1-8 Technical Information

NEC VERSA MINIDOCK 6000 CHIPSET

Refer to Table 1-1 for a quick summary of the chip types used in the system. See the
Abbreviations section at the beginning of this manual for a translation of chip technologies.
Table 1-1 NEC Versa MiniDock 6000 Chip Types and Technologies
Chip
PCI1131
PCIset 82380AB
(Moon PCI)
PCIset 82380AF
(Moon ISA)
PCI0646U
PCI Bus-to-CardBus Controller (PCI1131)
The PCI1131 supports two 32-bit CardBus credit-card-size add-in modules that give the
PC access to peripheral devices, such as modems, video programming, printers, external
video monitors, and local area networks.
T
bandwidth significantly greater than that of other CardBus controllers
T
supports two 32-bit CardBus credit-card-size and also supports 16-bit PCMCIA
(Personal Computer Memory Card Industry Association) or PC Card add-in
modules.

PCI to ISA Controller (PCIset 82380AB)

This chip provides the docking station with docking control and hot insertion as applicable
to the PCI/ISA bus. The PCIset 82380AB integrates the following in PCI/ISA technology:
T
supports full ISA including ISA masters
T
supports PCI at 25 Mhz to 33 Mhz
T
supports ISA at 7.5 Mhz to 8.33 Mhz
T
provides byte swap logic, I/O recovery support, wait-state generation, refresh and
SYSCLK generation.
Manufacturer Description
Texas Instruments CardBus Controller
Intel PCI to ISA Support
Intel PCI to PCI Support
CMD Technology, IDE Controller
Inc.
Technology
208-pin (TQFP)
160-pin MQFP
208-pin SQFP
100-pin SQFP
