Summary of Contents for Growatt MOD TL3-X2(Pro)
- Page 1 MOD 3-15KTL3-X2 (Pro) & User Manual Download Manual Shenzhen Growatt New Energy Co., Ltd. 4-13/F, Building A, Sino-German (Europe) Industrial Park, Hangcheng Blvd, Bao'an District, Shenzhen, China +86 755 2747 1942 service@ginverter.com www.ginverter.com GR-UM-337-A-01(PN: 044.0121801)
- Page 2 Ltd. (hereinafter referred to as Growatt). Notice All products, services and features are stipulated by the contract made between Growatt and the customer. All or part of the products, services and features described in this document may not fall under the scope of purchase or usage. Unless otherwise specified in the contract, Growatt makes no representations or warranties, express or implied with respect to this documentation.
- Page 3 The content of this document is continually reviewed and amended, where necessary. However, discrepancies cannot be excluded. Growatt reserves the right to make changes to the material at any time and without notice in order to keep the document accurate and up-to-date.
-
Page 4: Symbols In This Manual
Symbol convention Symbols in this manual Direct Current (DC) The following safety symbols are used throughout this document to denote important safety information. Familiarize yourself with the symbols and their meaning before installing or operating this instrument. Alternating Current (AC) Symbol Meaning Refer to the manual... -
Page 5: Table Of Contents
2.5.6 Dry contact ......................... 9 5.8 Connecting the meter (optional)................30 2.5.7 AFCI (Arc Fault Circuit Interrupter)..............10 5.8.1 Connecting Growatt smart meter ............... 31 2.5.8 GFCI (Ground Fault Circuit Interrupter) ............. 10 5.8.2 Connecting Eastron smart meter................. 33 2.5.9 Monitoring....................... 10 5.8.3 Connecting CHINT smart meter ................ - Page 6 6.3 Setting the communication address............... 40 12.1.1 Inverter alarm ....................... 61 12.2 System fault ......................67 6.4 Setting the country/area ..................41 12.2.1 Inverter fault ......................67 6.5 Setting the export limitation parameters............. 41 13 EU Declaration of conformity............74 6.6 Restoring to factory settings ...................
-
Page 7: Safety
Information Information Growatt shall not be held liable for any damage caused by the following circumstances: Use the product beyond the conditions specified in this manual or failure to meet the During installation, do not open the inverter without permission to Ÿ... - Page 8 1.1.3.3 Using a ladder Follow the wiring instructions specified in the user manual; Ÿ otherwise, any device damage caused by improper wiring will not be Any work which is performed 2 meters or more is known as work at Ÿ covered under any warranty.
-
Page 9: Product Overview
2 Product overview Figure 2-1 Schematic diagram 2.1 Introduction Features DC/DC DC/AC Output relay Boost converter GFCI DC Switch The MOD TL3-X2(Pro) is a high-quality grid-tied inverter that converts the solar power DC LINK generated by the PV panels into three-phase AC power and feeds it to the utility grid. Model description Filter Filter... -
Page 10: Application Scenarios
2.4 Application scenarios 2.5.2 LED indicator The MOD TL3-X2 (Pro) inverter is equipped with a leaf-shaped LED indicator, which 2.4.1 Grid-tied PV demonstrates the operating status of the inverter. The meaning of the LED indication is illustrated in the table below: Table 2-4 LED indicator description The use of an external electrical meter depends on the application Ÿ... - Page 11 DC side, which might lead to a fire hazard. Growatt inverters are integrated function can be activated. The detailed configuring steps are shown in Section 8.1 Export with an arc-fault detection function in compliance with UL1699B-2018 standards.
-
Page 12: Inspection Upon Delivery
3 Inspection upon delivery 3.2 Moving the inverter 3.1 Checking the packing list Before unpacking the inverter, check the outer packing materials for any externally visible When moving the inverter, do not place your hands on the terminals, Ÿ damage. After unpacking the inverter, check the scope of delivery for completeness. If the which are not designed to support the weight of the inverter. -
Page 13: Installation
Installation 4 3.4 Dimensions and weight 4.1 Required tools 3.4.1 Dimensions of the package Table 4-1 Installation tools Figure 3-4 Dimensions of the packing carton Tools Drilling bit Cross-head Hammer drill Hammer Level (Φ8mm) screwdriver 253mm 513mm 480mm Measuring tape Heat gun Vacuum Marker... -
Page 14: Carrier Requirements
4.2.2.1 Angle requirements Figure 4-1 Environment requirements Figure 4-3 Angle requirements Figure 4-2 Installing an awning and clearance requirements 4.2.2.2 Space requirements To ensure optimal operation of the inverter and facilitate ease of operation, please Ÿ reserve enough space around the inverter. The temperature at the ventilation air outlet is relatively high. -
Page 15: Wall-Mounted Installation
Step 1. Determining the hole position When multiple inverters are installed, please refer to the following figures to maintain proper clearances: Place the level at the predetermined installation position, then place the bracket above the level and mark the hole positions using the marker. Figure 4-5 Horizontal installation Figure 4-7 Dimensions of the mounting bracket ≥500mm... -
Page 16: Installing The Inverter
Step 3: Securing the mounting bracket Step 2. Secure the inverter to the bracket using M5 screws. Knock the plastic expansion tube, which can be found in the accessory bag, into the hole Figure 4-11 Securing the screw onto the inverter with a hammer. -
Page 17: Electrical Connection
Growatt shall not be Unqualified persons shall not perform any electrical connections. Ÿ... -
Page 18: Connecting The Grounding Cable
When using a heat gun, please take precautions to avoid Ÿ inverter might fail to disconnect from the grid when an exception equipment burns. occurs, which might lead to severe damage. Growatt shall not be DANGER liable for the consequences. Figure 5-1 Preparing the cable Each inverter must be equipped with an AC output breaker, and Ÿ... - Page 19 5.6 Connecting the DC input cable Figure 5-3 Assembling the AC connector Before connecting the DC input cables, verify that the DC voltage Ÿ is within the permissible range (＜36V DC) and ensure that the DC SWITCH on the inverter is set to the OFF position. Otherwise, high voltages may lead to electric shocks.
-
Page 20: Connecting The Communication Cable
5.7 Connecting the communication cable Description The MOD 3-15TL3-X2 (Pro) inverter has two PV inputs. When arranging the signal cables, separate them from power Ÿ Figure 5-6 PV inputs cables and keep them away from strong interference sources to avoid communication interruption. If a signal cable is not required to be connected, please do not Ÿ... -
Page 21: Connecting The Com Connector
To enable Figure 5-10 Securing the cables in place these functions, an external smart meter is required. Please purchase the meter from Growatt and the recommended model is the TPM-CT-G 100A smart meter. NOTICE After connecting the meter, you need to enable the meter Ÿ... - Page 22 5.8.1.1 3P3W wiring The phase sequence of the inverter must correspond with that of the Ÿ Figure 5-13 3P3W System (with a Growatt smart meter) meter; otherwise, it will not support export limitation and operating the inverter in different modes.
- Page 23 5.8.2 Connecting Eastron smart meter Manufacturer Eastron Table 5-6 Eastron smart meter specific parameters Mounting DIN rail 35mm Manufacturer Eastron Ingress protection IP51 (indoor) Type SDM630CT-Modbus V3 Material Self-extinguishing UL94V-0 General Specifications Communication port PIN A, RS485A/PIN B, RS485B Voltage AC (Un) 3*230V Voltage Range 184~299V AC...
- Page 24 5.8.2.2 3P4W wiring General specifications Figure 5-16 3P4W system (with an Eastron smart meter) Accuracy Active power 1% of range maximum Reactive power 2% of range maximum RS485B RS485A Environment Rated temperature -10℃~+45℃ Inverter Limit temperature -25℃~+70℃ Meter Relative humidity (average annual) <75% Atmosphere 63.0kPa~106.0kPa...
-
Page 25: Connecting The Monitoring Module
▲up via the cloud server and the APP. Recommended datalogger model: Table 5-8 Datalogger specifications The inverter side Brand Recommended model Applicable system The inverter side GROWATT A single inverter Ÿ ShineWiFi-X GROWATT ShineLan-X A single inverter Ÿ GROWATT A single inverter Ÿ... -
Page 26: Configuring The Datalogger
Human-machine interaction 6 5.9.4 Configuring the datalogger 6.1 OLED control You can access the configuration guide of the following datalogger models by scan the corresponding QR code. Table 6-1 Touch button Table 5-9 Datalogger configuration guide Symbol Description Explanation Switch pages or increase Datalogger Single tap the number by 1... -
Page 27: Setting The Country/Area
6.4 Setting the country/area Single tap to view the options available or increase the number by one; double tap to confirm your setting. Single tap to view the options or increase the number by one; double tap to confirm your settings. -
Page 28: Commissioning
Note: Setting the following parameters on the ShinePhone APP or the Server webpage requires the password. To access the password, Checking items Criteria please contact Growatt service personnel. Information Installation of the inverter The inverter is securely installed The communication cables and the power Cable layout 8.1 Setting the export limitation... -
Page 29: On The Server Webpage
8.1.3 On the Server webpage Step1. Log in with your Server account Step2. Setting > Export limit setting > Enable > Set the Phase level 8.2 DRMs & Remote logic control Ÿ Make sure the cable glands have been tightened firmly. If the cable glands are not mounted properly, the inverter can be Ÿ... -
Page 30: Active Power Control With A Rrcr (For Eu Models)
8.2.1.1 Method of asserting demand response modes 8.2.2.1 The following table illustrates the pin assignment and function: Figure 8-1 DRMs wiring diagram Figure 8-3 RRCR wiring diagram RRCR DRED RRCR 1 2 3 4 5 6 7 8 Table 8-1 DRMs function description A DRM socket B DRM socket Mode... -
Page 31: Setting The Com Address Of The Inverter
System maintenance 9 8.3 Setting the COM address of the inverter To ensure the long-term and reliable operation of the system, it is recommended to perform maintenance on a regular basis as instructed in this section. For details about setting COM address on the OLED display, please see Section 6.3 Setting the communication address. -
Page 32: Decommissioning
Specification 11 10 Decommissioning 11.1 MOD TL3-X2 (Pro) 10.1 Removing the inverter Disconnect all electrical connections from the inverter, including the RS485 Ÿ Model communication cable, DC input cables, AC output cables, and the grounding cable. 3000TL3-X2 4000TL3-X2 5000TL3-X2 6000TL3-X2 Remove the inverter from the mounting bracket. - Page 33 Model Model 3000TL3-X2 4000TL3-X2 5000TL3-X2 6000TL3-X2 3000TL3-X2 4000TL3-X2 5000TL3-X2 6000TL3-X2 (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) Specifications Specifications Power factor (@nominal Internal consumption at >0.99 power) night Adjustable power factor 0.8Leading ...0.8Lagging Topology Non-isolated THDi Cooling Natural heat dissipation <3% Electronics protection AC grid connection type...
- Page 34 Model Model 7000TL3-X2 8000TL3-X2 9000TL3-X2 10KTL3-X2 7000TL3-X2 8000TL3-X2 9000TL3-X2 10KTL3-X2 (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) Specifications Specifications Input data (DC) Adjustable power factor 0.8Leading ...0.8Lagging Max. recommended PV THDi 10500W 12000W 13500W 15000W <3% power(for module STC) AC grid connection type 3W+PE /3W+N+PE Max.
- Page 35 Model Model 7000TL3-X2 8000TL3-X2 9000TL3-X2 10KTL3-X2 11KTL3-X2 12KTL3-X2 13KTL3-X2 15KTL3-X2 (Pro) (Pro) (Pro) (Pro) Specifications Specifications (Pro) (Pro) (Pro) (Pro) Topology Non-isolated Input data (DC) Max. recommended PV Cooling Natural heat dissipation 16.5kW 18kW 19.5kW 22.5kW power(for module STC) Electronics protection IP66 Max.
- Page 36 Model Model 11KTL3-X2 12KTL3-X2 13KTL3-X2 15KTL3-X2 11KTL3-X2 12KTL3-X2 13KTL3-X2 15KTL3-X2 (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) (Pro) Specifications Specifications Adjustable power factor 0.8Leading ...0.8Lagging Topology Non-isolated THDi Cooling Natural heat dissipation <3% Electronics protection AC grid connection type 3W+PE /3W+N+PE IP66 degree Overvoltage category...
-
Page 37: Troubleshooting
Description Troubleshooting when a fault occurs, indicating that a system fault or an inverter fault has occurred. In message some cases, you may need to contact Growatt for technical assistance. 1. Restart the inverter. 12.1 System alarm Warning 217 BDC abnormal 2. - Page 38 1. Check if the communication cable is properly 1. Restart the inverter. Over- CT pairing timed connected. Warning 407 2. If the error message persists, contact Growatt Warning 307 temperature 2. If the error message persists, contact Growatt support. support.
- Page 39 2. Check if the temperature sensor is well- persists, contact Growatt support. Warning 505 lead-acid connected. battery is 3. If the error message persists, contact Growatt disconnected 1. Check if the load power exceeds the upper limit. support. Off-grid output Warning 606 2.
-
Page 40: System Fault
Residual I High 2. If the error message persists, please contact Error 306 CT LN Reversed 2. If the error message persists, contact Growatt Growatt support. support. 1. Disconnect the DC switch immediately and 1. Check if the communication cable is properly check the voltage. - Page 41 Error 413 IGBT drive fault 2. If the error message persists, please contact Error 402 component in 2. If the error message persists, contact Growatt Growatt support. output current support. 1. Restart the inverter. 1. Check if the output current is balanced after...
- Page 42 Growatt support. disconnected 2. If the error message persists, please contact Growatt support. BOOST short- Error 428 Please contact Growatt support. Lithium battery 1. Check the wiring of the battery terminals. circuited Error 507 overload 2. If the error message persists, please contact protection Growatt support.
-
Page 43: Eu Declaration Of Conformity 13
Error 605 2. If the error message persists, please contact self-test failed Shenzhen Growatt New Energy Co. Ltd confirms that the Growatt inverters and Growatt support. accessories described in this document are in compliance with the above-mentioned EU directives. The entire EU Declaration of Conformity can be found at www.ginverter.com. -
Page 44: Contact Us
15 Contact us If you have technical problems concerning our products, please contact Growatt Service at +86 755 2747 1942. To provide you with the necessary support, please have the following information ready: Serial Number Format: LSLxxxxxx Model SxxBxxDxxTxxPxxUxxMxxxx Error message...
