Johnson Controls ZL Series Installation Manual page 6

WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
WARNING
ELECTRICAL SHOCK, FIRE OR EXPLOSION
HAZARD
Failure to follow safety warnings exactly could result in
dangerous operation, serious injury, death or property
damage. Improper servicing could result in dangerous
operation, serious injury, death or property damage.
• Before servicing, disconnect all electrical power to
furnace.
• When servicing controls, label all wires prior to
disconnecting. Reconnect wires correctly.
• Verify proper operation after servicing.
Due to system pressure, moving parts, and electrical
components, installation and servicing of air
conditioning equipment can be hazardous. Only
qualified, trained service personnel should install,
repair, or service this equipment. Untrained
personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters.
Observe all precautions in the literature, labels,
and tags accompanying the equipment whenever
working on air conditioning equipment. The
installation must conform with local building codes
or, in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, and/or the
National Gas and Propane Installation Code, CSA
B149.1.
6 Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
Wear safety glasses and work gloves. Use
quenching cloth and have a fire extinguisher
available during brazing operations.
Inspection
As soon as a unit is received, it should be inspected
for possible damage during transit. If damage is
evident, the extent of the damage should be noted
on the carrier's freight bill. A separate request for
inspection by the carrier's agent should be made in
writing.
This product must be installed in strict compliance
with the enclosed installation instructions and any
applicable local, state and national codes including,
but not limited to, building, electrical, and mechanical
codes. The furnace and its individual shut-off valve
must be disconnected from the gas supply piping
system during any pressure testing at pressures in
excess of 1/2 psig. Pressures greater than 1/2 psig
will cause gas valve damage resulting in a hazardous
condition. If it is subjected to a pressure greater than
1/2 psig, the gas valve must be replaced. The furnace
must be isolated from the gas supply piping system
by closing its individual manual shut-off valve during
any pressure testing of the gas supply piping system
at test pressures equal to or less than 1/2 psig
Reference
Additional information is available in the following
reference forms:
• Technical Guide - ZX/ZQ/ZY/ZL 04-14 1068152
• General Installation - ZL08-14 5830280
• Economizer Accessory:
• Power Exhaust:
Renewal parts
Contact your local UP parts distribution center for
authorized replacement parts.
Johnson Controls Ducted Systems
CAUTION
- Vertical Flow Dry Bulb Economizer
Field Installed
- Horizontal Flow Dry Bulb Economizer
Field Installed
- Vertical Flow Dry Bulb Economizer
Field Installed
- Horizontal Flow Dry Bulb Economizer
Field Installed
