This warranty is in lieu of any other warranty either expressed or implied. Maple Systems’ liability is limited to the repair or replacement of the Product only, and not costs of installation, removal, or damage to user’s property or other liabilities. If Maple...
Sil ver Plus Se ries Installation of OITs CE Com pli ance The Silver Plus Series OITs have been tested to conform to European CE requirements per Council Directive 89/336/EEC. The European Union created these requirements to ensure conformity among products traded in those countries. Specifically, the Silver Plus Series OITs meet or exceed the noise emissions and immunity requirements as set forth in the EN50081 (Emissions) and EN50082 (Immunity) standards.
Con trol Panel Ground ing The control panel should be connected to a good, high-integrity earth ground, both for safety considerations and shielding purposes. Maple Systems cannot overemphasize the importance of good grounding. If you fail to use good grounding procedures during installation, sporadic malfunction of the OIT may occur: •...
Sil ver Plus Se ries • Connect the power cable’s shield wire to the OIT’s chassis ground terminal. • Connect the control panel to earth ground using a copper grounding rod close to the OIT and control panel. Hinged doors on control panels do not provide a long-term electrical connection to the rest of the enclosure.
Page 7
Sil ver Plus Se ries The power cable for the OIT should be 18AWG, 2-conductor wire with a shield drain wire and protective shield (foil or braid). The shield drain wire must be connected to earth ground at both ends of the cable. Please refer to the “Connect the OIT to Power” section for more information.
It is necessary to follow all installation procedures described in this chapter for electrical noise immunity and CE compliance. Your Maple Systems OIT is designed to connect easily to your PLC. External rear connectors provide quick connections for power, communications and programming wiring.
Sil ver Plus Se ries The power connector on the Silver Plus Series is a terminal block with wire clamps. Lugs are not required. Power Con nec tor on OIT Panel Prep a ra tion A metal panel or mounting surface with a minimum thickness of 15 gauge (0.059 inch/3.3mm) if cold-rolled steel or hardened steel, or 10 gauge (0.101 inch/2.6mm) if aluminum alloy (6061-T6 preferred) is required.
Screw Clamp Placement Clamps Tightened Mount ing Clip Bracket Place ment Model Left Side Right Side Bottom HMI5056T HMI5080T HMI5104T/X HMI5121T/X HMI5150X STEPS: 1. Set the OIT in the panel cutout and hold it in place until all clamps are in position.
Sil ver Plus Se ries Con fig u ra tion Wir ing The OIT must be configured for a particular protocol before use. The EZware-5000 software is used for configuring the OIT. For detailed instructions on installing and using the software, please refer to the software documentation section of this manual. Con nect the OIT to the PC for Con fig u ra tion To configure the OIT using Maple System’s configuration software, you will need an Ethernet crossover cable, Maple P/N 7431-0102.
