Always use the power cable that ships with the MiniDock. If you need to
replace the cable, follow these standards:
T
In North America, the cable should be rated for 120 volts (V), 7 amps (A).
The plug is a NEMA 5-15P. Use an SVT or SJT 18/3 AWG cable that is
less than 15 feet (4.5 m) long. Use connector type IEC320.
T
In Europe, the cable should be rated for 230 V (220-240 V), 10A. The
plug is country-specific. Use an H05VV-F or H05VVH2-F cable that is
less than 15 feet (4.5 m) long. Use connector type EN60320.

MiniDock FEATURES

MiniDock features are found on every surface of the unit. To become famil-
iar with these features, read each of the following sections.

Front and Top

The following figure shows the features found on the front and top of the
MiniDock. Descriptions of these features follow the figure.
T
Docking Guides — The docking guides on the glide panel ensure that
your NEC Versa is aligned properly for docking. These guides fit into
specially placed notches on the bottom of the notebook computer.
1-2 Introducing the NEC MiniDock 6000
Front and top features
