Table 16: ZL12 physical data
Evap fan data belt drive
Filters
1 MagnaDRY reheat option is available in power supply of 208/230/460/575-3-60 options only.
2 2 in. throwaway, standard, MERV 4 (Minimum Efficiency Reporting Value).
40 Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
Component
Nominal tonnage
Airflow option
Quantity
Fan size (in.)
Type
Motor sheave
Blower sheave
Belt
Motor max bhp, 3 phase
rpm
Frame size
Quantity - size
Johnson Controls Ducted Systems
Models
ZLG12
10
A B C
1 1 1
15 x 15 15 x 15 15 x 15
Centrifugal
1VL44 1VP50 1VP56
AK79 AK79 BK85
A50 A50 BX52
2.4 3.7 5.25
1725 1725 1725
56Y 56HZ 145TY
2
4 - (20 x 20 x 2) 2
ZLE12
10
A B C
1 1 1
15 x 15 15 x 15 15 x 15
1VL44 1VP50 1VP56
AK79 AK79 BK85
A50 A50 BX52
2.4 3.7 5.25
1725 1725 1725
56Y 56HZ 145TY
4 - (20 x 20 x 2) 2
