(RHR), which de-energizes SOL 1. The unit then operates with refrigerant flow in the evaporator reheat coil
and condenser coil circuit no. 1. See Figure 27.
Figure 26: Cooling operation piping schematic - circuit no. 1
Callout Component
A Airflow
B Evaporator coil
C Open solenoid valve (SOL 1)
D Accumulator
E Compressor
F Closed solenoid valve (SOL 2)
Callout
G
H
I
J
K
L
Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
Johnson Controls Ducted Systems
Component
Reheat valve (SOL 3)
Reheat coil
Refrigerant flow
Check valve
Condenser coil
TXV
65
