Johnson Controls ZL Series Installation Manual page 50

Table 26: Indoor blower specifications
Airflow
Model Size (ton)
option
Phase
Standard 3
ZL 08 (7.5) Medium 3
High static 3
Standard 3
ZL 09 (8.5) Medium 3
High static 3
Standard 3
ZL 12 (10) Medium 3
High static 3
Standard 3
ZL 14 (12.5) Medium 3
High static 3
50 Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
Motor
MAX
rpm Eff. SF Frame
bmp
2.4 1725 0.80 1.15 56Y
2.4 1725 0.80 1.15 56Y
3.7 1725 0.84 1.15 56HZ
2.4 1725 0.80 1.15 56Y
2.4 1725 0.80 1.15 56Y
3.7 1725 0.84 1.15 56HZ
2.4 1725 0.80 1.15 56Y
3.7 1725 0.84 1.15 56HZ
5.25 1725 0.84 1.15 145TY
2.9 1750 0.87 1.15 56Y
3.7 1750 0.90 1.15 184TZ
5.25 1750 0.90 1.15 184TZ
Johnson Controls Ducted Systems
Motor sheave
Datum dia. (in.) Bore (in.) Model
1.9 - 2.9 5/8 1VL34
2.8 - 3.8 5/8 1VL44
3.4 - 4.4 7/8 1VP50
1.9 - 2.9 5/8 1VL34
2.8 - 3.8 5/8 1VL44
3.4 - 4.4 7/8 1VP50
2.8 - 3.8 5/8 1VL44
3.4 - 4.4 7/8 1VP50
4.3 - 5.3 7/8 1VP56
2.8 - 3.8 5/8 1VL44
3.4 - 4.4 7/8 1VP50
4.3 - 5.3 7/8 1VP56
Blower sheave
Datum dia. (in.) Bore (in.) Model
7.0 1 AK74
7.0 1 AK74
7.0 1 AK74
7.0 1 AK74
7.0 1 AK74
7.0 1 AK74
7.5 1 AK79
7.5 1 AK79
7.9 1 BK85
7.5 1 AK79
7.5 1 AK79
7.9 1 BK85
Belt
A47
A48
A50
A47
A48
A50
A50
A50
BX52
A50
A52
BX52
