Maple Systems HMI5000 Series Installation Manual page 12

12
2. Set the HMI in the panel cutout and hold it in place until all
clamps are in position.
3. Tighten the screw clamps in an even pattern until all are
uniformly snug.
Caution: Do not over-tighten the screws beyond snugness or
you may damage the housing or warp the overlay.
Mounting Clamp Placement
Model
HMI5043N/T
HMI5056N
HMI5070NH/TH
HMI5100N/T,
HMI5104TH,
HMI5104XH
HMI5121X
HMI5150X
HMI5070ETH
REINSTALLATION: If, at anytime, you are required to reinstall an
HMI into a panel, be aware that the gasket will take a 'set' to the panel
and may no longer provide an adequate NEMA 4 seal Therefore, for best
results, we recommend that you replace the gasket if reinstallation is
required.
1010-1005 Rev 04
Left Right
Side Side
2 2
1 1
2 2
0 0
2 2
2 2
1 1
HMI5000 Series Installation Guide
Top Bottom
0 0
2 2
2 0
3 2
3 3
3 3
2 2
www.maplesystems.com
Clamps
Provided
with Unit
4
4
4
5
9
10
6
