) and Professional (TWF) Finishers 8.5.5 8.5.6 95E12780 8.5.7 8.5.8 8.5.5 Wrap the front left cover in bubble pack. 8.5.6 Wrap the H-Transport in bubble pack. 8.5.7 Wrap the latch housing in bubble pack. 8.5.8 Retrieve a 95E12780 box and...
  • Page 104 Repack/Return to SEC - Repacking the Advanced (TWE) and Professional (TWF) Finishers 8.5.9 8.5.10 8.5.11 8.5.12 8.5.9 Place the H-Trans- port in the box. Place the booklet maker tray in the box. 8.5.10 Place the small exit tray, latch housing, and front left cover in the box.
  • Page 105 Repack/Return to SEC - Repacking the Advanced (TWE) and Professional (TWF) Finishers 501E3500 8.5.13 8.5.14 8.5.15 8.5.16 8.5.13 Tape two foam block to the finisher as shown. 8.5.14 Retrieve an service- able 42 inch by 48 inch pallet. 8.5.15 Place the finisher on the pallet as shown.
  • Page 106 Repack/Return to SEC - Repacking the Advanced (TWE) and Professional (TWF) Finishers 8.5.17 8.5.18 8.5.19 8.5.20 8.5.17 Place the box with the bubble packed items on the pallet next to the finisher as shown. Place a corner board on the finisher edge on the outboard side.

  • Page 107: Repacking The Rear Wall Kit

    Repack/Return to SEC - Repacking the Rear Wall Kit Serviceable Serviceable 8.6.1 8.6.2 8.6.0 Repacking the Rear Wall Kit 8.6.1 Tools and materials required for repacking the rear wall are shown. 8.6.2 Ensure rear wall kits and mounting hardware are bubble wrapped.
  • Page 108 Repack/Return to SEC - Repacking the Rear Wall Kit Notes: WCP/CC C2128/C2636/C3545 Launch - November 2004...

This manual is also suitable for:

Wcp c2636Wcp c3545Cc c2128Cc c2636Cc c3545
