Johnson Controls ZL Series Installation Manual page 14

ZL08 to 14 unit weights
Figure 8: Unit 4 point load weight
Figure 10: Center of gravity
Table 2: ZL08 to 14 corner weights
Model Size Weight (lb)
(ton)
Shipping Operating
ZLE 08 (7.5) 925 920
ZLE 09 (8.5) 930 925
ZLE 12 (10) 960 955
ZLE 14 (12.5) 985 980
ZLG 08 (7.5) 1045 1040
ZLG 09 (8.5) 1035 1030
ZLG 12 (10) 1055 1050
ZLG 14 (12.5) 1075 1070
Table 3: ZL08-14 corner weights with MagnaDRY option
Model Size Weight (lb)
(ton)
Shipping Operating
ZLE 08 (7.5) 940 935
ZLE 09 (8.5) 945 940
ZLE 12 (10) 978 973
ZLE 14 (12.5) 1003 998
ZLG 08 (7.5) 1060 1055
ZLG 09 (8.5) 1050 1045
ZLG 12 (10) 1073 1068
ZLG 14 (12.5) 1093 1088
14 Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
Center of gravity 4 point load location (lb)
X Y A B
45 37 262 282
46 36 258 284
46 35 258 287
44 35 277 283
44 37 304 312
45 36 294 309
45 36 299 313
44 36 309 316
Center of gravity 4 point load location (lb)
X Y A B
45 37 269 289
46 36 256 290
46 35 261 288
44 35 278 285
44 37 313 319
45 36 295 315
45 36 302 322
44 36 312 320
Johnson Controls Ducted Systems
Figure 9: Unit 6 point load weight
C D A
195 181 173 181
201 182 169 180
216 194 169 181
213 208 184 186
215 210 202 205
219 208 194 201
224 214 198 204
225 220 205 208
C D A
195 182 178 186
209 185 167 181
222 202 171 183
220 215 185 188
213 209 208 211
225 211 195 203
230 215 199 208
231 226 207 211
6 point load location (lb)
B C D E
191 131 125
192 136 128
195 146 136
189 142 140
209 144 141
208 147 142
210 151 146
211 151 148
6 point load location (lb)
B C D E
195 132 126
197 143 131
195 150 141
191 147 145
213 143 141
212 151 145
217 155 148
214 154 152
F
119
120
127
138
139
138
142
146
F
120
121
132
143
139
139
142
150
